Isis::EditTool Class Reference

Interactive image edit tool. More...

#include <EditTool.h>

Inheritance diagram for Isis::EditTool:

Collaboration diagram for Isis::EditTool:

Public Types
enum	EditShape {   Point, HorizLine, VertLine, StartEndLine,   Rectangle }
	Enum for possible shapes. More...
enum	ReplacementValue {   UserDnComboValue, NullComboValue, HrsComboValue, LrsComboValue,   HisComboValue, LisComboValue }
	Enum for DN values. More...

Public Slots
void	activate (bool)
	Activates the tool.
void	setCubeViewport (MdiCubeViewport *cvp)
	Sets the current viewport to the given cvp.

Signals
void	cubeChanged (bool)
	Emitted when cube changed.
void	save ()
	Emitted when cube should be saved.
void	saveAs ()
	Emitted when cube should be saved as another file.
void	clearWarningSignal ()
void	toolActivated ()
void	viewportChanged ()

Public Member Functions
	EditTool (QWidget *parent)
	Constructs and EditTool object.
void	addTo (Workspace *)
	Adds the given workspace to the cubeviewport list.
void	addTo (ViewportMainWindow *mw)
	Adds the tool to the application.
void	addTo (ToolPad *toolpad)
	Adds the tool to the toolpad.
virtual void	addTo (QMenu *menu)
virtual QString	menuName () const
	Anytime a tool is created, you must give it a name for the menu.
virtual void	addToPermanent (QToolBar *toolbar)
void	addToActive (QToolBar *toolbar)
QString	toolIconDir () const
	returns the path to the icon directory.
virtual void	paintViewport (MdiCubeViewport *vp, QPainter *painter)
RubberBandTool *	rubberBandTool ()
void	setList (ToolList *currentList)

Protected Types
typedef QVector < MdiCubeViewport * >	CubeViewportList
	A list of cubeviewports.

Protected Slots
void	mouseButtonRelease (QPoint p, Qt::MouseButton m)
	This is a slot called when any mouse button is released inside of a viewport.
virtual void	enableRubberBandTool ()
	This method sets up the RubberBandTool depending on which mode is enabled.
void	rubberBandComplete ()
	This method is called any time the RubberBandTool is complete.
virtual void	screenPixelsChanged ()
	This is called when actions change which pixels from the cube are displayed.
virtual void	mouseEnter ()
virtual void	mouseMove (QPoint p)
virtual void	mouseMove (QPoint p, Qt::MouseButton)
virtual void	mouseLeave ()
virtual void	mouseDoubleClick (QPoint p)
virtual void	mouseButtonPress (QPoint p, Qt::MouseButton s)
virtual void	updateMeasure ()
virtual void	scaleChanged ()
virtual void	stretchRequested (MdiCubeViewport *, int)
void	registerTool (MdiCubeViewport *viewport)
	Registers the tool to the viewport.

Protected Member Functions
QAction *	toolPadAction (ToolPad *pad)
	Adds the EditTool to the tool pad.
QWidget *	createToolBarWidget (QStackedWidget *active)
	Creates the toolbar containing the edit tool widgets.
void	updateTool ()
	This is a virtual function belonging to the Tool class which is called when the user selects a different viewport.
MdiCubeViewport *	cubeViewport () const
	Return the current cubeviewport.
CubeViewportList *	cubeViewportList () const
	Return the list of cubeviewports.
virtual void	addConnections (MdiCubeViewport *cvp)
	Anytime a tool is created, you must add the connections for it.
virtual void	removeConnections (MdiCubeViewport *cvp)
	Anytime a tool is created, you must be able to remove it's connections.
Workspace *	workspace ()

Private Slots
void	listenToViewport (MdiCubeViewport *)
void	selectValType (int index)
	This is a private slot which is called when the user selects a new dn type.
void	changeDn ()
	This is a private slot called when the user hits the enter key after typing a value in the dnLineEdit field.
void	undoEdit ()
	This is a private slot called when the user selects the undo button.
void	undoAll (CubeViewport *vp)
	This method is used to discard any changes made to this viewport.
void	redoEdit ()
	This method is called to redo any edit operations that have been undone.
void	save (CubeViewport *vp)
	This method saves by removing any undo history for the viewport vp and reopening the cube.
void	removeViewport (QObject *vp)
	This is a private slot called to clean up when a viewport is destroyed.

Private Member Functions
QList< QPoint * > *	LineToPoints (const QLine &line)
	Convert rubber band line to points.
void	writeToCube (int iesamp, int issamp, int ieline, int isline, QList< QPoint * > *linePts)

Private Attributes
QComboBox *	p_shapeComboBox
	Shape combobox.
QComboBox *	p_valTypeComboBox
	Value type combobox.
QLineEdit *	p_dnLineEdit
	DN edit line.
QToolButton *	p_undoButton
	Undo button.
QToolButton *	p_redoButton
	Redo button.
QToolButton *	p_saveButton
	Save button.
QToolButton *	p_saveAsButton
	Save as button.
QWidget *	m_container
double	p_dn
	DN value.
QMap< CubeViewport *, QStack < Brick * > * >	p_undoEdit
	Viewport to brick map for undo.
QMap< CubeViewport *, QStack < Brick * > * >	p_redoEdit
	Viewport to brick map for redo.
QMap< CubeViewport *, int >	p_saveMarker
	Marker for last save.

Detailed Description

Interactive image edit tool.

This tool is part of the Qisis namespace and allows interactive editing of displayed images.

Author

2006-06-09 Tracie Sucharski

History:

2006-10-20 Tracie Sucharski - If rubberband for rectangle option goes off the right side or bottom of image, set esamp/eline to image nsamps/nlines.

History:

2008-05-23 Noah Hilt - Added RubberBandToolfunctionality and changed the mouseButtonReleased method. Also added a writeToCube method that is used by both the rubberBandComplete and mouseButtonRelease methods.

History:

2008-06-19 Noah Hilt - Added methods and signals for saving and discarding changes to the current cube.

History:

2010-06-26 Eric Hyer - uses MdiCubeViewport instead of CubeViewport. Fixed many include issues but some still remain!

History:

2010-11-15 Eric Hyer - valid rectangle dimensions for banding must now be >= 1 instead of >= 5

History:

2011-09-15 Steven Lambright - Enumerated values no longer conflict with global variable names and increased safety with usage of the valType combo box to make it less likely to break in the future. Fixes #345.

History:

2012-05-24 Steven Lambright - Minor changes to support prompting to save on exit once again (this has been broken for a very long time). The prompt now appears if you have edited your file but not saved it - not when clicking "Save." This was a minimal fix (I left a lot of problems to be solved at a later date). Fixes #854.

Definition at line 80 of file EditTool.h.

Member Typedef Documentation

typedef QVector< MdiCubeViewport * > Isis::Tool::CubeViewportList

protectedinherited

A list of cubeviewports.

Definition at line 219 of file Tool.h.

Member Enumeration Documentation

enum Isis::EditTool::EditShape

Enum for possible shapes.

Enumerator:

Point	point
HorizLine	horizontal line
VertLine	vertical line
StartEndLine	start-end line
Rectangle	rectangle

Definition at line 87 of file EditTool.h.

enum Isis::EditTool::ReplacementValue

Enum for DN values.

Enumerator:

UserDnComboValue	User Selected DN value.
NullComboValue	Null DN value.
HrsComboValue	High representation saturation DN value.
LrsComboValue	Low representation saturation DN value.
HisComboValue	High instrument saturation DN value.
LisComboValue	Low instrument satruation DN value.

Definition at line 99 of file EditTool.h.

Constructor & Destructor Documentation

Isis::EditTool::EditTool

(

QWidget *

parent

)

Constructs and EditTool object.

Parameters

parent

Parent widget

Definition at line 55 of file EditTool.cpp.

References Isis::Null, and p_dn.

Member Function Documentation

void Isis::Tool::activate ( bool  on )

slotinherited

Activates the tool.

Parameters

on

Definition at line 130 of file Tool.cpp.

References Isis::Tool::addViewportConnections(), Isis::Tool::disableToolBar(), Isis::Tool::enableToolBar(), Isis::Tool::m_active, Isis::Tool::m_toolPadAction, and Isis::Tool::removeViewportConnections().

Referenced by Isis::Tool::addTo(), Isis::AdvancedTrackTool::AdvancedTrackTool(), Isis::RubberBandTool::disable(), Isis::RubberBandTool::enable(), Isis::AdvancedTrackTool::eventFilter(), Isis::FileTool::FileTool(), Isis::RubberBandTool::RubberBandTool(), Isis::TrackTool::TrackTool(), Isis::WindowTool::WindowTool(), and Isis::Workspace::Workspace().

virtual void Isis::Tool::addConnections ( MdiCubeViewport *  cvp )

inlineprotectedvirtualinherited

Anytime a tool is created, you must add the connections for it.

Parameters

cvp

Reimplemented in Isis::TrackTool, and Isis::WindowTool.

Definition at line 253 of file Tool.h.

Referenced by Isis::Tool::addViewportConnections().

void Isis::Tool::addTo ( ViewportMainWindow *  pViewPortMnWin )

inherited

Adds the tool to the application.

Parameters

pViewPortMnWin

Definition at line 77 of file Tool.cpp.

References Isis::ViewportMainWindow::activeToolBar(), Isis::Tool::addToActive(), Isis::Tool::addToPermanent(), Isis::ViewportMainWindow::getMenu(), Isis::Tool::menuName(), Isis::ViewportMainWindow::permanentToolBar(), Isis::ViewportMainWindow::toolPad(), and Isis::ViewportMainWindow::workspace().

Referenced by Isis::ViewportMainWindow::ViewportMainWindow(), and Isis::Workspace::Workspace().

void Isis::Tool::addTo ( ToolPad *  toolpad )

inherited

Adds the tool to the toolpad.

Parameters

toolpad

Definition at line 97 of file Tool.cpp.

References Isis::Tool::activate(), Isis::ToolPad::addAction(), Isis::Tool::m_toolPadAction, and Isis::Tool::toolPadAction().

virtual void Isis::Tool::addTo ( QMenu *  menu )

inlinevirtualinherited

Parameters

menu

Reimplemented in Isis::FindTool, Isis::FeatureNomenclatureTool, Isis::StretchTool, Isis::QnetFileTool, Isis::AdvancedTrackTool, Isis::ZoomTool, Isis::SpectralPlotTool, Isis::MeasureTool, Isis::FileTool, Isis::SunShadowTool, Isis::HelpTool, Isis::SpecialPixelTool, Isis::BlinkTool, Isis::WindowTool, and Isis::PanTool.

Definition at line 105 of file Tool.h.

void Isis::EditTool::addTo ( Workspace *  ws )

virtual

Adds the given workspace to the cubeviewport list.

Parameters

ws

Reimplemented from Isis::Tool.

Definition at line 59 of file EditTool.cpp.

void Isis::Tool::addToActive ( QToolBar *  toolbar )

inherited

Parameters

toolbar

Definition at line 111 of file Tool.cpp.

References Isis::Tool::createToolBarWidget(), Isis::Tool::disableToolBar(), and Isis::Tool::m_toolBarWidget.

Referenced by Isis::Tool::addTo(), and Isis::Workspace::Workspace().

virtual void Isis::Tool::addToPermanent ( QToolBar *  toolbar )

inlinevirtualinherited

Parameters

toolbar

Reimplemented in Isis::AdvancedTrackTool, Isis::FileTool, Isis::HelpTool, Isis::SpecialPixelTool, Isis::BlinkTool, and Isis::WindowTool.

Definition at line 111 of file Tool.h.

Referenced by Isis::Tool::addTo(), and Isis::Workspace::Workspace().

void Isis::EditTool::changeDn ( )

privateslot

This is a private slot called when the user hits the enter key after typing a value in the dnLineEdit field.

Definition at line 231 of file EditTool.cpp.

References p_dn, and p_dnLineEdit.

Referenced by createToolBarWidget().

QWidget * Isis::EditTool::createToolBarWidget ( QStackedWidget *  active )

protectedvirtual

Creates the toolbar containing the edit tool widgets.

Parameters

active

input The widget that will contain the edit tool specific widgets

History:

2007-08-31 Tracie Sucharski - Changed signal on dn line edit from returnPressed to editingFinished.

Returns

QWidget*

Reimplemented from Isis::Tool.

Definition at line 98 of file EditTool.cpp.

References changeDn(), enableRubberBandTool(), HisComboValue, HrsComboValue, LisComboValue, LrsComboValue, NullComboValue, p_dnLineEdit, p_redoButton, p_saveAsButton, p_saveButton, p_shapeComboBox, p_undoButton, p_valTypeComboBox, redoEdit(), save(), saveAs(), selectValType(), Isis::Tool::toolIconDir(), undoEdit(), and UserDnComboValue.

void Isis::EditTool::cubeChanged ( bool  )

signal

Emitted when cube changed.

Referenced by redoEdit(), undoEdit(), and writeToCube().

MdiCubeViewport* Isis::Tool::cubeViewport ( ) const

inlineprotectedinherited

Return the current cubeviewport.

Returns

CubeViewport*

Definition at line 211 of file Tool.h.

References Isis::Tool::m_cvp.

Referenced by Isis::WindowTool::addConnections(), Isis::TrackTool::addConnections(), Isis::StretchTool::advancedStretchChanged(), Isis::FindTool::centerLinkedViewports(), Isis::StretchTool::changeStretch(), Isis::BandTool::changeView(), Isis::BandTool::copyLinkedViewports(), Isis::FileTool::discard(), Isis::Tool::enableToolBar(), Isis::FileTool::exportView(), Isis::StatisticsTool::getStatistics(), Isis::FindTool::handleRecordClicked(), LineToPoints(), Isis::TrackTool::locateCursor(), Isis::SunShadowTool::mouseButtonPress(), Isis::RubberBandTool::mouseButtonRelease(), mouseButtonRelease(), Isis::FeatureNomenclatureTool::mouseButtonRelease(), Isis::FindTool::mouseButtonRelease(), Isis::StretchTool::mouseButtonRelease(), Isis::MatchTool::mouseButtonRelease(), Isis::QnetTool::mouseButtonRelease(), Isis::AdvancedTrackTool::mouseLeave(), Isis::ScatterPlotTool::mouseMove(), Isis::SunShadowTool::mouseMove(), Isis::TrackTool::mouseMove(), Isis::RubberBandTool::mouseMove(), Isis::SunShadowTool::paintViewport(), Isis::RubberBandTool::paintViewport(), Isis::FindTool::paintViewport(), Isis::FileTool::print(), Isis::SunShadowTool::recalculateShadowHeight(), redoEdit(), Isis::FindTool::refresh(), Isis::HistogramTool::refreshPlot(), Isis::SpatialPlotTool::refreshPlot(), Isis::SpectralPlotTool::refreshPlot(), Isis::WindowTool::removeConnections(), Isis::TrackTool::removeConnections(), Isis::RubberBandTool::repaint(), Isis::WindowTool::resizeWindows(), Isis::HistogramTool::rubberBandComplete(), Isis::MeasureTool::rubberBandComplete(), Isis::ZoomTool::rubberBandComplete(), rubberBandComplete(), Isis::StretchTool::rubberBandComplete(), Isis::FileTool::save(), Isis::FileTool::saveAs(), Isis::FileTool::saveAsCubeByOption(), Isis::FileTool::saveAsReducedCube(), Isis::FileTool::saveInfo(), Isis::BandTool::setBandBin(), Isis::BandTool::setList(), Isis::StretchTool::setStretchAcrossBands(), Isis::StretchTool::setStretchAllViewports(), Isis::StretchTool::showAdvancedDialog(), Isis::ScatterPlotTool::showNewScatterPlotConfig(), Isis::StretchTool::stretchChanged(), Isis::StretchTool::stretchGlobal(), Isis::StretchTool::stretchGlobalAllBands(), Isis::StretchTool::stretchRegional(), undoEdit(), Isis::StretchTool::updateAdvStretchDialogforAll(), Isis::StretchTool::updateHistograms(), Isis::TrackTool::updateLabels(), Isis::MeasureTool::updateMeasure(), Isis::AdvancedTrackTool::updateRow(), Isis::WindowTool::updateTool(), Isis::BlinkTool::updateTool(), Isis::SpecialPixelTool::updateTool(), Isis::BandTool::updateTool(), Isis::SunShadowTool::updateTool(), Isis::AbstractPlotTool::updateTool(), Isis::ZoomTool::updateTool(), Isis::FileTool::updateTool(), updateTool(), Isis::FindTool::updateTool(), Isis::StretchTool::updateTool(), Isis::AbstractPlotTool::viewportsToPlot(), writeToCube(), Isis::ZoomTool::zoomBy(), Isis::ZoomTool::zoomFit(), Isis::ZoomTool::zoomFitHeight(), Isis::ZoomTool::zoomFitWidth(), and Isis::ZoomTool::zoomManual().

Tool::CubeViewportList * Isis::Tool::cubeViewportList ( ) const

protectedinherited

Return the list of cubeviewports.

Returns

CubeViewportList*

Definition at line 389 of file Tool.cpp.

References Isis::Workspace::cubeViewportList().

Referenced by Isis::BlinkTool::advance(), Isis::SpecialPixelTool::apply(), Isis::FindTool::centerLinkedViewports(), Isis::WindowTool::changeCursor(), Isis::FileTool::closeAll(), Isis::BandTool::copyAllViewports(), Isis::BandTool::copyLinkedViewports(), Isis::MatchTool::createPoint(), Isis::BlinkTool::eventFilter(), Isis::FeatureNomenclatureTool::featuresIdentified(), Isis::FeatureNomenclatureTool::findMissingNomenclature(), Isis::FeatureNomenclatureTool::findNomenclatureStateChanged(), Isis::FindTool::handleLinkClicked(), Isis::WindowTool::linkWindows(), Isis::RubberBandTool::mouseButtonRelease(), Isis::RubberBandTool::mouseMove(), Isis::QnetTool::openGround(), Isis::StereoTool::paintAllViewports(), Isis::MatchTool::paintAllViewports(), Isis::QnetTool::paintAllViewports(), Isis::FindTool::refresh(), Isis::ScatterPlotTool::repaintViewports(), Isis::AbstractPlotTool::repaintViewports(), Isis::WindowTool::resizeWindows(), Isis::BlinkTool::reverse(), Isis::ZoomTool::rubberBandComplete(), Isis::MatchTool::serialNumberList(), Isis::FeatureNomenclatureTool::setFontColor(), Isis::FeatureNomenclatureTool::setFontSize(), Isis::FeatureNomenclatureTool::setShowApprovedOnly(), Isis::StretchTool::setStretchAllViewports(), Isis::FeatureNomenclatureTool::setVectorType(), Isis::StretchTool::stretchGlobalAllViewports(), Isis::BlinkTool::toggleLink(), Isis::WindowTool::unlinkWindows(), Isis::MeasureTool::updateMeasure(), Isis::AdvancedTrackTool::updateRow(), Isis::WindowTool::updateTool(), Isis::BlinkTool::updateTool(), Isis::FindTool::updateTool(), Isis::AbstractPlotTool::viewportsToPlot(), Isis::ZoomTool::zoomBy(), Isis::ZoomTool::zoomFit(), Isis::ZoomTool::zoomFitHeight(), Isis::ZoomTool::zoomFitWidth(), and Isis::ZoomTool::zoomManual().

void Isis::EditTool::enableRubberBandTool ( )

protectedvirtualslot

This method sets up the RubberBandTool depending on which mode is enabled.

If a valid RubberBandTool mode is not enabled the RubberBandTool is disabled.

Definition at line 928 of file EditTool.cpp.

References Isis::RubberBandTool::disable(), Isis::RubberBandTool::enable(), p_shapeComboBox, and Isis::RubberBandTool::setDrawActiveViewportOnly().

Referenced by createToolBarWidget().

QList< QPoint * > * Isis::EditTool::LineToPoints ( const QLine &  line )

private

Convert rubber band line to points.

This routine takes two points (sx,sy) and (ex,ey) and determines all the points which make up that line segment. This is useful for drawing graphic on a display or image

Author

Jan 1 1996 Jeff Anderson, Original version

Parameters

line	input Line to be converted to points

Returns

QList<QPoint*>* A pointer to a QList of points representing line

Definition at line 844 of file EditTool.cpp.

References Isis::CubeViewport::cubeLines(), and Isis::Tool::cubeViewport().

Referenced by rubberBandComplete().

virtual QString Isis::Tool::menuName ( ) const

inlinevirtualinherited

Anytime a tool is created, you must give it a name for the menu.

Returns

QString

Reimplemented in Isis::FindTool, Isis::StretchTool, Isis::FeatureNomenclatureTool, Isis::AdvancedTrackTool, Isis::ZoomTool, Isis::FileTool, Isis::MeasureTool, Isis::BandTool, Isis::HelpTool, Isis::SpecialPixelTool, Isis::BlinkTool, Isis::WindowTool, and Isis::PanTool.

Definition at line 97 of file Tool.h.

Referenced by Isis::Tool::addTo(), and Isis::Workspace::Workspace().

void Isis::Tool::mouseButtonPress ( QPoint  p, Qt::MouseButton  s  )

protectedvirtualslotinherited

Parameters

p
s

Definition at line 366 of file Tool.cpp.

Referenced by Isis::Tool::addViewportConnections(), and Isis::Tool::removeViewportConnections().

void Isis::EditTool::mouseButtonRelease ( QPoint  p, Qt::MouseButton  m  )

protectedslot

This is a slot called when any mouse button is released inside of a viewport.

Parameters

p	input The point under the cursor
m	input Mouse button released (left,middle,right)

History:

2007-03-02 Tracie Sucharski - Reopen cube read/write Workspace::addCubeViewport was opening cube read/write, changed to open read only so that the cube date was not changed unless EditTool is invoked.

History:

2007-02-26 Tracie Sucharski - Remove test for off image editing. It is no longer needed since the bug in the Cube class is fixed.

History:

2008-05-23 Noah Hilt - Removed the rectangle and start/end line functionality from the mouseButtonRelease and moved it to the rubberBandComplete method.

Definition at line 404 of file EditTool.cpp.

References Isis::CubeViewport::cube(), Isis::CubeViewport::cubeLines(), Isis::CubeViewport::cubeSamples(), Isis::Tool::cubeViewport(), Isis::CubeViewport::grayBand(), HorizLine, Isis::CubeViewport::isColor(), Isis::Cube::isReadOnly(), Isis::Cube::lineCount(), p_dn, p_dnLineEdit, p_shapeComboBox, p_valTypeComboBox, Isis::Cube::pixelType(), Point, Isis::Cube::read(), Isis::Cube::reopen(), Isis::Cube::sampleCount(), Isis::Brick::SetBasePosition(), UserDnComboValue, VertLine, Isis::CubeViewport::viewportToCube(), and writeToCube().

void Isis::Tool::mouseDoubleClick ( QPoint  p )

protectedvirtualslotinherited

Parameters

p

Definition at line 357 of file Tool.cpp.

Referenced by Isis::Tool::addViewportConnections(), and Isis::Tool::removeViewportConnections().

void Isis::Tool::mouseMove ( QPoint  p )

protectedvirtualslotinherited

Parameters

p

Definition at line 351 of file Tool.cpp.

Referenced by Isis::Tool::addViewportConnections(), and Isis::Tool::removeViewportConnections().

virtual void Isis::Tool::paintViewport ( MdiCubeViewport *  vp, QPainter *  painter  )

inlinevirtualinherited

Parameters

vp
painter

Reimplemented in Isis::QnetTool, Isis::MatchTool, Isis::FindTool, Isis::FeatureNomenclatureTool, Isis::RubberBandTool, Isis::StereoTool, Isis::SunShadowTool, Isis::AbstractPlotTool, and Isis::ScatterPlotTool.

Definition at line 136 of file Tool.h.

void Isis::EditTool::redoEdit ( )

privateslot

This method is called to redo any edit operations that have been undone.

Definition at line 705 of file EditTool.cpp.

References Isis::CubeViewport::cube(), cubeChanged(), Isis::CubeViewport::cubeChanged(), Isis::CubeViewport::cubeContentsChanged(), Isis::Tool::cubeViewport(), Isis::CubeViewport::grayBand(), Isis::Cube::isReadOnly(), Isis::Buffer::Line(), Isis::Buffer::LineDimension(), p_redoButton, p_redoEdit, p_saveButton, p_undoButton, p_undoEdit, Isis::Cube::pixelType(), Isis::Cube::read(), Isis::Buffer::Sample(), Isis::Buffer::SampleDimension(), Isis::Brick::SetBasePosition(), Isis::CubeViewport::setCaption(), and Isis::Cube::write().

Referenced by createToolBarWidget().

void Isis::Tool::registerTool ( MdiCubeViewport *  viewport )

protectedslotinherited

Registers the tool to the viewport.

Parameters

viewport

Definition at line 326 of file Tool.cpp.

References Isis::Tool::m_cvp, and Isis::MdiCubeViewport::registerTool().

Referenced by Isis::Tool::addTo().

virtual void Isis::Tool::removeConnections ( MdiCubeViewport *  cvp )

inlineprotectedvirtualinherited

Anytime a tool is created, you must be able to remove it's connections.

Parameters

cvp

Reimplemented in Isis::MeasureTool, Isis::TrackTool, and Isis::WindowTool.

Definition at line 261 of file Tool.h.

Referenced by Isis::Tool::removeViewportConnections().

void Isis::EditTool::removeViewport ( QObject *  vp )

privateslot

This is a private slot called to clean up when a viewport is destroyed.

This viewport is removed from the undoEdit hash.

Parameters

vp	input Viewport to be removed from the undo edit hash

Definition at line 808 of file EditTool.cpp.

References p_redoEdit, and p_undoEdit.

void Isis::EditTool::rubberBandComplete ( )

protectedslot

This method is called any time the RubberBandTool is complete.

It checks if the viewport is writable, checks which mode it is in, either line or rectangle, and if RubberBandTool is valid. It then writes the data from the RubberBandTool to the cube.

Definition at line 277 of file EditTool.cpp.

References Isis::CubeViewport::cube(), Isis::CubeViewport::cubeLines(), Isis::CubeViewport::cubeSamples(), Isis::Tool::cubeViewport(), Isis::CubeViewport::isColor(), Isis::Cube::isReadOnly(), Isis::RubberBandTool::isValid(), LineToPoints(), p_shapeComboBox, Isis::RubberBandTool::rectangle(), Rectangle, Isis::Cube::reopen(), StartEndLine, Isis::CubeViewport::viewportToCube(), and writeToCube().

void Isis::EditTool::save ( )

signal

Emitted when cube should be saved.

Referenced by createToolBarWidget().

void Isis::EditTool::save ( CubeViewport *  vp )

privateslot

This method saves by removing any undo history for the viewport vp and reopening the cube.

These changes are finalized! There is no undoing after a save has been made.

Parameters

vp

Definition at line 781 of file EditTool.cpp.

References Isis::CubeViewport::cubeChanged(), p_saveButton, p_saveMarker, p_undoEdit, and Isis::CubeViewport::setCaption().

void Isis::EditTool::saveAs ( )

signal

Emitted when cube should be saved as another file.

Referenced by createToolBarWidget().

virtual void Isis::Tool::screenPixelsChanged ( )

inlineprotectedvirtualslotinherited

This is called when actions change which pixels from the cube are displayed.

Definition at line 162 of file Tool.h.

Referenced by Isis::Tool::addViewportConnections(), Isis::Tool::removeViewportConnections(), and Isis::FeatureNomenclatureTool::viewportDone().

void Isis::EditTool::selectValType ( int  index )

privateslot

This is a private slot which is called when the user selects a new dn type.

Parameters

index

input This is the index selected in the valType combo box

Definition at line 211 of file EditTool.cpp.

References Isis::His, HisComboValue, Isis::Hrs, HrsComboValue, Isis::Lis, LisComboValue, Isis::Lrs, LrsComboValue, Isis::Null, NullComboValue, p_dn, p_dnLineEdit, p_valTypeComboBox, and UserDnComboValue.

Referenced by createToolBarWidget().

void Isis::Tool::setCubeViewport ( MdiCubeViewport *  cvp )

slotinherited

Sets the current viewport to the given cvp.

Parameters

cvp

Definition at line 159 of file Tool.cpp.

References Isis::Tool::addViewportConnections(), Isis::Tool::enableToolBar(), Isis::Tool::m_active, Isis::Tool::m_cvp, Isis::Tool::removeViewportConnections(), and Isis::Tool::updateTool().

Referenced by Isis::Tool::addTo(), and Isis::FileTool::closeAll().

QString Isis::Tool::toolIconDir ( ) const

inlineinherited

returns the path to the icon directory.

Returns

QString

Definition at line 127 of file Tool.h.

References Isis::Tool::m_toolIconDir.

Referenced by Isis::AdvancedTrackTool::AdvancedTrackTool(), Isis::BlinkTool::BlinkTool(), Isis::MatchTool::createActions(), Isis::QnetTool::createActions(), Isis::StereoTool::createMenus(), Isis::PanTool::createToolBarWidget(), Isis::BandTool::createToolBarWidget(), Isis::StereoTool::createToolBarWidget(), Isis::ZoomTool::createToolBarWidget(), createToolBarWidget(), Isis::FindTool::createToolBarWidget(), Isis::StretchTool::createToolBarWidget(), Isis::FileTool::FileTool(), Isis::FindTool::FindTool(), Isis::HistogramTool::HistogramTool(), Isis::SpecialPixelTool::SpecialPixelTool(), Isis::RubberBandComboBox::toolIconDir(), Isis::PanTool::toolPadAction(), Isis::HistogramTool::toolPadAction(), Isis::ScatterPlotTool::toolPadAction(), Isis::SunShadowTool::toolPadAction(), Isis::BandTool::toolPadAction(), Isis::SpectralPlotTool::toolPadAction(), Isis::SpatialPlotTool::toolPadAction(), Isis::StereoTool::toolPadAction(), Isis::MeasureTool::toolPadAction(), Isis::ZoomTool::toolPadAction(), toolPadAction(), Isis::FeatureNomenclatureTool::toolPadAction(), Isis::StatisticsTool::toolPadAction(), Isis::FindTool::toolPadAction(), Isis::StretchTool::toolPadAction(), Isis::MatchTool::toolPadAction(), Isis::QnetTool::toolPadAction(), Isis::WindowTool::WindowTool(), and Isis::ZoomTool::ZoomTool().

QAction * Isis::EditTool::toolPadAction ( ToolPad *  pad )

protectedvirtual

Adds the EditTool to the tool pad.

Parameters

pad	input The tool pad that EditTool is to be added to

Returns

QAction*

Reimplemented from Isis::Tool.

Definition at line 73 of file EditTool.cpp.

References Isis::Tool::toolIconDir().

void Isis::EditTool::undoAll ( CubeViewport *  vp )

privateslot

This method is used to discard any changes made to this viewport.

If the viewport has been saved, then it will only discard changes to that save point.

Parameters

vp

Definition at line 646 of file EditTool.cpp.

References Isis::Buffer::at(), Isis::CubeViewport::cube(), Isis::Cube::isReadOnly(), p_redoEdit, p_saveMarker, p_undoEdit, and Isis::Cube::write().

void Isis::EditTool::undoEdit ( )

privateslot

This is a private slot called when the user selects the undo button.

With each call, another edit is reversed.

Definition at line 570 of file EditTool.cpp.

References Isis::CubeViewport::cube(), cubeChanged(), Isis::CubeViewport::cubeChanged(), Isis::CubeViewport::cubeContentsChanged(), Isis::Tool::cubeViewport(), Isis::CubeViewport::grayBand(), Isis::Cube::isReadOnly(), Isis::Buffer::Line(), Isis::Buffer::LineDimension(), p_redoButton, p_redoEdit, p_saveButton, p_undoButton, p_undoEdit, Isis::Cube::pixelType(), Isis::Cube::read(), Isis::Buffer::Sample(), Isis::Buffer::SampleDimension(), Isis::Brick::SetBasePosition(), Isis::CubeViewport::setCaption(), and Isis::Cube::write().

Referenced by createToolBarWidget().

void Isis::EditTool::updateTool ( )

protectedvirtual

This is a virtual function belonging to the Tool class which is called when the user selects a different viewport.

This sets up the signal/slot for destruction of a viewport so the viewport is removed from the undoEdit hash.

Reimplemented from Isis::Tool.

Definition at line 243 of file EditTool.cpp.

References Isis::Tool::cubeViewport(), p_redoButton, p_redoEdit, p_saveButton, p_undoButton, and p_undoEdit.

void Isis::EditTool::writeToCube ( int  iesamp, int  issamp, int  ieline, int  isline, QList< QPoint * > *  linePts  )

private

Parameters

iesamp	input
issamp	input
ieline	input
isline	input
linePts	input If the input data is a line, this will be the list of points in the line.

Definition at line 487 of file EditTool.cpp.

References Isis::CubeViewport::cube(), cubeChanged(), Isis::CubeViewport::cubeChanged(), Isis::CubeViewport::cubeContentsChanged(), Isis::Tool::cubeViewport(), Isis::CubeViewport::grayBand(), Isis::Buffer::Line(), Isis::Buffer::LineDimension(), p_dn, p_redoButton, p_redoEdit, p_saveButton, p_shapeComboBox, p_undoButton, p_undoEdit, Isis::Cube::pixelType(), Isis::Cube::read(), Isis::Buffer::Sample(), Isis::Buffer::SampleDimension(), Isis::Brick::SetBasePosition(), Isis::CubeViewport::setCaption(), Isis::Buffer::size(), StartEndLine, and Isis::Cube::write().

Referenced by mouseButtonRelease(), and rubberBandComplete().

Member Data Documentation

double Isis::EditTool::p_dn

private

DN value.

Definition at line 148 of file EditTool.h.

Referenced by changeDn(), EditTool(), mouseButtonRelease(), selectValType(), and writeToCube().

QLineEdit* Isis::EditTool::p_dnLineEdit

private

DN edit line.

Definition at line 142 of file EditTool.h.

Referenced by changeDn(), createToolBarWidget(), mouseButtonRelease(), and selectValType().

QToolButton* Isis::EditTool::p_redoButton

private

Redo button.

Definition at line 144 of file EditTool.h.

Referenced by createToolBarWidget(), redoEdit(), undoEdit(), updateTool(), and writeToCube().

QMap<CubeViewport *, QStack <Brick *> *> Isis::EditTool::p_redoEdit

private

Viewport to brick map for redo.

Definition at line 151 of file EditTool.h.

Referenced by redoEdit(), removeViewport(), undoAll(), undoEdit(), updateTool(), and writeToCube().

QToolButton* Isis::EditTool::p_saveAsButton

private

Save as button.

Definition at line 146 of file EditTool.h.

Referenced by createToolBarWidget().

QToolButton* Isis::EditTool::p_saveButton

private

Save button.

Definition at line 145 of file EditTool.h.

Referenced by createToolBarWidget(), redoEdit(), save(), undoEdit(), updateTool(), and writeToCube().

QMap<CubeViewport *, int> Isis::EditTool::p_saveMarker

private

Marker for last save.

Definition at line 152 of file EditTool.h.

Referenced by save(), and undoAll().

QComboBox* Isis::EditTool::p_shapeComboBox

private

Shape combobox.

Definition at line 140 of file EditTool.h.

Referenced by createToolBarWidget(), enableRubberBandTool(), mouseButtonRelease(), rubberBandComplete(), and writeToCube().

QToolButton* Isis::EditTool::p_undoButton

private

Undo button.

Definition at line 143 of file EditTool.h.

Referenced by createToolBarWidget(), redoEdit(), undoEdit(), updateTool(), and writeToCube().

QMap<CubeViewport *, QStack <Brick *> *> Isis::EditTool::p_undoEdit

private

Viewport to brick map for undo.

Definition at line 150 of file EditTool.h.

Referenced by redoEdit(), removeViewport(), save(), undoAll(), undoEdit(), updateTool(), and writeToCube().

QComboBox* Isis::EditTool::p_valTypeComboBox

private

Value type combobox.

Definition at line 141 of file EditTool.h.

Referenced by createToolBarWidget(), mouseButtonRelease(), and selectValType().

---

The documentation for this class was generated from the following files:

• src/qisis/objs/EditTool/EditTool.h
• src/qisis/objs/EditTool/EditTool.cpp
