Isis::AdvancedTrackTool Class Reference

Tool to display info for a point on a cube. More...

#include <AdvancedTrackTool.h>

Inheritance diagram for Isis::AdvancedTrackTool:

Collaboration diagram for Isis::AdvancedTrackTool:

Public Slots
virtual void	mouseMove (QPoint p)
	This method is called when the mouse has moved across the viewport and updates the row accordingly.
virtual void	mouseLeave ()
	This method is called when the mouse leaves the viewport and clears any rows accordingly.
void	record (QPoint p)
	This slot updates the row with data from the point given and records data to the current row.
void	activate (bool)
	Activates the tool.
virtual void	updateTool ()
	Updates the tool.
void	setCubeViewport (MdiCubeViewport *cvp)
	Sets the current viewport to the given cvp.

Signals
void	clearWarningSignal ()
void	toolActivated ()
void	viewportChanged ()

Public Member Functions
	AdvancedTrackTool (QWidget *parent)
	Constructs an AdvancedTrackTool object.
void	addTo (QMenu *menu)
	This method adds the action to bring up the track tool to the menu.
void	addToPermanent (QToolBar *perm)
	This method adds the action to bring up the track tool to the permanent tool bar.
bool	eventFilter (QObject *o, QEvent *e)
	An event filter that calls methods on certain events.
void	addTo (ViewportMainWindow *mw)
	Adds the tool to the application.
void	addTo (ToolPad *toolpad)
	Adds the tool to the toolpad.
virtual void	addTo (Workspace *ws)
	Adds the given workspace to the cubeviewport list.
void	addToActive (QToolBar *toolbar)
QString	toolIconDir () const
	returns the path to the icon directory.
virtual void	paintViewport (MdiCubeViewport *vp, QPainter *painter)
RubberBandTool *	rubberBandTool ()
void	setList (ToolList *currentList)

Protected Types
typedef QVector < MdiCubeViewport * >	CubeViewportList
	A list of cubeviewports.

Protected Slots
virtual void	rubberBandComplete ()
virtual void	screenPixelsChanged ()
	This is called when actions change which pixels from the cube are displayed.
virtual void	mouseEnter ()
virtual void	mouseMove (QPoint p, Qt::MouseButton)
virtual void	mouseDoubleClick (QPoint p)
virtual void	mouseButtonPress (QPoint p, Qt::MouseButton s)
virtual void	mouseButtonRelease (QPoint p, Qt::MouseButton s)
	Resets the Warning to Nowarning when a different activity occurs on the application.
virtual void	updateMeasure ()
virtual void	scaleChanged ()
virtual void	stretchRequested (MdiCubeViewport *, int)
void	registerTool (MdiCubeViewport *viewport)
	Registers the tool to the viewport.

Protected Member Functions
QString	menuName () const
	This method returns the menu name associated with this tool.
MdiCubeViewport *	cubeViewport () const
	Return the current cubeviewport.
CubeViewportList *	cubeViewportList () const
	Return the list of cubeviewports.
virtual QAction *	toolPadAction (ToolPad *toolpad)
	Anytime a tool is created, you must setup a tool pad action with it.
virtual QWidget *	createToolBarWidget (QStackedWidget *parent)
	Anytime a tool is created, you must add it to the tool bar.
virtual void	addConnections (MdiCubeViewport *cvp)
	Anytime a tool is created, you must add the connections for it.
virtual void	removeConnections (MdiCubeViewport *cvp)
	Anytime a tool is created, you must be able to remove it's connections.
virtual void	enableRubberBandTool ()
	Anytime a tool is created, you may use the rubber band tool.
Workspace *	workspace ()

Private Types
enum	{   ID, SAMPLE, LINE, BAND,   PIXEL, PLANETOCENTRIC_LAT, PLANETOGRAPHIC_LAT, EAST_LON_360,   WEST_LON_360, EAST_LON_180, WEST_LON_180, PROJECTED_X,   PROJECTED_Y, RADIUS, POINT_X, POINT_Y,   POINT_Z, RIGHT_ASCENSION, DECLINATION, RESOLUTION,   PHASE, INCIDENCE, EMISSION, LOCAL_INCIDENCE,   LOCAL_EMISSION, NORTH_AZIMUTH, SUN_AZIMUTH, SOLAR_LON,   SPACECRAFT_X, SPACECRAFT_Y, SPACECRAFT_Z, SPACECRAFT_AZIMUTH,   SLANT, DISTORTED_FOCAL_X, DISTORTED_FOCAL_Y, UNDISTORTED_FOCAL_X,   UNDISTORTED_FOCAL_Y, UNDISTORTED_FOCAL_Z, EPHEMERIS_TIME, SOLAR_TIME,   UTC, PATH, FILENAME, SERIAL_NUMBER,   TRACK_MOSAIC_INDEX, TRACK_MOSAIC_FILENAME, TRACK_MOSAIC_SERIAL_NUM, NOTES }
	Enum for column values. More...

Private Slots
void	updateRow (QPoint p)
	This method updates the row with data from the point given.
void	updateRow (MdiCubeViewport *cvp, QPoint p, int row)
	This method updates the row given with data from the viewport cvp at point p.
void	record ()
	This method records data to the current row.
void	updateID ()
	This method updates the record ID.
void	TrackMosaicOrigin (MdiCubeViewport *cvp, int piLine, int piSample, int &piOrigin, QString &psSrcFileName, QString &psSrcSerialNum)
	TrackMosaicOrigin - Given the pointer to Cube and line and sample index, finds the origin of the mosaic if the TRACKING band and Mosaic Origin Table exists.
void	helpDialog ()
	This method creates a dialog box that shows help tips.

Private Member Functions
void	readSettings ()
	Read this tool's preserved state.
void	writeSettings ()
	Write out this tool's preserved state between runs.
QString	settingsFilePath () const
	Generate the correct path for the config file.

Private Attributes
QAction *	p_action
	Action to bring up the track tool.
int	p_numRows
	The number of rows in the table.
int	p_id
	The record id.
TableMainWindow *	p_tableWin
	The table window.
bool	m_showHelpOnStart
	True to show dialog When tool is started.

Detailed Description

Tool to display info for a point on a cube.

This tool is part of the Qisis namespace and allows the user to view and record information from a point on a cube such as line, sample, band, lats, longs, etc.

Author

????-??-?? Unknown

History:

2008-06-25 Noah Hilt - Added enumeration for different column values.

History:

2008-10-14 Noah Hilt - Added Projected X and Y values to the table.

History:

2008-10-17 Noah Hilt - Added tooltips to certain items in the table that did not have descriptive names.

History:

2010-02-17 Sharmila Prasad -Added the attributes TRACK_MOSAIC_INDEX, TRACK_MOSAIC_FILENAME, TRACK_MOSAIC_SERIAL_NUM to track mosaic origin

History:

2010-03-08 Jeannie Walldren - Added record() slot to be able to record a QPoint passed from the FindTool to the current row.

History:

2010-05-07 Eric Hyer - record() SLOT now shows the table as well

History:

2010-06-26 Eric Hyer - Class now uses MdiCubeViewport, also fixed include issues

History:

2011-02-16 Sharmila Prasad - Added columns for Local Emission and Incidence Angles

History:

2012-06-22 Kimberly Oyama and Steven Lambright - Added a help menu to the menu bar and a help dialog that displays when the tool is opened the first time and when the user opens it through the help menu. Fixes #772.

History:

2012-07-06 Debbie A. Cook, Updated Spice members to be more compliant with Isis coding standards. References #972.

History:

2012-11-30 Debbie A. Cook - Changed to use TProjection instead of Projection. References #775.

History:

2013-04-24 Jeannie Backer - Modified to print "N/A" for NorthAzimuth if projection is not triaxial since this value is meaningless for ring plane projections. References #775.

History:

2014-06-17 Jeannie Backer - Modified to print set value to empty strings for photometric angles, azimuths, resolutions if not valid. References #1659.

History:

2015-05-13 Makayla Shepherd - Modified to improve handling of undefined slot behavior. References #2210.

History:

2015-06-19 Makayla Shepherd - Added distorted Focal Plane and undistorted Focal Plane to the table. References #1953.

History:

2015-12-21 Makayla Shepherd - Changed the ordering of the enum to match the order of when the columns are added, in order to fix the incidence and emission angle columns from reporting incorrect numbers. Fixes #2381.

Definition at line 82 of file AdvancedTrackTool.h.

Member Typedef Documentation

typedef QVector< MdiCubeViewport * > Isis::Tool::CubeViewportList

protectedinherited

A list of cubeviewports.

Definition at line 219 of file Tool.h.

Member Enumeration Documentation

anonymous enum

private

Enum for column values.

Enumerator:

ID	The record ID.
SAMPLE	The current sample.
LINE	The current line.
BAND	The current band.
PIXEL	The current pixel.
PLANETOCENTRIC_LAT	The planetocentric latitude for this point.
PLANETOGRAPHIC_LAT	The planetographic latitude for this point.
EAST_LON_360	The 360 east longitude for this point.
WEST_LON_360	The 360 west longitude for this point.
EAST_LON_180	The 180 east longitude for this point.
WEST_LON_180	The 180 west longitude for this point.
PROJECTED_X	Projected X value for valid projections.
PROJECTED_Y	Projected Y value for valid projections.
RADIUS	The radius for this point.
POINT_X	The x value for this point.
POINT_Y	The y value for this point.
POINT_Z	The z value for this point.
RIGHT_ASCENSION	The right ascension for this point.
DECLINATION	The declination for this point.
RESOLUTION	The resoultion for this point.
PHASE	The phase for this point.
INCIDENCE	The incidence for this point.
EMISSION	The emission for this point.
LOCAL_INCIDENCE	The local incidence for this point.
LOCAL_EMISSION	The local emission for this point.
NORTH_AZIMUTH	The north azimuth for this cube.
SUN_AZIMUTH	The sun azimuth for this cube.
SOLAR_LON	The solar longitude for this point.
SPACECRAFT_X	The spacecraft x position for this cube.
SPACECRAFT_Y	The spacecraft y position for this cube.
SPACECRAFT_Z	The spacecraft z position for this cube.
SPACECRAFT_AZIMUTH	The spacecraft azimuth for this cube.
SLANT	The slant for this cube.
DISTORTED_FOCAL_X	The x of the distorted focal plane.
DISTORTED_FOCAL_Y	The y of the distorted focal plane.
UNDISTORTED_FOCAL_X	The x of the undistorted focal plane.
UNDISTORTED_FOCAL_Y	The y of the undistorted focal plane.
UNDISTORTED_FOCAL_Z	The z of the undistorted focal plane.
EPHEMERIS_TIME	The ephemeris time for this cube.
SOLAR_TIME	The local solar time for this cube.
UTC	The UTC for this cube.
PATH	The path for this cube.
FILENAME	The filename for this cube.
SERIAL_NUMBER	The serial number for this cube.
TRACK_MOSAIC_INDEX	Track the origin of the Mosaic, display the zero based index.
TRACK_MOSAIC_FILENAME	Track the origin of the Mosaic, display file name.
TRACK_MOSAIC_SERIAL_NUM	Track the origin of the Mosaic, display file name.
NOTES	Any notes for this record.

Definition at line 125 of file AdvancedTrackTool.h.

Constructor & Destructor Documentation

Isis::AdvancedTrackTool::AdvancedTrackTool

(

QWidget *

parent

)

Constructs an AdvancedTrackTool object.

Parameters

parent

Definition at line 35 of file AdvancedTrackTool.cpp.

References Isis::Tool::activate(), Isis::TableMainWindow::addToTable(), helpDialog(), m_showHelpOnStart, p_action, p_id, p_tableWin, readSettings(), record(), Isis::TableMainWindow::setStatusMessage(), Isis::TableMainWindow::setTrackListItems(), Isis::TableMainWindow::table(), Isis::Tool::toolIconDir(), and updateID().

Member Function Documentation

void Isis::Tool::activate ( bool  on )

slotinherited

Activates the tool.

Parameters

on

Definition at line 130 of file Tool.cpp.

References Isis::Tool::addViewportConnections(), Isis::Tool::disableToolBar(), Isis::Tool::enableToolBar(), Isis::Tool::m_active, Isis::Tool::m_toolPadAction, and Isis::Tool::removeViewportConnections().

Referenced by Isis::Tool::addTo(), AdvancedTrackTool(), Isis::RubberBandTool::disable(), Isis::RubberBandTool::enable(), eventFilter(), Isis::FileTool::FileTool(), Isis::RubberBandTool::RubberBandTool(), Isis::TrackTool::TrackTool(), Isis::WindowTool::WindowTool(), and Isis::Workspace::Workspace().

virtual void Isis::Tool::addConnections ( MdiCubeViewport *  cvp )

inlineprotectedvirtualinherited

Anytime a tool is created, you must add the connections for it.

Parameters

cvp

Reimplemented in Isis::TrackTool, and Isis::WindowTool.

Definition at line 253 of file Tool.h.

Referenced by Isis::Tool::addViewportConnections().

void Isis::Tool::addTo ( ViewportMainWindow *  pViewPortMnWin )

inherited

Adds the tool to the application.

Parameters

pViewPortMnWin

Definition at line 77 of file Tool.cpp.

References Isis::ViewportMainWindow::activeToolBar(), Isis::Tool::addToActive(), Isis::Tool::addToPermanent(), Isis::ViewportMainWindow::getMenu(), Isis::Tool::menuName(), Isis::ViewportMainWindow::permanentToolBar(), Isis::ViewportMainWindow::toolPad(), and Isis::ViewportMainWindow::workspace().

Referenced by Isis::ViewportMainWindow::ViewportMainWindow(), and Isis::Workspace::Workspace().

void Isis::AdvancedTrackTool::addTo ( QMenu *  menu )

virtual

This method adds the action to bring up the track tool to the menu.

Parameters

menu

Reimplemented from Isis::Tool.

Definition at line 165 of file AdvancedTrackTool.cpp.

References p_action.

void Isis::Tool::addTo ( ToolPad *  toolpad )

inherited

Adds the tool to the toolpad.

Parameters

toolpad

Definition at line 97 of file Tool.cpp.

References Isis::Tool::activate(), Isis::ToolPad::addAction(), Isis::Tool::m_toolPadAction, and Isis::Tool::toolPadAction().

void Isis::Tool::addTo ( Workspace *  ws )

virtualinherited

Adds the given workspace to the cubeviewport list.

Parameters

ws

Reimplemented in Isis::EditTool, Isis::FileTool, Isis::SpecialPixelTool, and Isis::WindowTool.

Definition at line 44 of file Tool.cpp.

References Isis::Tool::registerTool(), and Isis::Tool::setCubeViewport().

void Isis::Tool::addToActive ( QToolBar *  toolbar )

inherited

Parameters

toolbar

Definition at line 111 of file Tool.cpp.

References Isis::Tool::createToolBarWidget(), Isis::Tool::disableToolBar(), and Isis::Tool::m_toolBarWidget.

Referenced by Isis::Tool::addTo(), and Isis::Workspace::Workspace().

void Isis::AdvancedTrackTool::addToPermanent ( QToolBar *  perm )

virtual

This method adds the action to bring up the track tool to the permanent tool bar.

Parameters

perm

Reimplemented from Isis::Tool.

Definition at line 175 of file AdvancedTrackTool.cpp.

References p_action.

virtual QWidget* Isis::Tool::createToolBarWidget ( QStackedWidget *  parent )

inlineprotectedvirtualinherited

Anytime a tool is created, you must add it to the tool bar.

Parameters

parent

Returns

QWidget*

Reimplemented in Isis::StretchTool, Isis::FindTool, Isis::StatisticsTool, Isis::FeatureNomenclatureTool, Isis::EditTool, Isis::ZoomTool, Isis::MeasureTool, Isis::StereoTool, Isis::SpatialPlotTool, Isis::SpectralPlotTool, Isis::AbstractPlotTool, Isis::BandTool, Isis::SunShadowTool, Isis::ScatterPlotTool, Isis::HistogramTool, and Isis::PanTool.

Definition at line 243 of file Tool.h.

Referenced by Isis::Tool::addToActive().

MdiCubeViewport* Isis::Tool::cubeViewport ( ) const

inlineprotectedinherited

Return the current cubeviewport.

Returns

CubeViewport*

Definition at line 211 of file Tool.h.

References Isis::Tool::m_cvp.

Referenced by Isis::WindowTool::addConnections(), Isis::TrackTool::addConnections(), Isis::StretchTool::advancedStretchChanged(), Isis::FindTool::centerLinkedViewports(), Isis::StretchTool::changeStretch(), Isis::BandTool::changeView(), Isis::BandTool::copyLinkedViewports(), Isis::FileTool::discard(), Isis::Tool::enableToolBar(), Isis::FileTool::exportView(), Isis::StatisticsTool::getStatistics(), Isis::FindTool::handleRecordClicked(), Isis::EditTool::LineToPoints(), Isis::TrackTool::locateCursor(), Isis::SunShadowTool::mouseButtonPress(), Isis::RubberBandTool::mouseButtonRelease(), Isis::EditTool::mouseButtonRelease(), Isis::FeatureNomenclatureTool::mouseButtonRelease(), Isis::FindTool::mouseButtonRelease(), Isis::StretchTool::mouseButtonRelease(), Isis::MatchTool::mouseButtonRelease(), Isis::QnetTool::mouseButtonRelease(), mouseLeave(), Isis::ScatterPlotTool::mouseMove(), Isis::SunShadowTool::mouseMove(), Isis::TrackTool::mouseMove(), Isis::RubberBandTool::mouseMove(), Isis::SunShadowTool::paintViewport(), Isis::RubberBandTool::paintViewport(), Isis::FindTool::paintViewport(), Isis::FileTool::print(), Isis::SunShadowTool::recalculateShadowHeight(), Isis::EditTool::redoEdit(), Isis::FindTool::refresh(), Isis::HistogramTool::refreshPlot(), Isis::SpatialPlotTool::refreshPlot(), Isis::SpectralPlotTool::refreshPlot(), Isis::WindowTool::removeConnections(), Isis::TrackTool::removeConnections(), Isis::RubberBandTool::repaint(), Isis::WindowTool::resizeWindows(), Isis::HistogramTool::rubberBandComplete(), Isis::MeasureTool::rubberBandComplete(), Isis::ZoomTool::rubberBandComplete(), Isis::EditTool::rubberBandComplete(), Isis::StretchTool::rubberBandComplete(), Isis::FileTool::save(), Isis::FileTool::saveAs(), Isis::FileTool::saveAsCubeByOption(), Isis::FileTool::saveAsReducedCube(), Isis::FileTool::saveInfo(), Isis::BandTool::setBandBin(), Isis::BandTool::setList(), Isis::StretchTool::setStretchAcrossBands(), Isis::StretchTool::setStretchAllViewports(), Isis::StretchTool::showAdvancedDialog(), Isis::ScatterPlotTool::showNewScatterPlotConfig(), Isis::StretchTool::stretchChanged(), Isis::StretchTool::stretchGlobal(), Isis::StretchTool::stretchGlobalAllBands(), Isis::StretchTool::stretchRegional(), Isis::EditTool::undoEdit(), Isis::StretchTool::updateAdvStretchDialogforAll(), Isis::StretchTool::updateHistograms(), Isis::TrackTool::updateLabels(), Isis::MeasureTool::updateMeasure(), updateRow(), Isis::WindowTool::updateTool(), Isis::BlinkTool::updateTool(), Isis::SpecialPixelTool::updateTool(), Isis::SunShadowTool::updateTool(), Isis::BandTool::updateTool(), Isis::AbstractPlotTool::updateTool(), Isis::ZoomTool::updateTool(), Isis::FileTool::updateTool(), Isis::EditTool::updateTool(), Isis::FindTool::updateTool(), Isis::StretchTool::updateTool(), Isis::AbstractPlotTool::viewportsToPlot(), Isis::EditTool::writeToCube(), Isis::ZoomTool::zoomBy(), Isis::ZoomTool::zoomFit(), Isis::ZoomTool::zoomFitHeight(), Isis::ZoomTool::zoomFitWidth(), and Isis::ZoomTool::zoomManual().

Tool::CubeViewportList * Isis::Tool::cubeViewportList ( ) const

protectedinherited

Return the list of cubeviewports.

Returns

CubeViewportList*

Definition at line 389 of file Tool.cpp.

References Isis::Workspace::cubeViewportList().

Referenced by Isis::BlinkTool::advance(), Isis::SpecialPixelTool::apply(), Isis::FindTool::centerLinkedViewports(), Isis::WindowTool::changeCursor(), Isis::FileTool::closeAll(), Isis::BandTool::copyAllViewports(), Isis::BandTool::copyLinkedViewports(), Isis::MatchTool::createPoint(), Isis::BlinkTool::eventFilter(), Isis::FeatureNomenclatureTool::featuresIdentified(), Isis::FeatureNomenclatureTool::findMissingNomenclature(), Isis::FeatureNomenclatureTool::findNomenclatureStateChanged(), Isis::FindTool::handleLinkClicked(), Isis::WindowTool::linkWindows(), Isis::RubberBandTool::mouseButtonRelease(), Isis::RubberBandTool::mouseMove(), Isis::QnetTool::openGround(), Isis::StereoTool::paintAllViewports(), Isis::MatchTool::paintAllViewports(), Isis::QnetTool::paintAllViewports(), Isis::FindTool::refresh(), Isis::ScatterPlotTool::repaintViewports(), Isis::AbstractPlotTool::repaintViewports(), Isis::WindowTool::resizeWindows(), Isis::BlinkTool::reverse(), Isis::ZoomTool::rubberBandComplete(), Isis::MatchTool::serialNumberList(), Isis::FeatureNomenclatureTool::setFontColor(), Isis::FeatureNomenclatureTool::setFontSize(), Isis::FeatureNomenclatureTool::setShowApprovedOnly(), Isis::StretchTool::setStretchAllViewports(), Isis::FeatureNomenclatureTool::setVectorType(), Isis::StretchTool::stretchGlobalAllViewports(), Isis::BlinkTool::toggleLink(), Isis::WindowTool::unlinkWindows(), Isis::MeasureTool::updateMeasure(), updateRow(), Isis::WindowTool::updateTool(), Isis::BlinkTool::updateTool(), Isis::FindTool::updateTool(), Isis::AbstractPlotTool::viewportsToPlot(), Isis::ZoomTool::zoomBy(), Isis::ZoomTool::zoomFit(), Isis::ZoomTool::zoomFitHeight(), Isis::ZoomTool::zoomFitWidth(), and Isis::ZoomTool::zoomManual().

void Isis::Tool::enableRubberBandTool ( )

protectedvirtualinherited

Anytime a tool is created, you may use the rubber band tool.

Enable the use of the rubberband tool.

Reimplemented in Isis::RubberBandTool, Isis::ZoomTool, Isis::MeasureTool, Isis::StereoTool, Isis::SpatialPlotTool, Isis::SpectralPlotTool, and Isis::HistogramTool.

Definition at line 338 of file Tool.cpp.

References Isis::RubberBandTool::disable().

Referenced by Isis::Tool::addViewportConnections().

bool Isis::AdvancedTrackTool::eventFilter	(	QObject *	o,
		QEvent *	e
	)

An event filter that calls methods on certain events.

Parameters

o
e

Returns

bool

Definition at line 144 of file AdvancedTrackTool.cpp.

References Isis::Tool::activate(), helpDialog(), m_showHelpOnStart, and writeSettings().

void Isis::AdvancedTrackTool::helpDialog ( )

privateslot

This method creates a dialog box that shows help tips.

It is displayed when the tool is opened the first time (unless the user says otherwise) and when the user opens it through the help menu.

Definition at line 620 of file AdvancedTrackTool.cpp.

References p_tableWin.

Referenced by AdvancedTrackTool(), and eventFilter().

QString Isis::AdvancedTrackTool::menuName ( ) const

inlineprotectedvirtual

This method returns the menu name associated with this tool.

Returns

QString

Reimplemented from Isis::Tool.

Definition at line 103 of file AdvancedTrackTool.h.

void Isis::Tool::mouseButtonPress ( QPoint  p, Qt::MouseButton  s  )

protectedvirtualslotinherited

Parameters

p
s

Definition at line 366 of file Tool.cpp.

Referenced by Isis::Tool::addViewportConnections(), and Isis::Tool::removeViewportConnections().

void Isis::Tool::mouseButtonRelease ( QPoint  p, Qt::MouseButton  s  )

protectedvirtualslotinherited

Resets the Warning to Nowarning when a different activity occurs on the application.

This is called by all the mouseButtonRelease events in all the tools.

Parameters

p
s

Reimplemented in Isis::FeatureNomenclatureTool.

Definition at line 379 of file Tool.cpp.

Referenced by Isis::Tool::addViewportConnections(), and Isis::Tool::removeViewportConnections().

void Isis::Tool::mouseDoubleClick ( QPoint  p )

protectedvirtualslotinherited

Parameters

p

Definition at line 357 of file Tool.cpp.

Referenced by Isis::Tool::addViewportConnections(), and Isis::Tool::removeViewportConnections().

void Isis::AdvancedTrackTool::mouseLeave ( )

virtualslot

This method is called when the mouse leaves the viewport and clears any rows accordingly.

Definition at line 194 of file AdvancedTrackTool.cpp.

References Isis::TableMainWindow::clearRow(), Isis::Tool::cubeViewport(), Isis::TableMainWindow::currentRow(), p_numRows, and p_tableWin.

void Isis::AdvancedTrackTool::mouseMove ( QPoint  p )

virtualslot

This method is called when the mouse has moved across the viewport and updates the row accordingly.

Parameters

p

Definition at line 185 of file AdvancedTrackTool.cpp.

References updateRow().

virtual void Isis::Tool::paintViewport ( MdiCubeViewport *  vp, QPainter *  painter  )

inlinevirtualinherited

Parameters

vp
painter

Reimplemented in Isis::QnetTool, Isis::MatchTool, Isis::FindTool, Isis::FeatureNomenclatureTool, Isis::RubberBandTool, Isis::StereoTool, Isis::SunShadowTool, Isis::AbstractPlotTool, and Isis::ScatterPlotTool.

Definition at line 136 of file Tool.h.

void Isis::AdvancedTrackTool::readSettings ( )

private

Read this tool's preserved state.

This uses the current state as defaults, so please make sure your variables are initialized before calling this method.

Definition at line 737 of file AdvancedTrackTool.cpp.

References m_showHelpOnStart, and settingsFilePath().

Referenced by AdvancedTrackTool().

void Isis::AdvancedTrackTool::record ( QPoint  p )

slot

This slot updates the row with data from the point given and records data to the current row.

Parameters

p	QPoint from which the row(s) will be updated and recorded.

Returns

void

Author

Jeannie Walldren

History:

2010-03-08 - Jeannie Walldren - This slot was added to be connected to the FindTool recordPoint() signal in qview.

History:

2010-05-07 - Eric Hyer - Now shows the table as well

Definition at line 712 of file AdvancedTrackTool.cpp.

References p_tableWin, record(), Isis::TableMainWindow::showTable(), and updateRow().

void Isis::AdvancedTrackTool::record ( )

privateslot

This method records data to the current row.

Definition at line 672 of file AdvancedTrackTool.cpp.

References Isis::TableMainWindow::currentIndex(), Isis::TableMainWindow::currentRow(), p_id, p_numRows, p_tableWin, Isis::TableMainWindow::setCurrentIndex(), Isis::TableMainWindow::setCurrentRow(), and Isis::TableMainWindow::table().

Referenced by AdvancedTrackTool(), and record().

void Isis::Tool::registerTool ( MdiCubeViewport *  viewport )

protectedslotinherited

Registers the tool to the viewport.

Parameters

viewport

Definition at line 326 of file Tool.cpp.

References Isis::Tool::m_cvp, and Isis::MdiCubeViewport::registerTool().

Referenced by Isis::Tool::addTo().

virtual void Isis::Tool::removeConnections ( MdiCubeViewport *  cvp )

inlineprotectedvirtualinherited

Anytime a tool is created, you must be able to remove it's connections.

Parameters

cvp

Reimplemented in Isis::MeasureTool, Isis::TrackTool, and Isis::WindowTool.

Definition at line 261 of file Tool.h.

Referenced by Isis::Tool::removeViewportConnections().

virtual void Isis::Tool::screenPixelsChanged ( )

inlineprotectedvirtualslotinherited

This is called when actions change which pixels from the cube are displayed.

Definition at line 162 of file Tool.h.

Referenced by Isis::Tool::addViewportConnections(), Isis::Tool::removeViewportConnections(), and Isis::FeatureNomenclatureTool::viewportDone().

void Isis::Tool::setCubeViewport ( MdiCubeViewport *  cvp )

slotinherited

Sets the current viewport to the given cvp.

Parameters

cvp

Definition at line 159 of file Tool.cpp.

References Isis::Tool::addViewportConnections(), Isis::Tool::enableToolBar(), Isis::Tool::m_active, Isis::Tool::m_cvp, Isis::Tool::removeViewportConnections(), and Isis::Tool::updateTool().

Referenced by Isis::Tool::addTo(), and Isis::FileTool::closeAll().

QString Isis::AdvancedTrackTool::settingsFilePath ( ) const

private

Generate the correct path for the config file.

Returns

the config file path

Definition at line 762 of file AdvancedTrackTool.cpp.

References _FILEINFO_, and Isis::IException::Programmer.

Referenced by readSettings(), and writeSettings().

QString Isis::Tool::toolIconDir ( ) const

inlineinherited

returns the path to the icon directory.

Returns

QString

Definition at line 127 of file Tool.h.

References Isis::Tool::m_toolIconDir.

Referenced by AdvancedTrackTool(), Isis::BlinkTool::BlinkTool(), Isis::MatchTool::createActions(), Isis::QnetTool::createActions(), Isis::StereoTool::createMenus(), Isis::PanTool::createToolBarWidget(), Isis::BandTool::createToolBarWidget(), Isis::StereoTool::createToolBarWidget(), Isis::ZoomTool::createToolBarWidget(), Isis::EditTool::createToolBarWidget(), Isis::FindTool::createToolBarWidget(), Isis::StretchTool::createToolBarWidget(), Isis::FileTool::FileTool(), Isis::FindTool::FindTool(), Isis::HistogramTool::HistogramTool(), Isis::SpecialPixelTool::SpecialPixelTool(), Isis::RubberBandComboBox::toolIconDir(), Isis::PanTool::toolPadAction(), Isis::HistogramTool::toolPadAction(), Isis::ScatterPlotTool::toolPadAction(), Isis::SunShadowTool::toolPadAction(), Isis::BandTool::toolPadAction(), Isis::SpectralPlotTool::toolPadAction(), Isis::SpatialPlotTool::toolPadAction(), Isis::StereoTool::toolPadAction(), Isis::MeasureTool::toolPadAction(), Isis::ZoomTool::toolPadAction(), Isis::EditTool::toolPadAction(), Isis::FeatureNomenclatureTool::toolPadAction(), Isis::StatisticsTool::toolPadAction(), Isis::FindTool::toolPadAction(), Isis::StretchTool::toolPadAction(), Isis::MatchTool::toolPadAction(), Isis::QnetTool::toolPadAction(), Isis::WindowTool::WindowTool(), and Isis::ZoomTool::ZoomTool().

virtual QAction* Isis::Tool::toolPadAction ( ToolPad *  toolpad )

inlineprotectedvirtualinherited

Anytime a tool is created, you must setup a tool pad action with it.

Parameters

toolpad

Returns

QAction*

Reimplemented in Isis::QnetTool, Isis::MatchTool, Isis::StretchTool, Isis::FindTool, Isis::StatisticsTool, Isis::FeatureNomenclatureTool, Isis::EditTool, Isis::ZoomTool, Isis::MeasureTool, Isis::SpatialPlotTool, Isis::StereoTool, Isis::SpectralPlotTool, Isis::BandTool, Isis::SunShadowTool, Isis::ScatterPlotTool, Isis::HistogramTool, and Isis::PanTool.

Definition at line 231 of file Tool.h.

Referenced by Isis::Tool::addTo().

void Isis::AdvancedTrackTool::TrackMosaicOrigin ( MdiCubeViewport *  cvp, int  piLine, int  piSample, int &  piOrigin, QString &  psSrcFileName, QString &  psSrcSerialNum  )

privateslot

TrackMosaicOrigin - Given the pointer to Cube and line and sample index, finds the origin of the mosaic if the TRACKING band and Mosaic Origin Table exists.

Author

sprasad (11/16/2009)

Parameters

cvp	- Points to the CubeViewPort
piLine	- Line Index
piSample	- Sample Index
piOrigin	- Contains the Src Index (zero based)
psSrcFileName	- Contains the Src FileName
psSrcSerialNum-	Contains the Src Serial Number

Returns

void

Definition at line 556 of file AdvancedTrackTool.cpp.

References Isis::CubeViewport::cube(), Isis::PvlObject::findGroup(), Isis::PvlObject::findObject(), Isis::Cube::hasTable(), Isis::PvlContainer::keywords(), Isis::Cube::label(), Isis::Cube::pixelType(), Isis::Cube::read(), Isis::Table::Records(), Isis::Cube::sampleCount(), Isis::Portal::SetPosition(), Isis::PvlKeyword::size(), Isis::SizeOf(), and Isis::IException::toString().

Referenced by updateRow().

void Isis::AdvancedTrackTool::updateID ( )

privateslot

This method updates the record ID.

Definition at line 723 of file AdvancedTrackTool.cpp.

References Isis::TableMainWindow::currentRow(), ID, p_id, p_tableWin, and Isis::TableMainWindow::table().

Referenced by AdvancedTrackTool().

void Isis::AdvancedTrackTool::updateRow ( QPoint  p )

privateslot

This method updates the row with data from the point given.

Parameters

p

Definition at line 212 of file AdvancedTrackTool.cpp.

References Isis::TableMainWindow::clearRow(), Isis::Tool::cubeViewport(), Isis::Tool::cubeViewportList(), Isis::TableMainWindow::currentRow(), Isis::MdiCubeViewport::isLinked(), p_numRows, and p_tableWin.

Referenced by mouseMove(), and record().

void Isis::AdvancedTrackTool::updateRow ( MdiCubeViewport *  cvp, QPoint  p, int  row  )

privateslot

This method updates the row given with data from the viewport cvp at point p.

Parameters

cvp	CubeViewPort that contains p
p	QPoint from which the row will be updated
row	Row to be updated

Definition at line 242 of file AdvancedTrackTool.cpp.

References BAND, Isis::CubeViewport::camera(), Isis::Sensor::Coordinate(), Isis::CubeViewport::cube(), Isis::CubeViewport::cubeLines(), Isis::CubeViewport::cubeSamples(), Isis::Tool::cubeViewport(), DECLINATION, Isis::Sensor::Declination(), Isis::Angle::degrees(), DISTORTED_FOCAL_X, DISTORTED_FOCAL_Y, Isis::Camera::DistortionMap(), EAST_LON_180, EAST_LON_360, EMISSION, Isis::Sensor::EmissionAngle(), EPHEMERIS_TIME, FILENAME, Isis::Cube::fileName(), Isis::Camera::FocalPlaneMap(), Isis::CameraFocalPlaneMap::FocalPlaneX(), Isis::CameraFocalPlaneMap::FocalPlaneY(), Isis::CubeViewport::grayBand(), Isis::CubeViewport::grayPixel(), INCIDENCE, Isis::Sensor::IncidenceAngle(), Isis::Spice::instrumentPosition(), Isis::CubeViewport::isGray(), Isis::MdiCubeViewport::isLinked(), Isis::Projection::IsSky(), Isis::IsValidPixel(), LINE, LOCAL_EMISSION, LOCAL_INCIDENCE, Isis::Camera::LocalPhotometricAngles(), Isis::TProjection::LocalRadius(), Isis::Sensor::LocalRadius(), Isis::Sensor::LocalSolarTime(), Isis::TProjection::Longitude(), Isis::Distance::meters(), Isis::ShapeModel::name(), NORTH_AZIMUTH, Isis::Camera::NorthAzimuth(), p_id, p_tableWin, Isis::FileName::path(), PATH, PHASE, Isis::Sensor::PhaseAngle(), PIXEL, Isis::Camera::PixelResolution(), Isis::PixelToString(), PLANETOCENTRIC_LAT, PLANETOGRAPHIC_LAT, POINT_X, POINT_Y, POINT_Z, PROJECTED_X, PROJECTED_Y, Isis::CubeViewport::projection(), Isis::Projection::projectionType(), Isis::Spice::radii(), RADIUS, Isis::CubeViewport::redBand(), Isis::CubeViewport::redPixel(), RESOLUTION, RIGHT_ASCENSION, Isis::Sensor::RightAscension(), SAMPLE, Isis::Camera::SetImage(), Isis::Projection::SetWorld(), Isis::Target::shape(), SLANT, Isis::Sensor::SlantDistance(), SOLAR_LON, SOLAR_TIME, Isis::Spice::solarLongitude(), SPACECRAFT_AZIMUTH, SPACECRAFT_X, SPACECRAFT_Y, SPACECRAFT_Z, Isis::Camera::SpacecraftAzimuth(), SUN_AZIMUTH, Isis::Camera::SunAzimuth(), Isis::TableMainWindow::table(), Isis::Spice::target(), Isis::Spice::time(), Isis::RingPlaneProjection::To180Domain(), Isis::TProjection::To180Domain(), Isis::TProjection::ToPlanetographic(), TRACK_MOSAIC_FILENAME, TRACK_MOSAIC_INDEX, TRACK_MOSAIC_SERIAL_NUM, TrackMosaicOrigin(), Isis::Projection::Triaxial, UNDISTORTED_FOCAL_X, UNDISTORTED_FOCAL_Y, UNDISTORTED_FOCAL_Z, Isis::CameraDistortionMap::UndistortedFocalPlaneX(), Isis::CameraDistortionMap::UndistortedFocalPlaneY(), Isis::CameraDistortionMap::UndistortedFocalPlaneZ(), Isis::Sensor::UniversalLatitude(), Isis::TProjection::UniversalLatitude(), Isis::Sensor::UniversalLongitude(), Isis::TProjection::UniversalLongitude(), Isis::RingPlaneProjection::UniversalRingLongitude(), Isis::RingPlaneProjection::UniversalRingRadius(), UTC, Isis::CubeViewport::viewportToCube(), WEST_LON_180, WEST_LON_360, Isis::Projection::XCoord(), and Isis::Projection::YCoord().

void Isis::Tool::updateTool ( )

virtualslotinherited

Updates the tool.

Reimplemented in Isis::StretchTool, Isis::FindTool, Isis::FeatureNomenclatureTool, Isis::EditTool, Isis::FileTool, Isis::ZoomTool, Isis::MeasureTool, Isis::SpatialPlotTool, Isis::SpectralPlotTool, Isis::AbstractPlotTool, Isis::BandTool, Isis::SunShadowTool, Isis::SpecialPixelTool, Isis::BlinkTool, Isis::HistogramTool, and Isis::WindowTool.

Definition at line 317 of file Tool.cpp.

Referenced by Isis::Tool::enableToolBar(), and Isis::Tool::setCubeViewport().

void Isis::AdvancedTrackTool::writeSettings ( )

private

Write out this tool's preserved state between runs.

This is NOT called on close, so you should call this any time you change the preserved state.

Definition at line 749 of file AdvancedTrackTool.cpp.

References m_showHelpOnStart, and settingsFilePath().

Referenced by eventFilter().

Member Data Documentation

bool Isis::AdvancedTrackTool::m_showHelpOnStart

private

True to show dialog When tool is started.

Definition at line 179 of file AdvancedTrackTool.h.

Referenced by AdvancedTrackTool(), eventFilter(), readSettings(), and writeSettings().

QAction* Isis::AdvancedTrackTool::p_action

private

Action to bring up the track tool.

Definition at line 175 of file AdvancedTrackTool.h.

Referenced by addTo(), addToPermanent(), and AdvancedTrackTool().

int Isis::AdvancedTrackTool::p_id

private

The record id.

Definition at line 177 of file AdvancedTrackTool.h.

Referenced by AdvancedTrackTool(), record(), updateID(), and updateRow().

int Isis::AdvancedTrackTool::p_numRows

private

The number of rows in the table.

Definition at line 176 of file AdvancedTrackTool.h.

Referenced by mouseLeave(), record(), and updateRow().

TableMainWindow* Isis::AdvancedTrackTool::p_tableWin

private

The table window.

Definition at line 178 of file AdvancedTrackTool.h.

Referenced by AdvancedTrackTool(), helpDialog(), mouseLeave(), record(), updateID(), and updateRow().

---

The documentation for this class was generated from the following files:

• src/qisis/objs/AdvancedTrackTool/AdvancedTrackTool.h
• src/qisis/objs/AdvancedTrackTool/AdvancedTrackTool.cpp
