A single control point. More...

#include <ControlPoint.h>

Inheritance diagram for Isis::ControlPoint:

Collaboration diagram for Isis::ControlPoint:

Classes
struct	RadiusSource
struct	SurfacePointSource

Public Types
enum	PointType { Fixed = 0, Constrained = 1, Free = 2 }
	These are the valid 'types' of point. More...
enum	Status { Failure, Success, PointLocked }
	This is a return status for many of the mutating (setter) method calls. More...
enum	ConstraintStatus { LatitudeConstrained = 0, LongitudeConstrained = 1, RadiusConstrained = 2 }
	This is a convenience member for checking number of constrained coordinates in the SurfacePoint. More...

Public Member Functions
	ControlPoint ()
	Construct a control point.
	ControlPoint (const ControlPoint &)
	Copy the given control point into this instance.
	ControlPoint (const QString &id)
	Construct a control point with given Id.
	ControlPoint (const ControlPointFileEntryV0002 &fileEntry, const Distance &majorRad, const Distance &minorRad, const Distance &polarRad)
	This is used when reading from a protocol buffer.
	~ControlPoint ()
	This destroys the current instance and cleans up any and all allocated memory.
ControlNet *	Parent ()
void	Load (PvlObject &p)
	Loads the PvlObject into a ControlPoint.
void	Add (ControlMeasure *measure)
	Add a measurement to the control point, taking ownership of the measure in the process.
int	Delete (ControlMeasure *measure)
	Remove a measurement from the control point, deleting reference measure is allowed.
int	Delete (QString serialNumber)
	Remove a measurement from the control point, deleting reference measure is allowed.
int	Delete (int index)
	Remove a measurement from the control point, deleting reference measure is allowed.
Status	ResetApriori ()
	Reset all the Apriori info to defaults.
const ControlMeasure *	GetMeasure (QString serialNumber) const
	Get a control measure based on its cube's serial number.
ControlMeasure *	GetMeasure (QString serialNumber)
	Get a control measure based on its cube's serial number.
const ControlMeasure *	GetMeasure (int index) const
ControlMeasure *	GetMeasure (int index)
const ControlMeasure *	GetRefMeasure () const
	Get the reference control measure.
ControlMeasure *	GetRefMeasure ()
	Get the measure that is the reference directly.
Status	SetChooserName (QString name)
	Set the point's chooser name.
Status	SetDateTime (QString newDateTime)
	Set the point's last modified time.
Status	SetEditLock (bool editLock)
	Set the EditLock state.
Status	SetId (QString id)
	Sets the Id of the control point.
Status	SetRefMeasure (ControlMeasure *cm)
	Set the point's reference measure.
Status	SetRefMeasure (int index)
	Set the point's reference measure.
Status	SetRefMeasure (QString sn)
	Set the points reference measure.
Status	SetRejected (bool rejected)
	Set the jigsawRejected state.
Status	SetIgnored (bool newIgnoreStatus)
	Set whether to ignore or use control point.
Status	SetAdjustedSurfacePoint (SurfacePoint newSurfacePoint)
	Set or update the surface point relating to this control point.
Status	SetType (PointType newType)
	Updates the control point's type.
Status	SetAprioriRadiusSource (RadiusSource::Source source)
	This updates the source of the radius of the apriori surface point.
Status	SetAprioriRadiusSourceFile (QString sourceFile)
	This updates the filename of the DEM that the apriori radius came from.
Status	SetAprioriSurfacePoint (SurfacePoint aprioriSP)
	This updates the apriori surface point.
Status	SetAprioriSurfacePointSource (SurfacePointSource::Source source)
	This updates the source of the surface point.
Status	SetAprioriSurfacePointSourceFile (QString sourceFile)
	This updates the filename of where the apriori surface point came from.
Status	ComputeApriori ()
	This method computes the apriori lat/lon for a point.
Status	ComputeResiduals ()
	This method computes the BundleAdjust residuals for a point.
Status	ComputeResiduals_Millimeters ()
	This method computes the residuals for a point.
SurfacePoint	GetAdjustedSurfacePoint () const
SurfacePoint	GetBestSurfacePoint () const
	Returns the adjusted surface point if it exists, otherwise returns the a priori surface point.
QString	GetChooserName () const
QString	GetDateTime () const
bool	IsEditLocked () const
bool	IsRejected () const
QString	GetId () const
	Return the Id of the control point.
bool	IsIgnored () const
bool	IsValid () const
bool	IsInvalid () const
bool	IsFixed () const
bool	HasAprioriCoordinates ()
bool	IsConstrained ()
bool	IsLatitudeConstrained ()
bool	IsLongitudeConstrained ()
bool	IsRadiusConstrained ()
int	NumberOfConstrainedCoordinates ()
QString	GetPointTypeString () const
	Obtain a string representation of the PointType.
PointType	GetType () const
QString	GetRadiusSourceString () const
	Obtain a string representation of the RadiusSource.
QString	GetSurfacePointSourceString () const
	Obtain a string representation of the SurfacePointSource.
SurfacePoint	GetAprioriSurfacePoint () const
RadiusSource::Source	GetAprioriRadiusSource () const
QString	GetAprioriRadiusSourceFile () const
SurfacePointSource::Source	GetAprioriSurfacePointSource () const
QString	GetAprioriSurfacePointSourceFile () const
int	GetNumMeasures () const
int	GetNumValidMeasures () const
int	GetNumLockedMeasures () const
	Returns the number of locked control measures.
bool	HasSerialNumber (QString serialNumber) const
	Return true if given serial number exists in point.
int	IndexOf (ControlMeasure *, bool throws=true) const
int	IndexOf (QString sn, bool throws=true) const
int	IndexOfRefMeasure () const
bool	IsReferenceExplicit () const
QString	GetReferenceSN () const
Statistics	GetStatistic (double(ControlMeasure::*statFunc)() const) const
	This function will call a given method on every control measure that this point has.
Statistics	GetStatistic (long dataType) const
QList< ControlMeasure * >	getMeasures (bool excludeIgnored=false) const
QList< QString >	getCubeSerialNumbers () const
const ControlMeasure *	operator[] (QString serialNumber) const
	Same as GetMeasure (provided for convenience)
ControlMeasure *	operator[] (QString serialNumber)
	Same as GetMeasure (provided for convenience)
const ControlMeasure *	operator[] (int index) const
	Same as GetMeasure (provided for convenience)
ControlMeasure *	operator[] (int index)
	Same as GetMeasure (provided for convenience)
bool	operator!= (const ControlPoint &pPoint) const
	Compare two Control Points for inequality.
bool	operator== (const ControlPoint &pPoint) const
	Compare two Control Points for equality.
const ControlPoint &	operator= (const ControlPoint &pPoint)
void	ZeroNumberOfRejectedMeasures ()
	Initialize the number of rejected measures to 0.
void	SetNumberOfRejectedMeasures (int numRejected)
	Set (update) the number of rejected measures for the control point.
int	GetNumberOfRejectedMeasures () const
	Get the number of rejected measures on the control point.
double	GetSampleResidualRms () const
	Get rms of sample residuals.
double	GetLineResidualRms () const
	Get rms of line residuals.
double	GetResidualRms () const
	Get rms of residuals.
void	ClearJigsawRejected ()
	Set jigsaw rejected flag for all measures to false and set the jigsaw rejected flag for the point itself to false.
ControlPointFileEntryV0002	ToFileEntry () const

Static Public Member Functions
static QString	PointTypeToString (PointType type)
	Obtain a string representation of a given PointType.
static PointType	StringToPointType (QString pointTypeString)
	Obtain a PointType given a string representation of it.
static QString	RadiusSourceToString (RadiusSource::Source source)
	Obtain a string representation of a given RadiusSource.
static RadiusSource::Source	StringToRadiusSource (QString str)
	Obtain a RadiusSource::Source from a string.
static QString	SurfacePointSourceToString (SurfacePointSource::Source source)
	Obtain a string representation of a given SurfacePointSource.
static SurfacePointSource::Source	StringToSurfacePointSource (QString str)
	Obtain a SurfacePoint::Source from a string.

Static Public Attributes
static const int	PointTypeCount = 3

Private Member Functions
void	SetExplicitReference (ControlMeasure *measure)
	Explicitly defines a new reference measure by pointer.
void	ValidateMeasure (QString serialNumber) const
	Throws an exception if none of the point's measures have the given serial number.
void	AddMeasure (ControlMeasure *measure)
	Do the actual work of adding a measure to this point, without changing any extra data.
void	PointModified ()

Private Attributes
ControlNet *	parentNetwork
	List of Control Measures.
QHash< QString, ControlMeasure * > *	measures
QStringList *	cubeSerials
ControlMeasure *	referenceMeasure
QString	id
	This is the control point ID.
QString	chooserName
	This is the user name of the person who last modified this control point.
QString	dateTime
	This is the last modified date and time.
PointType	type
	What this control point is tying together.
bool	invalid
	If we forced a build that we would normally have thrown an exception for then this is set to true.
bool	editLock
	This stores the edit lock state.
bool	jigsawRejected
	This stores the jigsaw rejected state.
std::bitset< 6 >	constraintStatus
	This stores the constraint status of the a priori SurfacePoint.
bool	referenceExplicitlySet
	This indicates if a program has explicitely set the reference in this point or the implicit reference is still the current reference.
bool	ignore
	True if we should preserve but ignore the entire control point and its measures.
SurfacePointSource::Source	aprioriSurfacePointSource
	Where the apriori surface point originated from.
QString	aprioriSurfacePointSourceFile
	FileName where the apriori surface point originated from.
RadiusSource::Source	aprioriRadiusSource
	Where the apriori surface point's radius originated from, most commonly used by jigsaw.
QString	aprioriRadiusSourceFile
	The name of the file that derives the apriori surface point's radius.
SurfacePoint	aprioriSurfacePoint
	The apriori surface point.
SurfacePoint	adjustedSurfacePoint
	This is the calculated, or aposterori, surface point.
int	numberOfRejectedMeasures
	This parameter is used and maintained by BundleAdjust for the jigsaw application.

Friends
class	ControlNet

Detailed Description

A single control point.

A control point is one or more measurements that identify the same feature or location in different images.

Author: 2005-07-29 Jeff Anderson

See Also: ControlMeasure ControlNet

History:: 2005-07-29 Jeff Anderson Original version

History:: 2006-01-11 Jacob Danton Added ReferenceIndex method and updated unitTest

History:: 2006-06-28 Tracie Sucharski, Added method to return measure for given serial number.

History:: 2006-10-31 Tracie Sucharski, Added HasReference method, changed ReferenceIndex method to throw error if there is no Reference ControlMeasure.

History:: 2007-01-25 Debbie A. Cook, Removed return statement in SetApriori method for case so that FocalPlaneMeasures will get set. The method already has a later return statement to avoid changing the lat/lon values.

History:: 2007-10-19 Debbie A. Cook, Wrapped longitudes when calculating apriori longitude for points with a difference of more than 180 degrees of longitude between measures.

History:: 2008-01-14 Debbie A. Cook, Changed call to Camera->SetUniversalGround in ComputeErrors to include the radius as an argument since the method has been overloaded to include radius.

History:: 2008-09-12 Tracie Sucharski, Add method to return true/false for existence of Serial Number.

History:: 2009-03-07 Debbie A. Cook Fixed ComputeErrors method to set focal plane coordinates without changing time and improved error messages.

History:: 2009-06-03 Christopher Austin, Added the invalid functionality along with forceBuild, fixed documentation errors.

History:: 2009-06-22 Jeff Anderson, Modified ComputeAprior method to correctly handle ground and held points. Previosuly it would throw an error if the lat/lon of a measure could not be computed. Also, modify the ComputeErrors method to not abort any longer if a control point lat/lon could not be projected back to a image line/sample.

History:: 2009-08-13 Debbie A. Cook Corrected calculation of scale used to get the undistorted focal plane coordinates to use the signed focal length (Z) from the CameraDistortionMap,

History:: 2009-08-21 Christopher Austin, Put the default return of ReferenceIndex() back as the first Measured measure.

History:: 2009-09-01 Eric Hyer, fixed some include issues.

History:: 2009-09-08 Eric Hyer, Added PointTypeToString method.

History:: 2009-10-13 Jeannie Walldren - Added detail to error messages.

History:: 2009-12-06 Tracie Sucharski, Renamed ComputeErrors to ComputeResiudals.

History:: 2010-03-19 Debbie A. Cook Replaced code in method ComputeErrors with call to CameraGroundMap->GetXY

History:: 2010-01-12 Tracie Sucharski, Added support for binary networds, added new parameters, renamed ComputeErrors to ComputeResiduals, renamed MaximumError to MaximumResidual, renamed AverageError to AverageResidual.

History:: 2010-03-19 Debbie A. Cook Replaced code in method ComputeErrors with call to CameraGroundMap->GetXY

History:: 2010-05-06 Tracie Sucharski, Use defaults of 0. instead of Isis::Null, because 0. is the default in the protocol buffers.

History:: 2010-05-11 Sharmila Prasad Added API's Copy Constructor to copy one point to another and ReferenceIndexNoException not to throw Exception if there are no reference point or no measures in a Control Point. Also added the boolean logical operator method = and !=.

History:: 2010-05-26 Tracie Sucharski, Changed point type of Ground to GroundXYZ, GroundXY, or GroundZ.

History:: 2010-06-01 Tracie Sucharski, Added Ellipsoid and DEM to AprioriSource enum. Change AprioriSourceBasemap to AprioriLatLonSourcFile and AprioriRadiusSourceFile.

History:: 2010-06-03 Tracie Sucharski, Moved SetReference method from ControlMeasure so check for multiple reference meausres can be done.

History:: 2010-06-17 Tracie Sucharski, Added Lock keyword, new methods SetLocked, Locked and NumLockedMeasures.

History:: 2010-06-04 Eric Hyer - removed parametor for PointTypeToString() additional working sessions for Control network design.

History:: 2010-07-27 Tracie Sucharski, Updated for changes made after additional working sessions for Control network design. Major change to keywords, including storing coordinates as x/y/z instead of lat/lon/radius. Needed methods to allow inputting either, and conversion methods.

History:: 2010-08-18 Tracie Sucharski, Updated for changes made to SurfacePoint covariance matrix.

History:: 2010-08-25 Tracie Sucharski, Fixed some bugs relating to conversions between sigmas and covariance matrices.

History:: 2010-09-13 Tracie Sucharski, Added methods for setting planetocentric sigmas as both degrees and meters, as a result of changes made to the SurfacePoint class.

History:: 2010-09-15 Tracie Sucharski, It was decided after mtg with Debbie, Stuart, Ken and Tracie that ControlPoint will only function with x/y/z, not lat/lon/radius. It will be the responsibility of the application or class using ControlPoint to set up a SurfacePoint object to do conversions between x/y/z and lat/lon/radius. So... remove all conversion methods from this class. It was also decided that when importing old networks that contain Sigmas, the sigmas will not be imported, due to conflicts with the units of the sigmas.

History:: 2010-05-11 Sharmila Prasad Added API's Copy Constructor to copy one point to another and ReferenceIndexNoException not to throw Exception if there are no reference point or no measures in a Control Point.

History:: 2010-06-04 Eric Hyer - removed parametor for PointTypeToString()

History:: 2010-09-09 Sharmila Prasad - Added API's to get Latitude, Longitude, Radius from the Reference Measure in the Point. Also to get the min & max Line & Sample Errors

History:: 2010-09-27 Tracie Sucharski, Removed these new methods and move functionality to the ControlNetFilter class. Add the old methods, SetUniversalGround, UniversalLatitude, UniversalLongitude and Radius back in for convenience.

History:: 2010-10-05 Eric Hyer - interface to ID is now with QString

History:: 2010-10-06 Sharmila Prasad - Added method ReferenceLocked()

History:: 2010-10-18 Tracie Sucharski, Change "Setters", ComputeApriori and ComputeResiduals to return either Success or PointLocked. If the point is locked do not set values.

History:: 2010-10-18 Tracie Sucharski, Change SurfacePoint::Rectangular and SurfacePoint::Ocentric to SurfacePoint as both return values and parameters.

History:: 2010-10-06 Sharmila Prasad - API to reset Apriori

History:: 2010-10-21 Steven Lambright Minimized the header file and moved most implementations to the cpp. Reorganized the order of methods. Made more methods callable on a const instance. Added GetMeasure(...) methods and a suggested implementation for the bracket operators, not yet implemented due to returning reference conflicts. Finished implementing the new use of SurfacePoint mentioned in the last history comment. Marked SetUniversalGround(), UniversalLatitude(), UniversalLongitude(), and Radius() as deprecated. These methods need to be phased out and GetSurfacePoint() used instead. There are naming conflicts with accessors (some use Get, some don't) still. The comparison operator now relies on QVector's comparison operator instead of looping itself. Added private helper methods: int FindMeasureIndex(QString serialNumber) const void PointModified(); Updated documentation extensively. Removed everything apost except for inside of Load() and CreatePvlObject(). Added automatic updating of DateTime and ChooserName.

History:: 2010-10-26 Steven Lambright Change default chooser name from user name to application name.

History:: 2010-11-03 Mackenzie Boyd Added ToString methods for enums, String and statis ToString now exist for PointType, RadiusSource, and SurfacePointSource.

History:: 2010-11-16 Debbie Cook, Added jigsawRejected keyword.

History:: 2010-12-08 Tracie Sucharski, Added IsGround convenience method.

History:: 2010-12-28 Steven Lambright Changed accessors to match ControlMeasure's method of accessing data. Removed obsolete methods to prevent further use of them.

History:: 2011-01-13 Mackenzie Boyd Added pointer to owning ControlNet.

History:: 2011-01-17 Eric Hyer - Points now own and delete their measures. ControlNet now notified of changes (like adding and removing measures). Returning pointers to measures is now safe and encouraged.

History:: 2011-02-10 Eric Hyer - measures no longer know or care if they are the reference measure. This information is now completely maintained by this class. Made numerous API and internal changes, eliminating substantial duplicate code and increasing interface clearity. Hungarian notation now eliminated from this class.

History:: 2011-02-11 Steven Lambright - Measure log data is now written to the binary file properly.

History:: 2011-02-18 Eric Hyer - Added Delete(ControlMeasure *) method. Fixed bugs related to network notification of measure addition and deletion.

History:: 2011-02-28 Eric Hyer - Fixed bug in operator= that caused the the reference measure to not get propagated correctly

History:: 2011-02-28 Steven Lambright - Added a flag for cnetref to say whether a reference measure has been explicitly or implicitly set.

History:: 2011-03-01 Eric Hyer - Added StringToRadiusSource and StringToSurfacePointSource methods

History:: 2011-03-08 Ken Edmundson and Debbie Cook - Added members ConstraintStatus, LatitudeConstrained, LongitudeConstrained, RadiusConstrained, constraintStatus and methods ConputeResiduals_Millimeters(), HasAprioriCoordinates(), IsConstrained(), IsLatitudeConstrained(), IsLongitudeConstrained(), and NumberOfConstrainedCoordinates().

History:: 2011-03-11 Debbie Cook - changed name of member surfacePoint to adjustedSurfacePoint. Also changed methods SetSurfacePoint to SetAdjustedSurfacePoint and GetSurfacePoint to GetAdjustedSurfacePoint.

History:: 2011-03-14 Eric Hyer - Added GetMeasures method. Network now notified when a point's ignored status changes for updating its cube connection graph (cube connections were not respecting ignored flags on points / measures).

History:: 2011-03-14 Christopher Austin - Added GetBestSurfacePoint to reduce external duplicate code.

History:: 2011-03-15 Steven Lambright - Now writes AdjustedX, AdjustedY, and AdjustedZ to the pvl format. Also updated proto buffer calls to reflect naming changes.

History:: 2011-03-17 Eric Hyer - Added default parameter to GetMeasures method for excluding ignored measures.

History:: 2011-03-25 Christopher Austin - Added functionality to SetId()

History:: 2011-04-01 Debbie A. Cook and Ken Edmundson - Added argument to constructor for target radii

History:: 2011-04-04 Steven Lambright - Removed an old constructor and made the Distance vector one take a const reference.

History:: 2011-04-04 Steven Lambright - Updated constructor from binary to take planetary radii

History:: 2011-05-02 Debbie A. Cook - Added new point type Constrained

History:: 2011-06-07 Debbie A. Cook and Tracie Sucharski - Modified point types: Ground ------> Fixed Tie----------> Free

History:: 2011-06-30 Eric Hyer - Added StringToPointType() method

History:: 2011-07-01 Debbie A. Cook - Removed editLock checks from SetAdjustedSurfacePoint and ComputeResiduals

History:: 2011-07-08 Travis Addair - Locked measures can no longer be deleted

History:: 2011-07-12 Ken Edmundson - Modified ComputeApriori method to handle radius properly when computing average coordinates

History:: 2011-07-29 Jai Rideout, Steven Lambright, and Eric Hyer - Made this inherit from QObject to get destroyed() signal

History:: 2011-07-29 Eric Hyer - Changed some graph code in Delete()

History:: 2011-09-13 Eric Hyer,Tracie Sucharski - operator= changes: Change input parameter to const &. Re-wrote to use Delete and AddMeasure methods, so that the ControlGraphNode is updated correctly.

History:: 2011-09-30 Steven Lambright and Tracie Sucharski - Fixed bugs that caused unpredictable behavior in the assignment operator.

History:: 2011-10-01 Steven Lambright - Simplified the copy constructor and fixed problems (which caused ASSERT fails) in the copy constructor.

History:: 2011-10-06 Steven Lambright - Radii provided in the protocol buffer constructor can now be invalid.

History:: 2011-10-07 Steven Lambright and Stuart Sides - Fixed bug in the constructor given a protocol buffer. This caused unpredictable reference measure behaviour sometimes (rarely).

History:: 2011-10-14 Ken Edmundson Added method ClearJigsawRejected(); to set all measure and point JigsawRejected flags to false prior to bundle adjustment.

History:: 2012-03-31 Debbie A. Cook Programmer note: Revised ComputeResiduals to call ComputeResidualsMillimeters and avoid duplication of code. Also revised ComputeResidualsMillimeters to make the radar case handled the same as other instruments.

History:: 2013-11-12 Ken Edmundson Programmer note: Revised ComputeApriori such that initial coordinates are computed for "Free" points that have constrained coordinates. References #1653.

History:: 2013-11-13 Kimberly Oyama - Added missing member variables to == operator and made sure the comparisons are being done correctly. Fixes #1014.

History:: 2015-11-05 Kris Becker - invalid flag was not properly initialized in ControlPointFileEntryV0002 constructor (Merged by Kristin Berry. Fixes #2392)

Definition at line 339 of file ControlPoint.h.

Member Enumeration Documentation

enum Isis::ControlPoint::ConstraintStatus

This is a convenience member for checking number of constrained coordinates in the SurfacePoint.

Enumerator:

LatitudeConstrained

This is the status of constrained coordinates in the SurfacePoint.

Todo:: We will eventually need to deal with rectangular coordinates as well, but for now BundleAdjust uses spherical coordinates only.

Definition at line 400 of file ControlPoint.h.

enum Isis::ControlPoint::PointType

These are the valid 'types' of point.

A point type defines what a point is tying together.

Enumerator:

Fixed

A Fixed point is a Control Point whose lat/lon is well established and should not be changed.

Some people will refer to this as a truth (i.e., ground truth). A fixed point can be identifed in one or more cubes. Historically this point was called a "Ground" point.

Constrained

A Constrained point is a Control Point whose lat/lon/radius is somewhat established and should not be changed.

Free

A Free point is a Control Point that identifies common measurements between two or more cubes.

While it could have a lat/lon, it is not necessarily correct and is subject to change. This is the most common type of control point. This point type floats freely in a bundle adjustment. Historically this point type was called "Tie".

Definition at line 349 of file ControlPoint.h.

enum Isis::ControlPoint::Status

This is a return status for many of the mutating (setter) method calls.

We chose to use return status' because often times ignoring them is the behavior the caller wants.

Enumerator:

Failure

This is returned when an operation cannot be performed due to a problem such as the point is ignored and the operation doesn't make sense.

Success

This is returned when the operation successfully took effect.

PointLocked

This is returned when the operation requires Edit Lock to be false but it is currently true.

The operation did not take effect.

Definition at line 378 of file ControlPoint.h.

Constructor & Destructor Documentation

Isis::ControlPoint::ControlPoint ( )

Construct a control point.

Author: tsucharski (5/5/2010)

Definition at line 43 of file ControlPoint.cpp.

References aprioriRadiusSource, aprioriSurfacePointSource, constraintStatus, dateTime, editLock, Free, ignore, jigsawRejected, numberOfRejectedMeasures, parentNetwork, referenceExplicitlySet, and type.

Isis::ControlPoint::ControlPoint ( const ControlPoint & other )

Copy the given control point into this instance.

Parameters

other The control point to duplicate

Definition at line 70 of file ControlPoint.cpp.

References AddMeasure(), adjustedSurfacePoint, aprioriRadiusSource, aprioriRadiusSourceFile, aprioriSurfacePoint, aprioriSurfacePointSource, aprioriSurfacePointSourceFile, chooserName, constraintStatus, dateTime, editLock, GetMeasure(), id, ignore, invalid, jigsawRejected, numberOfRejectedMeasures, parentNetwork, referenceExplicitlySet, SetRefMeasure(), and type.

Isis::ControlPoint::ControlPoint ( const QString & newId )

Construct a control point with given Id.

Parameters

id	Control Point Id

Definition at line 322 of file ControlPoint.cpp.

References aprioriRadiusSource, aprioriSurfacePointSource, constraintStatus, editLock, Free, ignore, jigsawRejected, numberOfRejectedMeasures, parentNetwork, referenceExplicitlySet, and type.

Isis::ControlPoint::ControlPoint	(	const ControlPointFileEntryV0002 &	fileEntry,
		const Distance &	majorRad,
		const Distance &	minorRad,
		const Distance &	polarRad
	)

This is used when reading from a protocol buffer.

Given a file representation (protocol buffer), and log data, construct the control point.

History:: 2008-06-18 Debbie A. Cook, Swapped Init with SetRadii calls to avoid resetting the surface points with no radii

History:: 2015-11-03 Kris Becker - invalid flag was not being initialized

Definition at line 122 of file ControlPoint.cpp.

References _FILEINFO_, AddMeasure(), adjustedSurfacePoint, aprioriRadiusSource, aprioriRadiusSourceFile, aprioriSurfacePoint, aprioriSurfacePointSource, aprioriSurfacePointSourceFile, chooserName, Constrained, constraintStatus, dateTime, editLock, Fixed, Free, ignore, Isis::Distance::isValid(), jigsawRejected, LatitudeConstrained, Isis::Displacement::Meters, numberOfRejectedMeasures, parentNetwork, Isis::IException::Programmer, referenceExplicitlySet, Isis::SurfacePoint::SetRadii(), Isis::SurfacePoint::SetRectangularMatrix(), SetRefMeasure(), and type.

Isis::ControlPoint::~ControlPoint ( )

This destroys the current instance and cleans up any and all allocated memory.

Definition at line 345 of file ControlPoint.cpp.

Member Function Documentation

void Isis::ControlPoint::Add ( ControlMeasure * measure )

Add a measurement to the control point, taking ownership of the measure in the process.

Parameters

measure The ControlMeasure to add

Definition at line 421 of file ControlPoint.cpp.

References AddMeasure().

Referenced by Isis::QnetTool::createFixedPoint(), Isis::StereoTool::createPoint(), Isis::MatchTool::createPoint(), and Isis::QnetTool::createPoint().

void Isis::ControlPoint::AddMeasure ( ControlMeasure * measure )

private

Do the actual work of adding a measure to this point, without changing any extra data.

Definition at line 431 of file ControlPoint.cpp.

References _FILEINFO_, Isis::ControlMeasure::GetCubeSerialNumber(), GetId(), IsReferenceExplicit(), Isis::ControlNet::measureAdded(), parentNetwork, Isis::ControlMeasure::parentPoint, and Isis::IException::Programmer.

Referenced by Add(), ControlPoint(), and operator=().

void Isis::ControlPoint::ClearJigsawRejected ( )

Set jigsaw rejected flag for all measures to false and set the jigsaw rejected flag for the point itself to false.

Definition at line 2190 of file ControlPoint.cpp.

References GetMeasure(), Isis::ControlMeasure::SetRejected(), and SetRejected().

Referenced by Isis::ControlNet::ClearJigsawRejected().

ControlPoint::Status Isis::ControlPoint::ComputeApriori ( )

This method computes the apriori lat/lon for a point.

It computes this by determining the average lat/lon of all the measures. Note that this does not change ignored, or fixed points. Also, it does not use unmeasured or ignored measures when computing the lat/lon.

History:: 2008-06-18 Tracie Sucharski/Jeannie Walldren, Changed error messages for Held/Ground points.

History:: 2009-10-13 Jeannie Walldren - Added detail to error message.

History:: 2010-11-29 Tracie Sucharski - Remove call to ControlMeasure:: SetMeasuredEphemerisTime, the values were never used. so these methods were removed from ControlMeasure and the call was removed here.

History:: 2010-12-02 Debbie A. Cook - Added units to SetRectangular calls since default is meters and units are km.

History:: 2011-03-17 Debbie A. Cook - Added initialization of adjustedSurfacePoint to aprioriSurfacePoint and set test for empty covariance matrix to use 0. instead of nulls.

History:: 2011-03-24 Debbie A. Cook - Removed IsMeasured check since it was really checking for Candidate measures.

History:: 2011-07-12 Debbie A. Cook - Removed editLock test. Users agreed editLock was only for fixed and constrained points, which are already left unchanged by ComputeApriori. If a free point is editLocked the editLock will be ignored by this method.

Returns: Status Success or PointLocked

Definition at line 1018 of file ControlPoint.cpp.

References _FILEINFO_, adjustedSurfacePoint, aprioriSurfacePoint, Isis::Sensor::Coordinate(), Isis::Camera::DistortionMap(), Fixed, Free, GetId(), GetMeasure(), GetType(), Isis::Displacement::Kilometers, Isis::IException::Programmer, SetAprioriRadiusSource(), SetAprioriSurfacePointSource(), Isis::ControlMeasure::SetFocalPlaneMeasured(), Isis::Camera::SetImage(), Isis::SurfacePoint::SetRectangular(), Success, Isis::CameraDistortionMap::UndistortedFocalPlaneX(), Isis::CameraDistortionMap::UndistortedFocalPlaneY(), and Isis::IException::User.

Referenced by Isis::ControlNet::ComputeApriori(), and Isis::QnetSetAprioriDialog::setApriori().

ControlPoint::Status Isis::ControlPoint::ComputeResiduals ( )

This method computes the BundleAdjust residuals for a point.

*** Warning:  Only BundleAdjust and its applications should be
              using this method.

History:: 2008-07-17 Tracie Sucharski, Added ptid and measure serial number to the unable to map to surface error.

History:: 2009-12-06 Tracie Sucharski, Renamed from ComputeErrors

History:: 2010-08-05 Tracie Sucharski, Changed lat/lon/radius to x/y/z

History:: 2010-12-10 Debbie A. Cook, Revised error calculation for radar because it was always reporting line errors=0.

History:: 2011-03-17 Debbie A. Cook, Fixed typo in radar call to get longitude

History:: 2011-03-24 Debbie A. Cook, Removed IsMeasured check since it was really checking for Candidate measures.

History:: 2011-07-01 Debbie A. Cook, Removed editLock check to allow BundleAdjust to compute residuals for editLocked points

History:: 2012-01-18 Debbie A. Cook, Revised to call ComputeResidualsMillimeters() to avoid duplication of code

Definition at line 1172 of file ControlPoint.cpp.

References _FILEINFO_, ComputeResiduals_Millimeters(), Isis::CameraFocalPlaneMap::DetectorLine(), Isis::CameraFocalPlaneMap::DetectorSample(), Isis::Camera::DistortionMap(), Failure, Isis::Camera::FocalPlaneMap(), Isis::CameraDistortionMap::FocalPlaneX(), Isis::CameraDistortionMap::FocalPlaneY(), Isis::Camera::GetCameraType(), Isis::ControlMeasure::GetCubeSerialNumber(), GetId(), Isis::Sensor::GetSurfacePoint(), Isis::CameraGroundMap::GetXY(), Isis::Camera::GroundMap(), Isis::IException::Programmer, Isis::Camera::Radar, Isis::CameraFocalPlaneMap::SetFocalPlane(), Isis::Camera::SetImage(), Isis::ControlMeasure::SetResidual(), Isis::CameraDistortionMap::SetUndistortedFocalPlane(), and Success.

Referenced by Isis::BundleAdjust::ComputeResiduals(), and Isis::BundleAdjust::WrapUp().

ControlPoint::Status Isis::ControlPoint::ComputeResiduals_Millimeters ( )

This method computes the residuals for a point.

History:: 2008-07-17 Tracie Sucharski - Added ptid and measure serial number to the unable to map to surface error.

History:: 2010-12-06 Tracie Sucharski - Renamed from ComputeErrors

History:: 2011-03-19 Debbie A. Cook - Changed to use the Camera classes like ComputeResiduals and get the correct calculations for each camera type.

History:: 2011-03-24 Debbie A. Cook - Removed IsMeasured check since it was really checking for Candidate measures.

History:: 2012-01-18 Debbie A. Cook - Made radar case the same as other instruments and removed incorrect call to SetResidual, which was setting focal plane residuals in x and y instead of image residuals in sample and line.

Definition at line 1324 of file ControlPoint.cpp.

References Failure, Isis::Camera::GetCameraType(), Isis::CameraGroundMap::GetXY(), Isis::Camera::GroundMap(), Isis::ControlMeasure::SetFocalPlaneComputed(), Isis::Camera::SetImage(), and Success.

Referenced by ComputeResiduals().

int Isis::ControlPoint::Delete ( ControlMeasure * measure )

Remove a measurement from the control point, deleting reference measure is allowed.

Parameters

measure The measure to delete

Definition at line 534 of file ControlPoint.cpp.

References Isis::ControlMeasure::GetCubeSerialNumber().

Referenced by Delete(), Isis::ControlNet::DeleteMeasuresWithId(), Isis::MatchTool::deletePoint(), operator=(), and Isis::QnetTool::savePoint().

int Isis::ControlPoint::Delete ( QString serialNumber )

Remove a measurement from the control point, deleting reference measure is allowed.

Parameters

serialNumber The serial number of the measure to delete

Definition at line 489 of file ControlPoint.cpp.

References Isis::ControlMeasure::IsEditLocked(), Isis::ControlNet::measureDeleted(), parentNetwork, referenceExplicitlySet, Success, and ValidateMeasure().

int Isis::ControlPoint::Delete ( int index )

Remove a measurement from the control point, deleting reference measure is allowed.

Parameters

index The index of the control measure to delete

Definition at line 546 of file ControlPoint.cpp.

References _FILEINFO_, Delete(), and Isis::IException::Programmer.

SurfacePoint Isis::ControlPoint::GetBestSurfacePoint ( ) const

Returns the adjusted surface point if it exists, otherwise returns the a priori surface point.

Definition at line 1408 of file ControlPoint.cpp.

References adjustedSurfacePoint, and aprioriSurfacePoint.

Referenced by Isis::QnetPointRangeFilter::filter(), and Isis::QnetPointDistanceFilter::filter().

QList< QString > Isis::ControlPoint::getCubeSerialNumbers ( ) const

Returns: A list of cube serial numbers

Definition at line 1908 of file ControlPoint.cpp.

Referenced by Isis::ControlNet::SetImages().

QString Isis::ControlPoint::GetId ( ) const

Return the Id of the control point.

Returns: Control Point Id

Definition at line 1421 of file ControlPoint.cpp.

References id.

double Isis::ControlPoint::GetLineResidualRms ( ) const

Get rms of line residuals.

Returns: The rms of line residuals

Definition at line 2136 of file ControlPoint.cpp.

References Isis::Statistics::AddData(), GetMeasure(), and Isis::Statistics::Rms().

const ControlMeasure * Isis::ControlPoint::GetMeasure ( QString serialNumber ) const

Get a control measure based on its cube's serial number.

Parameters

serialNumber serial number of measure to get

Returns: const control measure with matching serial number

Definition at line 595 of file ControlPoint.cpp.

References ValidateMeasure().

ControlMeasure * Isis::ControlPoint::GetMeasure ( QString serialNumber )

Get a control measure based on its cube's serial number.

Parameters

serialNumber serial number of measure to get

Returns: control measure with matching serial number

Definition at line 583 of file ControlPoint.cpp.

References ValidateMeasure().

QList< ControlMeasure * > Isis::ControlPoint::getMeasures ( bool excludeIgnored = false ) const

Parameters

excludeIgnored Ignored measures are excluded if this is true. It is false by default.

Returns: A list of this points measures

Definition at line 1893 of file ControlPoint.cpp.

Referenced by Isis::ControlNet::AddPoint(), and Isis::ControlNet::DeletePoint().

int Isis::ControlPoint::GetNumberOfRejectedMeasures ( ) const

Get the number of rejected measures on the control point.

Returns: The number of rejected measures on this control point

Definition at line 2098 of file ControlPoint.cpp.

References numberOfRejectedMeasures.

Referenced by Isis::BundleAdjust::OutputNoErrorPropagation(), Isis::BundleAdjust::OutputPointsCSV(), and Isis::BundleAdjust::OutputWithErrorPropagation().

int Isis::ControlPoint::GetNumLockedMeasures ( ) const

Returns the number of locked control measures.

Returns: Number of locked control measures

Definition at line 1751 of file ControlPoint.cpp.

Referenced by Isis::InterestOperator::FindCnetRef(), Isis::ControlNetStatistics::GeneratePointStats(), Isis::ControlNet::GetNumEditLockMeasures(), Isis::ControlNetFilter::PointCubeNamesFilter(), Isis::ControlNetFilter::PointEditLockFilter(), Isis::ControlNetFilter::PointGoodnessOfFitFilter(), Isis::ControlNetFilter::PointNumMeasuresEditLockFilter(), and Isis::ControlNetFilter::PointStats().

int Isis::ControlPoint::GetNumValidMeasures ( ) const

Returns: Number of valid control measures

Definition at line 1735 of file ControlPoint.cpp.

Referenced by Isis::ControlNetStatistics::GeneratePointStats(), Isis::ControlNet::GetNumIgnoredMeasures(), Isis::ControlNet::GetNumValidMeasures(), Isis::ControlNetFilter::PointCubeNamesFilter(), Isis::ControlNetFilter::PointEditLockFilter(), Isis::ControlNetFilter::PointGoodnessOfFitFilter(), and Isis::ControlNetFilter::PointStats().

QString Isis::ControlPoint::GetPointTypeString ( ) const

Obtain a string representation of the PointType.

Returns: A string representation of the PointType

Definition at line 1503 of file ControlPoint.cpp.

References GetType(), and PointTypeToString().

QString Isis::ControlPoint::GetRadiusSourceString ( ) const

Obtain a string representation of the RadiusSource.

Returns: A string representation of the RadiusSource

Definition at line 1586 of file ControlPoint.cpp.

References aprioriRadiusSource, and RadiusSourceToString().

QString Isis::ControlPoint::GetReferenceSN ( ) const

Returns: The cube serial number of the reference measure

Definition at line 1785 of file ControlPoint.cpp.

References _FILEINFO_, Isis::ControlMeasure::GetCubeSerialNumber(), GetId(), and Isis::IException::Programmer.

Referenced by Isis::MatchTool::IsMeasureLocked(), Isis::MatchTool::loadMeasureTable(), Isis::MatchTool::loadPoint(), Isis::MatchTool::updateLeftMeasureInfo(), and Isis::MatchTool::updateRightMeasureInfo().

const ControlMeasure * Isis::ControlPoint::GetRefMeasure ( ) const

Get the reference control measure.

Returns: const reference measure for this point

Definition at line 626 of file ControlPoint.cpp.

References _FILEINFO_, GetId(), and Isis::IException::Programmer.

ControlMeasure * Isis::ControlPoint::GetRefMeasure ( )

Get the measure that is the reference directly.

Definition at line 639 of file ControlPoint.cpp.

References _FILEINFO_, GetId(), and Isis::IException::Programmer.

double Isis::ControlPoint::GetResidualRms ( ) const

Get rms of residuals.

Returns: The rms of residuals

Definition at line 2164 of file ControlPoint.cpp.

References Isis::Statistics::AddData(), GetMeasure(), and Isis::Statistics::Rms().

Referenced by Isis::BundleAdjust::OutputNoErrorPropagation(), Isis::BundleAdjust::OutputPointsCSV(), and Isis::BundleAdjust::OutputWithErrorPropagation().

double Isis::ControlPoint::GetSampleResidualRms ( ) const

Get rms of sample residuals.

Returns: The rms of sample residuals

Definition at line 2108 of file ControlPoint.cpp.

References Isis::Statistics::AddData(), GetMeasure(), and Isis::Statistics::Rms().

Statistics Isis::ControlPoint::GetStatistic ( double(ControlMeasure::*)() const statFunc ) const

This function will call a given method on every control measure that this point has.

Parameters

statFunc The function to use for data collection

Returns: The gathered statistic

History:: 2011-03-08 Debbie A. Cook - Changed to get statistics for all point types and not just Candidate.

Definition at line 1864 of file ControlPoint.cpp.

References Isis::Statistics::AddData().

Referenced by Isis::ControlNet::AverageResidual(), Isis::QnetPointJigsawErrorFilter::filter(), Isis::QnetPointRegistrationErrorFilter::filter(), Isis::ControlNet::GetMaximumResidual(), and Isis::ControlNetStatistics::GetPointDoubleStats().

QString Isis::ControlPoint::GetSurfacePointSourceString ( ) const

Obtain a string representation of the SurfacePointSource.

Returns: A string representation of the SurfacePointSource

Definition at line 1662 of file ControlPoint.cpp.

References aprioriSurfacePointSource, and SurfacePointSourceToString().

ControlPoint::PointType Isis::ControlPoint::GetType ( ) const

Returns: this point't type

Definition at line 1512 of file ControlPoint.cpp.

References type.

Referenced by Isis::BundleAdjust::AddPartials(), ComputeApriori(), Isis::ControlPointGraphicsItem::ControlPointGraphicsItem(), Isis::ControlNetFilter::CubeDistanceFilter(), Isis::QnetTool::drawAllMeasurments(), Isis::QnetTool::drawGroundMeasures(), Isis::BundleAdjust::FillPointIndexMap(), Isis::QnetPointTypeFilter::filter(), Isis::InterestOperator::FindCnetRef(), Isis::ControlNetStatistics::GenerateImageStats(), Isis::ControlNetStatistics::GeneratePointStats(), GetPointTypeString(), Isis::BundleAdjust::InitializePointWeights(), Isis::BundleAdjust::OutputNoErrorPropagation(), Isis::BundleAdjust::OutputPointsCSV(), Isis::BundleAdjust::OutputWithErrorPropagation(), Isis::ChipViewport::paintEvent(), Isis::StereoTool::paintViewport(), Isis::ControlNetFilter::PointCubeNamesFilter(), Isis::ControlNetFilter::PointEditLockFilter(), Isis::ControlNetFilter::PointGoodnessOfFitFilter(), Isis::ControlNetFilter::PointPixelShiftFilter(), Isis::ControlNetFilter::PointPropertiesFilter(), Isis::ControlNetFilter::PointResMagnitudeFilter(), Isis::ControlNetFilter::PointStats(), Isis::QnetTool::savePoint(), Isis::BundleAdjust::SetParameterWeights(), and Isis::BundleAdjust::Update().

bool Isis::ControlPoint::HasSerialNumber ( QString serialNumber ) const

Return true if given serial number exists in point.

Parameters

serialNumber The serial number

Returns: True if point contains serial number, false if not

Definition at line 1768 of file ControlPoint.cpp.

Referenced by Isis::MatchTool::drawAllMeasurments(), Isis::StereoTool::paintViewport(), Isis::QnetTool::savePoint(), and Isis::QnetNewMeasureDialog::setFiles().

int Isis::ControlPoint::IndexOf	(	ControlMeasure *	cm,
		bool	throws = `true`
	)		const

Parameters

cm	The control measure to find the index of
throws	Throws an exception on failure instead of returning -1. Be aware that by default this is true!

Returns: The index of the passed in measure, or -1 on failure if throws is false.

Definition at line 1804 of file ControlPoint.cpp.

References Isis::ControlMeasure::GetCubeSerialNumber().

int Isis::ControlPoint::IndexOf	(	QString	sn,
		bool	throws = `true`
	)		const

Parameters

sn	The serial number of the control measure to find the index of
throws	Throws an exception on failure instead of returning -1. Be aware that by default this is true!

Returns: The index of the measure with serial number matching sn, or -1 on failure if throws is false.

Definition at line 1818 of file ControlPoint.cpp.

References _FILEINFO_, and Isis::IException::Programmer.

int Isis::ControlPoint::IndexOfRefMeasure ( ) const

Parameters

throws Throws an exception on failure instead of returning -1. Be aware that by default this is true!

Returns: The index of the reference measure, or -1 if no measures exist in the point (A point with at least one measure ALWAYS has a reference measure.

Definition at line 1839 of file ControlPoint.cpp.

References _FILEINFO_, Isis::ControlMeasure::GetCubeSerialNumber(), and Isis::IException::Programmer.

Referenced by Isis::InterestOperator::FindCnetRef(), and Isis::MatchTool::loadPoint().

bool Isis::ControlPoint::IsReferenceExplicit ( ) const

Returns: true Returns true if SetRefMeasure has ever been set on this point.

Definition at line 1777 of file ControlPoint.cpp.

References referenceExplicitlySet.

Referenced by AddMeasure(), Isis::MatchTool::deletePoint(), Isis::MatchTool::IsMeasureLocked(), Isis::MatchTool::loadMeasureTable(), Isis::MatchTool::loadPoint(), Isis::MatchTool::updateLeftMeasureInfo(), and Isis::MatchTool::updateRightMeasureInfo().

void Isis::ControlPoint::Load ( PvlObject & p )

Loads the PvlObject into a ControlPoint.

Parameters

p	PvlObject containing ControlPoint information
forceBuild	Allows invalid Control Measures to be added to this Control Point

Exceptions

Isis::iException::User	- Invalid Point Type
Isis::iException::User	- Unable to add ControlMeasure to Control Point

History:: 2008-06-18 Tracie Sucharski/Jeannie Walldren, Fixed bug with checking for "True" vs "true", change to lower case for comparison.

History:: 2009-12-29 Tracie Sucharski - Added new ControlPoint information.

History:: 2010-01-13 Tracie Sucharski - Changed from Set methods to simply setting private variables to increase speed?

History:: 2010-07-30 Tracie Sucharski, Updated for changes made after additional working sessions for Control network design.

History:: 2010-09-01 Tracie Sucharski, Add checks for AprioriLatLonSource AprioriLatLonSourceFile. If there are AprioriSigmas,but no AprioriXYZ, use the XYZ values.

History:: 2010-09-15 Tracie Sucharski, It was decided after mtg with Debbie, Stuart, Ken and Tracie that ControlPoint will only function with x/y/z, not lat/lon/radius. It will be the responsibility of the application or class using ControlPoint to set up a SurfacePoint object to do conversions between x/y/z and lat/lon/radius. So... remove all conversion methods from this class. It was also decided that when importing old networks that contain Sigmas, the sigmas will not be imported , due to conflicts with the units of the sigmas,we cannot get accurate x,y,z sigams from the lat,lon,radius sigmas without the covariance matrix.

History:: 2010-09-28 Tracie Sucharski, Added back the conversion methods from lat,lon,radius to x,y,z only for the point, since that is what most applications need.

History:: 2010-12-02 Debbie A. Cook, Added units to SurfacePoint.SetSpherical calls.

History:: 2011-03-12 Debbie A. Cook, Added targetRadius to do conversions

Definition at line 410 of file ControlPoint.cpp.

bool Isis::ControlPoint::operator!= ( const ControlPoint & other ) const

Compare two Control Points for inequality.

Parameters

other The other point to compare this one to

Returns: true if the two points are not equal, and false otherwise

Definition at line 1970 of file ControlPoint.cpp.

const ControlPoint & Isis::ControlPoint::operator= ( const ControlPoint & other )

Parameters

pPoint

Returns: ControlPoint&

History:: 2011-09-13 Eric Hyer,Tracie Sucharski - Changed input parameter to const &. Re-wrote using Delete and AddMeasure methods, so that the ControlGraphNode is updated correctly.

History:: 2011-09-30 Tracie Sucharski - Fixed some memory leaks and deleted some calls that were already handled in AddMeasure.

History:: 2011-10-03 Tracie Sucharski - Unlock measures before Deleting

Definition at line 2024 of file ControlPoint.cpp.

References AddMeasure(), adjustedSurfacePoint, aprioriRadiusSource, aprioriRadiusSourceFile, aprioriSurfacePoint, aprioriSurfacePointSource, aprioriSurfacePointSourceFile, chooserName, constraintStatus, dateTime, Delete(), editLock, id, ignore, invalid, jigsawRejected, numberOfRejectedMeasures, referenceExplicitlySet, SetRefMeasure(), and type.

bool Isis::ControlPoint::operator== ( const ControlPoint & other ) const

Compare two Control Points for equality.

Parameters

other The other point to compare to

Returns: true if the two points are equal, and false otherwise

Definition at line 1983 of file ControlPoint.cpp.

References adjustedSurfacePoint, aprioriRadiusSource, aprioriRadiusSourceFile, aprioriSurfacePoint, aprioriSurfacePointSource, aprioriSurfacePointSourceFile, chooserName, constraintStatus, dateTime, editLock, id, ignore, invalid, jigsawRejected, numberOfRejectedMeasures, referenceExplicitlySet, and type.

const ControlMeasure * Isis::ControlPoint::operator[] ( QString serialNumber ) const

Same as GetMeasure (provided for convenience)

Parameters

serialNumber Cube serial number of desired control measure

Returns: const version of the measure which has the provided serial number

Definition at line 1920 of file ControlPoint.cpp.

References GetMeasure().

ControlMeasure * Isis::ControlPoint::operator[] ( QString serialNumber )

Same as GetMeasure (provided for convenience)

Parameters

serialNumber Cube serial number of desired control measure

Returns: The measure which has the provided serial number

Definition at line 1932 of file ControlPoint.cpp.

References GetMeasure().

const ControlMeasure * Isis::ControlPoint::operator[] ( int index ) const

Same as GetMeasure (provided for convenience)

Parameters

index If there are n measures, the measure returned will be the ith measure added to the point

Returns: const version of the measure which has the provided serial number

Definition at line 1945 of file ControlPoint.cpp.

References GetMeasure().

ControlMeasure * Isis::ControlPoint::operator[] ( int index )

Same as GetMeasure (provided for convenience)

Parameters

index If there are n measures, the measure returned will be the ith measure added to the point

Returns: The measure which has the provided serial number

Definition at line 1958 of file ControlPoint.cpp.

References GetMeasure().

QString Isis::ControlPoint::PointTypeToString ( PointType pointType )

static

Obtain a string representation of a given PointType.

Parameters

type	PointType to convert to a string

Returns: A string representation of type

Definition at line 1448 of file ControlPoint.cpp.

References Constrained, Fixed, and Free.

Referenced by Isis::QnetTool::createControlPointGroupBox(), and GetPointTypeString().

QString Isis::ControlPoint::RadiusSourceToString ( RadiusSource::Source source )

static

Obtain a string representation of a given RadiusSource.

Parameters

source RadiusSource to convert to string

Returns: A string representation of RadiusSource

Definition at line 1524 of file ControlPoint.cpp.

Referenced by GetRadiusSourceString().

ControlPoint::Status Isis::ControlPoint::ResetApriori ( )

Reset all the Apriori info to defaults.

Author: Sharmila Prasad (10/22/2010)

Definition at line 561 of file ControlPoint.cpp.

References aprioriRadiusSource, aprioriRadiusSourceFile, aprioriSurfacePoint, aprioriSurfacePointSource, aprioriSurfacePointSourceFile, constraintStatus, PointLocked, and Success.

ControlPoint::Status Isis::ControlPoint::SetAdjustedSurfacePoint ( SurfacePoint newSurfacePoint )

Set or update the surface point relating to this control point.

This is the point on the surface of the planet that the measures are tied to. This updates the last modified attributes of this point. *** Warning: Only BundleAdjust and its applications should be using this method.

Parameters

newSurfacePoint The point on the target's surface the measures are tied to

History:: 2011-07-01 Debbie A. Cook Removed editLock check

Definition at line 852 of file ControlPoint.cpp.

References adjustedSurfacePoint, and Success.

Referenced by Isis::BundleAdjust::applyParameterCorrections_CHOLMOD(), Isis::BundleAdjust::applyParameterCorrections_SPECIALK(), Isis::BundleAdjust::errorPropagation_CHOLMOD(), Isis::BundleAdjust::errorPropagation_SPECIALK(), Isis::BundleAdjust::formNormals2_CHOLMOD(), Isis::BundleAdjust::formNormals2_SPECIALK(), Isis::BundleAdjust::InitializePoints(), Isis::BundleAdjust::SetPostBundleSigmas(), and Isis::BundleAdjust::Update().

ControlPoint::Status Isis::ControlPoint::SetAprioriRadiusSource ( RadiusSource::Source source )

This updates the source of the radius of the apriori surface point.

See Also: RadiusSource::Source

Parameters

source Where the radius came from

Definition at line 890 of file ControlPoint.cpp.

References aprioriRadiusSource, editLock, PointLocked, and Success.

Referenced by ComputeApriori(), and Isis::QnetSetAprioriDialog::setApriori().

ControlPoint::Status Isis::ControlPoint::SetAprioriRadiusSourceFile ( QString sourceFile )

This updates the filename of the DEM that the apriori radius came from.

It doesn't really make sense to call this unless the RadiusSource is DEM.

See Also: RadiusSource::Source

Parameters

source Where the radius came from

Definition at line 908 of file ControlPoint.cpp.

References aprioriRadiusSourceFile, editLock, PointLocked, and Success.

ControlPoint::Status Isis::ControlPoint::SetAprioriSurfacePoint ( SurfacePoint aprioriSP )

This updates the apriori surface point.

See Also: SetAprioriRadiusSource; SetAprioriRadiusSourceFile; SetAprioriPointSource; SetAprioriPointSourceFile; aprioriSurfacePoint

Parameters

aprioriSP The apriori surface point to remember

Todo:: This method needs to be revisited. It will set the constraint status based on the sigmas and override the existing status.

Definition at line 931 of file ControlPoint.cpp.

References aprioriSurfacePoint, constraintStatus, editLock, Isis::ControlNet::GetTargetRadii(), Isis::Angle::isValid(), Isis::Distance::isValid(), LatitudeConstrained, parentNetwork, PointLocked, Isis::SurfacePoint::SetRadii(), and Success.

Referenced by Isis::QnetTool::createFixedPoint(), Isis::StereoTool::createPoint(), Isis::StereoTool::measureSaved(), and Isis::QnetSetAprioriDialog::setApriori().

ControlPoint::Status Isis::ControlPoint::SetAprioriSurfacePointSource ( SurfacePointSource::Source source )

This updates the source of the surface point.

See Also: SurfacePointSource::Source

Parameters

source Where the surface point came from

Definition at line 958 of file ControlPoint.cpp.

References aprioriSurfacePointSource, editLock, PointLocked, and Success.

Referenced by ComputeApriori(), and Isis::QnetSetAprioriDialog::setApriori().

ControlPoint::Status Isis::ControlPoint::SetAprioriSurfacePointSourceFile ( QString sourceFile )

This updates the filename of where the apriori surface point came from.

See Also: RadiusSource::Source

Parameters

sourceFile Where the surface point came from

Definition at line 975 of file ControlPoint.cpp.

References aprioriSurfacePointSourceFile, editLock, PointLocked, and Success.

ControlPoint::Status Isis::ControlPoint::SetChooserName ( QString name )

Set the point's chooser name.

This will be lost if any attributes relating to this point is later changed and the current user will be set. This is one of the 'last modified attributes' referred to in other comments.

Parameters

name	The username of the person who last modified this control point

Definition at line 656 of file ControlPoint.cpp.

References chooserName, editLock, PointLocked, and Success.

Referenced by Isis::QnetTool::createFixedPoint(), Isis::MatchTool::createPoint(), and Isis::QnetTool::createPoint().

ControlPoint::Status Isis::ControlPoint::SetDateTime ( QString newDateTime )

Set the point's last modified time.

This will be lost if any attributes relating to this point are later changed and the current time will be set. This is one of the 'last modified attributes' referred to in other comments.

Parameters

newDateTime The date and time this control point was last modified

Definition at line 672 of file ControlPoint.cpp.

References dateTime, editLock, PointLocked, and Success.

ControlPoint::Status Isis::ControlPoint::SetEditLock ( bool lock )

Set the EditLock state.

If edit lock is on, then most attributes relating to this point are not modifiable. Edit lock is like "Don't modify my attributes, but you can still modify my measures' attributes". The reference measure is implicitely edit locked if the point is edit locked.

Parameters

lock	True to enable edit lock, false to disable it and allow the point to be modified.

Definition at line 689 of file ControlPoint.cpp.

References editLock, and Success.

Referenced by Isis::ControlNetFilter::FilterOutMeasuresBySerialNum(), Isis::ControlNetFilter::FilterOutPoint(), Isis::MatchTool::setLockPoint(), and Isis::MatchTool::updatePointInfo().

void Isis::ControlPoint::SetExplicitReference ( ControlMeasure * measure )

private

Explicitly defines a new reference measure by pointer.

This assumes the point already has ownership over this pointer. As part of the explicit definition process, the reference will attempt to be made ignored if the measure will allow it.

In the past, setting an explicit reference would also attempt to set the new reference to un-ignored (this would only fail if the measure was "Edit Locked"). This blanket rule was removed, however, because the bundle adjustment processing phase could often intentionally set references to ignored, and in some instances (e.g., merging a partial network back into the base network) this rule would mistakenly set those properly ignored references back to un-ignored. While this rule made sense for the registration phase of processing, it clearly caused problems during bundle adjustment and merging.

Parameters

measure The new reference measure

Definition at line 800 of file ControlPoint.cpp.

References referenceExplicitlySet.

Referenced by SetRefMeasure().

ControlPoint::Status Isis::ControlPoint::SetId ( QString newId )

Sets the Id of the control point.

Parameters

id	Control Point Id

Returns: (int) status Success or PointLocked

Definition at line 716 of file ControlPoint.cpp.

References editLock, id, parentNetwork, PointLocked, Success, and Isis::ControlNet::UpdatePointReference().

ControlPoint::Status Isis::ControlPoint::SetIgnored ( bool newIgnoreStatus )

Set whether to ignore or use control point.

Parameters

newIgnoreStatus True to ignore this Control Point, False to un-ignore

Definition at line 812 of file ControlPoint.cpp.

References editLock, ignore, Isis::ControlNet::measureUnIgnored(), parentNetwork, PointLocked, and Success.

Referenced by Isis::InterestOperator::FindCnetRef(), Isis::MatchTool::measureSaved(), Isis::InterestOperator::ProcessLocked_Point_Reference(), Isis::MatchTool::setIgnorePoint(), and Isis::MatchTool::updatePointInfo().

void Isis::ControlPoint::SetNumberOfRejectedMeasures ( int numRejected )

Set (update) the number of rejected measures for the control point.

Parameters

numRejected The number of rejected measures

Definition at line 2087 of file ControlPoint.cpp.

References numberOfRejectedMeasures.

Referenced by Isis::BundleAdjust::FlagOutliers().

ControlPoint::Status Isis::ControlPoint::SetRefMeasure ( ControlMeasure * cm )

Set the point's reference measure.

Parameters

cm	The new reference measure

Definition at line 732 of file ControlPoint.cpp.

References editLock, PointLocked, SetExplicitReference(), and Success.

Referenced by ControlPoint(), Isis::InterestOperator::FindCnetRef(), and operator=().

ControlPoint::Status Isis::ControlPoint::SetRefMeasure ( int index )

Set the point's reference measure.

Parameters

index The index of the new reference measure

Definition at line 747 of file ControlPoint.cpp.

References _FILEINFO_, editLock, PointLocked, Isis::IException::Programmer, SetExplicitReference(), Success, and Isis::toString().

ControlPoint::Status Isis::ControlPoint::SetRefMeasure ( QString sn )

Set the points reference measure.

Parameters

sn	The serial number of the new reference measure

Definition at line 767 of file ControlPoint.cpp.

References _FILEINFO_, editLock, PointLocked, Isis::IException::Programmer, SetExplicitReference(), and Success.

ControlPoint::Status Isis::ControlPoint::SetRejected ( bool reject )

Set the jigsawRejected state.

If IsRejected is true, then this point should be ignored until the next iteration in the bundle adjustement. BundleAdjust decides when to reject or accept a point. The initial IsRejected state of a measure is false.

Parameters

reject True to reject a measure, false to include it in the adjustment

Definition at line 703 of file ControlPoint.cpp.

References jigsawRejected, and Success.

Referenced by ClearJigsawRejected(), and Isis::BundleAdjust::FlagOutliers().

ControlPoint::Status Isis::ControlPoint::SetType ( PointType newType )

Updates the control point's type.

This updates the last modified attributes of this point.

See Also: PointType

Parameters

newType The new type this control point should be

Definition at line 868 of file ControlPoint.cpp.

References _FILEINFO_, Constrained, editLock, Fixed, Free, GetId(), PointLocked, Isis::IException::Programmer, Success, and type.

Referenced by Isis::QnetTool::createFixedPoint(), Isis::StereoTool::createPoint(), and Isis::MatchTool::createPoint().

ControlPoint::PointType Isis::ControlPoint::StringToPointType ( QString pointTypeString )

static

Obtain a PointType given a string representation of it.

Parameters

pointTypeString for the requested PointType

Returns: the PointType for the given string

Definition at line 1474 of file ControlPoint.cpp.

References _FILEINFO_, Constrained, Fixed, Free, Isis::IException::Programmer, and type.

ControlPoint::RadiusSource::Source Isis::ControlPoint::StringToRadiusSource ( QString str )

static

Obtain a RadiusSource::Source from a string.

Parameters

str	string to get a RadiusSource::Source from

Returns: The RadiusSource::Source matching the given string

Definition at line 1559 of file ControlPoint.cpp.

ControlPoint::SurfacePointSource::Source Isis::ControlPoint::StringToSurfacePointSource ( QString str )

static

Obtain a SurfacePoint::Source from a string.

Parameters

str	string to get a SurfacePoint::Source from

Returns: The SurfacePint::Source matching the given string

Definition at line 1636 of file ControlPoint.cpp.

QString Isis::ControlPoint::SurfacePointSourceToString ( SurfacePointSource::Source source )

static

Obtain a string representation of a given SurfacePointSource.

Parameters

souce SurfacePointSource to get a string representation of

Returns: A string representation of SurfacePointSource

Definition at line 1598 of file ControlPoint.cpp.

Referenced by GetSurfacePointSourceString().

void Isis::ControlPoint::ValidateMeasure ( QString serialNumber ) const

private

Throws an exception if none of the point's measures have the given serial number.

It is common to ensure that a measure exists before taking some action.

Parameters

sn	The serial number of the measure to validate

Definition at line 474 of file ControlPoint.cpp.

References _FILEINFO_, and Isis::IException::Programmer.

Referenced by Delete(), and GetMeasure().

void Isis::ControlPoint::ZeroNumberOfRejectedMeasures ( )

Initialize the number of rejected measures to 0.

Definition at line 2074 of file ControlPoint.cpp.

References numberOfRejectedMeasures.

Referenced by Isis::BundleAdjust::FlagOutliers().

Member Data Documentation

SurfacePoint Isis::ControlPoint::adjustedSurfacePoint

private

This is the calculated, or aposterori, surface point.

This is what most programs should be working with and updating.

Definition at line 682 of file ControlPoint.h.

Referenced by ComputeApriori(), ControlPoint(), GetBestSurfacePoint(), operator=(), operator==(), and SetAdjustedSurfacePoint().

RadiusSource::Source Isis::ControlPoint::aprioriRadiusSource

private

Where the apriori surface point's radius originated from, most commonly used by jigsaw.

Definition at line 661 of file ControlPoint.h.

Referenced by ControlPoint(), GetRadiusSourceString(), operator=(), operator==(), ResetApriori(), and SetAprioriRadiusSource().

QString Isis::ControlPoint::aprioriRadiusSourceFile

private

The name of the file that derives the apriori surface point's radius.

Definition at line 666 of file ControlPoint.h.

Referenced by ControlPoint(), operator=(), operator==(), ResetApriori(), and SetAprioriRadiusSourceFile().

SurfacePoint Isis::ControlPoint::aprioriSurfacePoint

private

The apriori surface point.

This is the "known truth" or trustworthy point that should not be modified unless done very explicitely. This comes from places like hand picking where you really don't want the surface point to vary far from this point, but some variation is okay (1/10th of a pixel is fair for human accuracy for example). Very often this point does not exist.

Definition at line 676 of file ControlPoint.h.

Referenced by ComputeApriori(), ControlPoint(), GetBestSurfacePoint(), operator=(), operator==(), ResetApriori(), and SetAprioriSurfacePoint().

SurfacePointSource::Source Isis::ControlPoint::aprioriSurfacePointSource

private

Where the apriori surface point originated from.

Definition at line 652 of file ControlPoint.h.

Referenced by ControlPoint(), GetSurfacePointSourceString(), operator=(), operator==(), ResetApriori(), and SetAprioriSurfacePointSource().

QString Isis::ControlPoint::aprioriSurfacePointSourceFile

private

FileName where the apriori surface point originated from.

Definition at line 655 of file ControlPoint.h.

Referenced by ControlPoint(), operator=(), operator==(), ResetApriori(), and SetAprioriSurfacePointSourceFile().

QString Isis::ControlPoint::chooserName

private

This is the user name of the person who last modified this control point.

Modifications are things like updating the surface point, but not things like updating the last modified time. The calculations relating to this control point have to actually change for this to be updated. This is an empty string if we need to dynamically get the username of the caller when asked for (or written to file).

Definition at line 598 of file ControlPoint.h.

Referenced by ControlPoint(), operator=(), operator==(), and SetChooserName().

std::bitset<6> Isis::ControlPoint::constraintStatus

private

This stores the constraint status of the a priori SurfacePoint.

Todo:: Eventually add x, y, and z

Definition at line 635 of file ControlPoint.h.

Referenced by ControlPoint(), operator=(), operator==(), ResetApriori(), and SetAprioriSurfacePoint().

QString Isis::ControlPoint::dateTime

private

This is the last modified date and time.

This is updated automatically and works virtually in the same way as chooserName.

Definition at line 604 of file ControlPoint.h.

Referenced by ControlPoint(), operator=(), operator==(), and SetDateTime().

bool Isis::ControlPoint::editLock

private

This stores the edit lock state.

See Also: SetEditLock

Definition at line 623 of file ControlPoint.h.

Referenced by ControlPoint(), operator=(), operator==(), SetAprioriRadiusSource(), SetAprioriRadiusSourceFile(), SetAprioriSurfacePoint(), SetAprioriSurfacePointSource(), SetAprioriSurfacePointSourceFile(), SetChooserName(), SetDateTime(), SetEditLock(), SetId(), SetIgnored(), SetRefMeasure(), and SetType().

QString Isis::ControlPoint::id

private

This is the control point ID.

This is supposed to be a unique identifier for control points. This often has a number in it, and looks like "T0052" where the next one is "T0053" and so on.

Definition at line 588 of file ControlPoint.h.

Referenced by ControlPoint(), GetId(), operator=(), operator==(), and SetId().

bool Isis::ControlPoint::ignore

private

True if we should preserve but ignore the entire control point and its measures.

Definition at line 649 of file ControlPoint.h.

Referenced by ControlPoint(), operator=(), operator==(), and SetIgnored().

bool Isis::ControlPoint::invalid

private

If we forced a build that we would normally have thrown an exception for then this is set to true.

Otherwise, and most of the time, this is false.

Definition at line 617 of file ControlPoint.h.
