MESSENGER MDIS NAC and WAC Camera Model. More...

#include <MdisCamera.h>

Inheritance diagram for Isis::MdisCamera:

Collaboration diagram for Isis::MdisCamera:

Public Types
enum	CameraType { Framing, PushFrame, LineScan, Radar, Point }
	This enum defines the types of cameras supported in this class. More...

Public Member Functions
	MdisCamera (Cube &cube)
	Initialize the MDIS camera model for NAC and WAC.
	~MdisCamera ()
	Destroys the MdisCamera Object.
virtual std::pair< iTime, iTime >	ShutterOpenCloseTimes (double time, double exposureDuration)
	Returns the shutter open and close times.
virtual int	CkFrameId () const
	CK frame ID - - MESSENGER instrument code (MSGR_SPACECRAFT)
virtual int	CkReferenceId () const
	CK Reference ID - J2000.
virtual int	SpkTargetId () const
	SPK Target Body ID - MESSENGER spacecraft -236.
virtual int	SpkReferenceId () const
	SPK Reference ID - J2000.
virtual CameraType	GetCameraType () const
	This method returns Framing camera type.
bool	SetImage (const double sample, const double line)
	Sets the sample/line values of the image to get the lat/lon values.
bool	SetUniversalGround (const double latitude, const double longitude)
	Sets the lat/lon values to get the sample/line values.
bool	SetUniversalGround (const double latitude, const double longitude, const double radius)
	Sets the lat/lon/radius values to get the sample/line values.
bool	SetUniversalGround (const double latitude, const double longitude, bool backCheck=true)
	This is the opposite routine for SetLookDirection.
bool	SetUniversalGround (const double latitude, const double longitude, const double radius, bool backCheck=true)
	This overloaded method has the opposite function as SetLookDirection.
bool	SetGround (Latitude latitude, Longitude longitude)
	Sets the lat/lon values to get the sample/line values.
bool	SetGround (const SurfacePoint &surfacePt)
	Sets the lat/lon/radius values to get the sample/line values.
bool	SetGround (const SurfacePoint &surfacePt, bool backCheck=true)
	This overloaded method has the opposite function as SetLookDirection.
bool	SetRightAscensionDeclination (const double ra, const double dec)
	Sets the right ascension declination.
void	LocalPhotometricAngles (Angle &phase, Angle &incidence, Angle &emission, bool &success)
	Calculates LOCAL photometric angles using the DEM (not ellipsoid).
void	GetLocalNormal (double normal[3])
	This method will find the local normal at the current (sample, line) and set it to the passed in array.
bool	HasProjection ()
	Checks to see if the camera object has a projection.
virtual bool	IsBandIndependent ()
	Virtual method that checks if the band is independent.
int	ReferenceBand () const
	Returns the reference band.
bool	HasReferenceBand () const
	Checks to see if the Camera object has a reference band.
virtual void	SetBand (const int band)
	Virtual method that sets the band number.
double	Sample ()
	Returns the current sample number.
int	Band ()
	Returns the current band.
double	Line ()
	Returns the current line number.
bool	GroundRange (double &minlat, double &maxlat, double &minlon, double &maxlon, Pvl &pvl)
	Computes the Ground Range.
bool	ringRange (double &minRingRadius, double &maxRingRadius, double &minRingLongitude, double &maxRingLongitude, Pvl &pvl)
	Analogous to the above Ground Range method.
bool	IntersectsLongitudeDomain (Pvl &pvl)
	Checks whether the ground range intersects the longitude domain or not.
double	PixelResolution ()
	Returns the pixel resolution at the current position in m/pix.
double	LineResolution ()
	Returns the line resolution at the current position.
double	SampleResolution ()
	Returns the sample resolution at the current position.
double	DetectorResolution ()
	Returns the detector resolution at the current position.
virtual double	resolution ()
	Returns the resolution of the camera.
double	LowestImageResolution ()
	Returns the lowest/worst resolution in the entire image.
double	HighestImageResolution ()
	Returns the highest/best resolution in the entire image.
void	BasicMapping (Pvl &map)
	Writes the basic mapping group to the specified Pvl.
void	basicRingMapping (Pvl &map)
	Writes the basic mapping group for ring plane to the specified Pvl.
double	FocalLength () const
	Returns the focal length.
double	PixelPitch () const
	Returns the pixel pitch.
virtual QList< QPointF >	PixelIfovOffsets ()
	Returns the pixel ifov offsets from center of pixel, which defaults to the (pixel pitch * summing mode ) / 2.
int	Samples () const
	Returns the number of samples in the image.
int	Lines () const
	Returns the number of lines in the image.
int	Bands () const
	Returns the number of bands in the image.
int	ParentLines () const
	Returns the number of lines in the parent alphacube.
int	ParentSamples () const
	Returns the number of samples in the parent alphacube.
bool	RaDecRange (double &minra, double &maxra, double &mindec, double &maxdec)
	Computes the RaDec range.
double	RaDecResolution ()
	Returns the RaDec resolution.
CameraDistortionMap *	DistortionMap ()
	Returns a pointer to the CameraDistortionMap object.
CameraFocalPlaneMap *	FocalPlaneMap ()
	Returns a pointer to the CameraFocalPlaneMap object.
CameraDetectorMap *	DetectorMap ()
	Returns a pointer to the CameraDetectorMap object.
CameraGroundMap *	GroundMap ()
	Returns a pointer to the CameraGroundMap object.
CameraSkyMap *	SkyMap ()
	Returns a pointer to the CameraSkyMap object.
QString	instrumentNameLong () const
	This method returns the full instrument name.
QString	instrumentNameShort () const
	This method returns the shortened instrument name.
QString	spacecraftNameLong () const
	This method returns the full spacecraft name.
QString	spacecraftNameShort () const
	This method returns the shortened spacecraft name.
void	SetDistortionMap (CameraDistortionMap *map)
	Sets the Distortion Map.
void	SetFocalPlaneMap (CameraFocalPlaneMap *map)
	Sets the Focal Plane Map.
void	SetDetectorMap (CameraDetectorMap *map)
	Sets the Detector Map.
void	SetGroundMap (CameraGroundMap *map)
	Sets the Ground Map.
void	SetSkyMap (CameraSkyMap *map)
	Sets the Sky Map.
double	NorthAzimuth ()
	Returns the North Azimuth.
double	SunAzimuth ()
	Returns the Sun Azimuth.
double	SpacecraftAzimuth ()
	Return the Spacecraft Azimuth.
double	OffNadirAngle ()
	Return the off nadir angle in degrees.
void	IgnoreProjection (bool ignore)
	Set whether or not the camera should ignore the Projection.
void	LoadCache ()
	This loads the spice cache big enough for this image.
std::pair< double, double >	StartEndEphemerisTimes ()
	Calculates the start and end ephemeris times.
int	CacheSize (double startTime, double endTime)
	This method calculates the spice cache size.
void	GetGeometricTilingHint (int &startSize, int &endSize)
	This will get the geometric tiling hint; these values are typically used for ProcessRubberSheet::SetTiling(...).
bool	InCube ()
	This returns true if the current Sample() or Line() value is outside of the cube (meaning the point must have been extrapolated).
virtual int	SpkCenterId () const
	Provides the center of motion body for SPK NAIF kernel.
void	setTime (const iTime &time)
	By setting the time you essential set the position of the spacecraft and body as indicated in the class Spice.
bool	SetLookDirection (const double v[3])
	Sets the look direction of the spacecraft.
bool	HasSurfaceIntersection () const
	Returns if the last call to either SetLookDirection or SetUniversalGround had a valid intersection with the target.
void	Coordinate (double p[3]) const
	Returns the x,y,z of the surface intersection in BodyFixed km.
double	UniversalLatitude () const
	Returns the planetocentric latitude, in degrees, at the surface intersection point in the body fixed coordinate system.
Latitude	GetLatitude () const
	Returns a planetocentric latitude object at the surface intersection point in body fixed.
double	UniversalLongitude () const
	Returns the positive east, 0-360 domain longitude, in degrees, at the surface intersection point in the body fixed coordinate system.
Longitude	GetLongitude () const
	Returns a positive east, 0-360 domain longitude object at the surface intersection point in the body fixed coordinate system.
SurfacePoint	GetSurfacePoint () const
	Returns the surface point (most efficient accessor).
Distance	LocalRadius () const
	Returns the local radius at the intersection point.
Distance	LocalRadius (Latitude lat, Longitude lon)
	Returns the local radius at the intersection point.
Distance	LocalRadius (double lat, double lon)
	Returns the local radius at the intersection point.
double	PhaseAngle () const
	Returns the phase angle in degrees.
double	EmissionAngle () const
	Returns the emission angle in degrees.
double	IncidenceAngle () const
	Returns the incidence angle in degrees.
void	LookDirection (double v[3]) const
	Returns the look direction in the camera coordinate system.
double	RightAscension ()
	Returns the right ascension angle (sky longitude).
double	Declination ()
	Returns the declination angle (sky latitude).
void	SpacecraftSurfaceVector (double scSurfaceVector[3]) const
	Sets the vector between the spacecraft and surface point in body-fixed.
double	SlantDistance () const
	Return the distance between the spacecraft and surface point in kmv.
double	LocalSolarTime ()
	Return the local solar time in hours.
double	SolarDistance () const
	Returns the distance between the sun and surface point in AU.
double	SpacecraftAltitude ()
	Returns the distance from the spacecraft to the subspacecraft point in km.
void	IgnoreElevationModel (bool ignore)
	This allows you to ignore the cube elevation model and use the ellipse.
void	instrumentPosition (double p[3]) const
	Returns the spacecraft position in body-fixed frame km units.
SpicePosition *	instrumentPosition () const
	Accessor method for the instrument position.
void	instrumentBodyFixedPosition (double p[3]) const
	Returns the spacecraft position in body-fixed frame km units.
void	sunPosition (double p[3]) const
	Fills the input vector with sun position information, in either body-fixed or J2000 reference frame and km units.
SpicePosition *	sunPosition () const
	Accessor method for the sun position.
double	targetCenterDistance () const
	Calculates and returns the distance from the spacecraft to the target center.
Longitude	solarLongitude ()
	Returns the solar longitude.
void	instrumentBodyFixedVelocity (double v[3]) const
	Returns the spacecraft velocity in body-fixed frame km/sec units.
iTime	time () const
	Returns the ephemeris time in seconds which was used to obtain the spacecraft and sun positions.
void	radii (Distance r[3]) const
	Returns the radii of the body in km.
void	createCache (iTime startTime, iTime endTime, const int size, double tol)
	This method creates an internal cache of spacecraft and sun positions over a specified time range.
iTime	cacheStartTime () const
	Accessor method for the cache start time.
iTime	cacheEndTime () const
	Accessor method for the cache end time.
void	subSpacecraftPoint (double &lat, double &lon)
	Returns the sub-spacecraft latitude/longitude in universal coordinates (0-360 positive east, ocentric)
void	subSolarPoint (double &lat, double &lon)
	Returns the sub-solar latitude/longitude in universal coordinates (0-360 positive east, ocentric)
Target *	target () const
	Returns a pointer to the target object.
QString	targetName () const
	Returns the string name of the target.
iTime	getClockTime (QString clockValue, int sclkCode=-1)
	This converts the spacecraft clock ticks value (clockValue) to an iTime.
SpiceDouble	getDouble (const QString &key, int index=0)
	This returns a value from the NAIF text pool.
SpiceInt	getInteger (const QString &key, int index=0)
	This returns a value from the NAIF text pool.
QString	getString (const QString &key, int index=0)
	This returns a value from the NAIF text pool.
SpiceRotation *	bodyRotation () const
	Accessor method for the body rotation.
SpiceRotation *	instrumentRotation () const
	Accessor method for the instrument rotation.
bool	hasKernels (Pvl &lab)
	Returns true if the kernel group has kernel files.
SpiceInt	naifBodyCode () const
	This returns the NAIF body code of the target indicated in the labels.
SpiceInt	naifSpkCode () const
	This returns the NAIF SPK code to use when reading from SPK kernels.
SpiceInt	naifCkCode () const
	This returns the NAIF CK code to use when reading from CK kernels.
SpiceInt	naifIkCode () const
	This returns the NAIF IK code to use when reading from instrument kernels.
SpiceInt	naifSclkCode () const
	This returns the NAIF SCLK code to use when reading from instrument kernels.
SpiceInt	naifBodyFrameCode () const
	This returns the NAIF body frame code.
PvlObject	getStoredNaifKeywords () const
	This returns the PvlObject that stores all of the requested Naif data and can be a replacement for furnishing text kernels.

Static Public Member Functions
static double	GroundAzimuth (double glat, double glon, double slat, double slon)
	Computes and returns the ground azimuth between the ground point and another point of interest, such as the subspacecraft point or the subsolar point.

Protected Types
enum	SpiceValueType { SpiceDoubleType, SpiceStringType, SpiceIntType, SpiceByteCodeType }
	NAIF value primitive type. More...

Protected Member Functions
void	SetFocalLength (double v)
	Sets the focal length.
void	SetFocalLength ()
	Reads the focal length from the instrument kernel.
void	SetPixelPitch (double v)
	Sets the pixel pitch.
void	SetPixelPitch ()
	Reads the Pixel Pitch from the instrument kernel.
void	SetGeometricTilingHint (int startSize=128, int endSize=8)
	This method sets the best geometric tiling size for projecting from this camera model.
QVariant	readValue (QString key, SpiceValueType type, int index=0)
	This should be used for reading ALL text naif kernel values.
void	storeResult (QString name, SpiceValueType type, QVariant value)
QVariant	getStoredResult (QString name, SpiceValueType type)
void	storeValue (QString key, int index, SpiceValueType type, QVariant value)
QVariant	readStoredValue (QString key, SpiceValueType type, int index)

Protected Attributes
QString	m_instrumentNameLong
	Full instrument name.
QString	m_instrumentNameShort
	Shortened instrument name.
QString	m_spacecraftNameLong
	Full spacecraft name.
QString	m_spacecraftNameShort
	Shortened spacecraft name.
SpiceDouble	m_uB [3]
	This contains the sun position (u) in the bodyfixed reference frame (B).
SpiceDouble	m_BJ [3][3]
	This contains the transformation matrix from J2000 (J) to Body fixed (B).

Private Member Functions
double	computeFocalLength (const QString &filterCode, Pvl &label)
	Computes temperature-dependent focal length.

Detailed Description

MESSENGER MDIS NAC and WAC Camera Model.

This is the camera model for both MESSENGER MDIS Wide Angle (WAC) and Narrow Angle (NAC) cameras.

This camera model is desinfed to be externally managed as much as possible through the Messenger MDIS instrument kernel (IAK). See the file $ISIS3DATA/messenger/kernels/iak/mdisAddendum???.ti for details.

See Also: http://pds-imaging.jpl.nasa.gov/documentation/MDISEDRSIS.PDF; http://pds-imaging.jpl.nasa.gov/documentation/MDIS_CDR_RDRSIS.PDF

Author: 2005-07-29 Kris Becker

History:: 2006-10-31 Jeff Anderson - Updated to accomodate Spice class refactory.

History:: 2007-04-24 Kris Becker - Corrected problems with setting Ephemeris time after the cache is created; fixed problem with FPU binning geometry is mapped to detector map as described in the SIS. This problem is due to an FPGA coding bug on the camera.

History:: 2007-09-05 Kris Becker - Removed test for jailbar imaging mode as the MDIS team reports it should be treated as a normal image.

History:: 2007-09-06 Kris Becker - Removed test for subframe imaging mode as the team provided calification on its implications.

History:: 2007-12-06 Kris Becker - Added camera distortion model provided by Scott Turner, JHU/APL.

History:: 2008-08-08 Steven Lambright Now using the new LoadCache(...) method instead of CreateCache(...).

History:: 2009-01-21 Kris Becker Added a new implementation of the MDIS NAC distortion model contributed by Scott Turner and Lillian Nguyen at JHU/APL.

History:: 2009-06-11 Steven Lambright - Documentation fixes

History:: 2009-08-28 Steven Lambright - Changed inheritance to no longer inherit directly from Camera

History:: 2010-10-06 Kris Becker - Updated WAC distortion model to the same as the NAC - A Taylor Series implementation. Update to the MDIS IK (msgr_mdis_v120.ti) udpates these parameters as well as the WAC focal lengths. The NAC is unaffected by these changes. Updated unitTest.

History:: 2010-12-20 Kris Becker - Added implementation of CK and SPK NAIF codes for the Camera class.

History:: 2011-01-14 Travis Addair - Added new CK/SPK accessor methods, pure virtual in Camera, implemented in mission specific cameras.

History:: 2011-02-09 Steven Lambright - Major changes to camera classes.

History:: 2011-03-31 Kris Becker - Fixed bug in handling of pixel binning. Valid values for PixelBinningMode are 0, 2 or 4. This was not handled properly until it was used in conjuction with FPU binning in orbit.

History:: 2011-05-03 Jeannie Walldren - Added ShutterOpenCloseTimes() method. Updated unitTest to test for new methods. Updated documentation. Removed Messenger namespace wrap inside Isis namespace wrap. Added Isis Disclaimer to files. Added NAIF error check to constructor.

History:: 2012-07-06 Debbie A. Cook, Updated Spice members to be more compliant with Isis coding standards. References #972.

History:: 2012-07-25 Kris Becker - Added temperature dependant focal length computation from new IK content. Fixes #922.

History:: 2012-10-25 Kris Becker - Create instrument neutral temperature dependent focal length keyword (TempDependentFocalLength) in the NaifKeywords group to store this value for easy access. Incremented camera version number to 2. Removed backword compatibility code supporting older IKs. The first valid one with this version is msgr_mdis_v131.ti. Updated FK (msgr_v220.tf) and PCK (pck00010_MSGR_v10.tpc). Reran spiceinit on all MESSENGER data in the test suite and updated all appTests (18 total were affected by this change). Fixes #1214.

History:: 2015-08-13 Ian Humphrey and Makayla Shepherd - Added new data members and methods to get spacecraft and instrument names. Extended unit test to test these methods.

History:: 2015-10-01 Ian Humphrey and Makayla Shepherd - Updated check for Wac instrument to include instrument codes that correspond to its filters. References #2335.

History:: 2015-10-16 Ian Humphrey - Removed declarations of spacecraft and instrument members and methods and removed implementation of these methods since Camera now handles this. References #2335.

Definition at line 109 of file MdisCamera.h.

Member Enumeration Documentation

enum Isis::Camera::CameraType

inherited

This enum defines the types of cameras supported in this class.

Enumerator:

Framing	Framing Camera.
PushFrame	Push Frame Camera.
LineScan	Line Scan Camera.
Radar	Radar Camera.
Point	Point Camera.

Definition at line 321 of file Camera.h.

enum Isis::Spice::SpiceValueType

protectedinherited

NAIF value primitive type.

Enumerator:

SpiceDoubleType	SpiceDouble type.
SpiceStringType	SpiceString type.
SpiceIntType	SpiceInt type.
SpiceByteCodeType	SpiceByteCode type.

Definition at line 333 of file Spice.h.

Constructor & Destructor Documentation

Isis::MdisCamera::MdisCamera ( Cube & cube )

Initialize the MDIS camera model for NAC and WAC.

This constructor reads the Messenger/MDIS instrument addendum for many of its default parameters.

This camera model does not support subframes of jailbar imaging modes. An exception is thrown in those cases.

Parameters

lab	Pvl label from a Messenger MDIS image.

Exceptions

iException::User	- "Subframe imaging mode is not supported"
iException::User	- "Jail bar observations are not supported"
iException::User	- "New MDIS/NAC distortion model invalidates previous SPICE - you must rerun spiceinit to get new kernels"

History:: 2011-05-03 Jeannie Walldren - Added NAIF error check.

Definition at line 64 of file MdisCamera.cpp.

References _FILEINFO_, Isis::NaifStatus::CheckErrors(), computeFocalLength(), Isis::PvlObject::findGroup(), Isis::Spice::getClockTime(), Isis::Spice::getDouble(), Isis::Spice::getString(), Isis::Cube::label(), Isis::Camera::LoadCache(), Isis::Camera::m_instrumentNameLong, Isis::Camera::m_instrumentNameShort, Isis::Camera::m_spacecraftNameLong, Isis::Camera::m_spacecraftNameShort, Isis::Spice::naifIkCode(), Isis::IException::Programmer, Isis::CameraDetectorMap::SetDetectorLineSumming(), Isis::CameraFocalPlaneMap::SetDetectorOrigin(), Isis::CameraDetectorMap::SetDetectorSampleSumming(), Isis::TaylorCameraDistortionMap::SetDistortion(), Isis::Camera::SetFocalLength(), Isis::Camera::SetPixelPitch(), Isis::CameraDetectorMap::SetStartingDetectorLine(), Isis::CameraDetectorMap::SetStartingDetectorSample(), Isis::Sensor::setTime(), Isis::toString(), Isis::PvlObject::Traverse, and Isis::IException::User.

Isis::MdisCamera::~MdisCamera ( )

inline

Destroys the MdisCamera Object.

Definition at line 113 of file MdisCamera.h.

Member Function Documentation

int Isis::Camera::Band ( )

inherited

Returns the current band.

Returns: int Band

Definition at line 2448 of file Camera.cpp.

References Isis::Camera::p_childBand.

Referenced by Isis::Camera::GroundRangeResolution(), Isis::Camera::RaDecRange(), Isis::Camera::RaDecResolution(), and Isis::Camera::ringRangeResolution().

int Isis::Camera::Bands ( ) const

inherited

Returns the number of bands in the image.

Returns: int Number of Bands

Definition at line 2531 of file Camera.cpp.

References Isis::Camera::p_bands.

Referenced by Isis::ProjectionFactory::CreateForCube(), Isis::CameraStatistics::init(), Isis::ProjectionFactory::RingsCreateForCube(), and Isis::Camera::StartEndEphemerisTimes().

void Isis::Camera::BasicMapping ( Pvl & pvl )

inherited

Writes the basic mapping group to the specified Pvl.

Parameters

pvl	Pvl to write mapping group to

Definition at line 1122 of file Camera.cpp.

References Isis::PvlObject::addGroup(), Isis::Camera::GroundRangeResolution(), Isis::Camera::p_maxlat, Isis::Camera::p_maxlon, Isis::Camera::p_minlat, Isis::Camera::p_minlon, Isis::Camera::p_minres, Isis::Target::radii(), Isis::Spice::radii(), Isis::Spice::target(), and Isis::toString().

Referenced by Isis::ImagePolygon::Create().

void Isis::Camera::basicRingMapping ( Pvl & pvl )

inherited

Writes the basic mapping group for ring plane to the specified Pvl.

Parameters

pvl	Pvl to write mapping group to

Definition at line 1151 of file Camera.cpp.

References _FILEINFO_, Isis::PvlObject::addGroup(), Isis::Camera::p_maxRingLongitude, Isis::Camera::p_maxRingRadius, Isis::Camera::p_minres, Isis::Camera::p_minRingLongitude, Isis::Camera::p_minRingRadius, Isis::Camera::ringRangeResolution(), Isis::Spice::target(), Isis::toString(), and Isis::IException::User.

SpiceRotation * Isis::Spice::bodyRotation ( ) const

inherited

Accessor method for the body rotation.

Returns: iTime Body rotation for the image.

Author: Steven Lambright

History:: 2011-02-09 Steven Lambright - Original version.

Definition at line 1406 of file Spice.cpp.

Referenced by Isis::BundleAdjust::ApproximatePoint_ClosestApproach(), Isis::Sensor::computeRaDec(), Isis::Sensor::EmissionAngle(), Isis::RadarGroundMap::GetdXYdPosition(), Isis::RadarGroundMap::GetXY(), Isis::Camera::LocalPhotometricAngles(), Isis::Sensor::LookDirection(), Isis::MiniRF::MiniRF(), Isis::Sensor::PhaseAngle(), Isis::RadarGroundMap::SetFocalPlane(), Isis::RadarGroundMap::SetGround(), Isis::Sensor::SetGroundLocal(), Isis::Sensor::SetLookDirection(), and Isis::Sensor::SlantDistance().

iTime Isis::Spice::cacheEndTime ( ) const

inherited

Accessor method for the cache end time.

Returns: iTime End time for the image.

Author: Steven Lambright

History:: 2011-02-09 Steven Lambright - Original version.

Definition at line 648 of file Spice.cpp.

int Isis::Camera::CacheSize	(	double	startTime,
		double	endTime
	)

inherited

This method calculates the spice cache size.

This method finds the number of lines in the beta cube and adds 1, since we need at least 2 points for interpolation. This method must be called before a call to the Spice::createCache() method. It is called in the LoadCache() method.

Exceptions

iException::Programmer - "A cache has already been created."

See Also: createCache(); LoadCache()

Author: 2011-02-02 Jeannie Walldren

History:: 2011-02-02 Jeannie Walldren - Original version.

Definition at line 2283 of file Camera.cpp.

References Isis::AlphaCube::BetaLines(), and Isis::Camera::p_alphaCube.

Referenced by Isis::Camera::LoadCache().

iTime Isis::Spice::cacheStartTime ( ) const

inherited

Accessor method for the cache start time.

Returns: iTime Start time for the image.

Author: Steven Lambright

History:: 2011-02-09 Steven Lambright - Original version.

Definition at line 633 of file Spice.cpp.

virtual int Isis::MdisCamera::CkFrameId ( ) const

inlinevirtual

CK frame ID - - MESSENGER instrument code (MSGR_SPACECRAFT)

Returns: int The appropriate instrument code for the "Camera-matrix" Kernel Frame ID

Implements Isis::Camera.

Definition at line 123 of file MdisCamera.h.

virtual int Isis::MdisCamera::CkReferenceId ( ) const

inlinevirtual

CK Reference ID - J2000.

Returns: int The appropriate instrument code for the "Camera-matrix" Kernel Reference ID

Implements Isis::Camera.

Definition at line 130 of file MdisCamera.h.

double Isis::MdisCamera::computeFocalLength	(	const QString &	filterCode,
		Pvl &	label
	)

private

Computes temperature-dependent focal length.

This method computes temperature dependent focal lengths based upon a 5th order polynomial using the FocalPlaneTemperature keyword value stored in the ISIS label (it is the FOCAL_PLANE_TEMPERATURE PDS keyword). At the time of this writing, only (the two) linear terms are used.

In addition, this method is initially coded to be backword compatible but this feature is likely to be removed when the kernels become fully adopted.

IMPORTANT: The computed temperature dependent focal length is stored in the label of the cube during spiceinit. This implementation uses the special recording of keywords as retrieved from kernels and stores them as a string value so (SOCET) folks can easily read and apply the focal lengths in their environments. String storage is preferred over storing as double since these values are stored in hexidecimal format.

Author: Kris Becker (8/13/2012)

History:: 2012-10-22 Kris Becker - Store temperature dependant keyword in instrument neutral keyword called TempDependentFocalLength.

Parameters

filterCode	Integer MDIS instrument/filter code
label	Pvl label from cube being initialized where temperature keywords are extracted from.

Returns: double Computed temperature dependant focal length

Definition at line 306 of file MdisCamera.cpp.

References _FILEINFO_, Isis::PvlObject::findGroup(), Isis::Spice::getDouble(), Isis::Spice::getString(), Isis::IException::Programmer, Isis::Spice::SpiceStringType, Isis::PvlObject::Traverse, and Isis::IString::UpCase().

Referenced by MdisCamera().

void Isis::Sensor::Coordinate ( double p[3] ) const

inherited

Returns the x,y,z of the surface intersection in BodyFixed km.

Parameters

p[]	The coordinate of the surface intersection.

Definition at line 210 of file Sensor.cpp.

References Isis::Displacement::kilometers(), Isis::Target::shape(), Isis::ShapeModel::surfaceIntersection(), and Isis::Spice::target().

Referenced by Isis::ControlPoint::ComputeApriori(), Isis::Camera::ComputeAzimuth(), Isis::Camera::DetectorResolution(), Isis::Sensor::EmissionAngle(), Isis::VimsGroundMap::Init(), Isis::Camera::LocalPhotometricAngles(), Isis::Camera::OffNadirAngle(), Isis::Sensor::PhaseAngle(), Isis::Sensor::SetGroundLocal(), Isis::Sensor::SetLookDirection(), Isis::Sensor::SlantDistance(), and Isis::AdvancedTrackTool::updateRow().

void Isis::Spice::createCache	(	iTime	startTime,
		iTime	endTime,
		const int	size,
		double	tol
	)

inherited

This method creates an internal cache of spacecraft and sun positions over a specified time range.

The SPICE kernels are then immediately unloaded. This allows multiple instances of the Spice object to be created as the NAIF toolkit can clash if multiple sets of SPICE kernels are loaded. Note that the cache size is specified as an argument. Therefore, times requested via setTime() which are not directly loaded in the cache will be interpolated. If the instrument position is not cached and cacheSize is greater than 3, the tolerance is passed to the SpicePosition Memcache2HermiteCache() method.

Note: Before this method is called, the private variables m_cacheSize, m_startTime and m_endTime must be set. This is done in the Camera classes using the methods SetCacheSize() and SetStartEndEphemerisTime().

Parameters

startTime	Starting ephemeris time to cache
endTime	Ending ephemeris time to cache
size	Size of the cache.
tol	Tolerance.

Exceptions

Isis::IException::Programmer	- "Argument cacheSize must be greater than zero"
Isis::IException::Programmer	- "Argument startTime must be less than or equal to endTime"
Isis::IException::User	- "This instrument does not support time padding"

History:: 2011-04-10 Debbie A. Cook - Updated to only create cache for instrumentPosition if type is Spice.

Definition at line 539 of file Spice.cpp.

References _FILEINFO_, and Isis::iTime::Et().

Referenced by Isis::CrismCamera::CrismCamera(), Isis::Camera::LoadCache(), Isis::MiniRF::MiniRF(), and Isis::VimsCamera::VimsCamera().

double Isis::Sensor::Declination ( )

inherited

Returns the declination angle (sky latitude).

Returns: double Declination angle, in degrees.

Definition at line 542 of file Sensor.cpp.

References Isis::Sensor::computeRaDec(), Isis::Sensor::m_dec, and Isis::Sensor::m_newLookB.

Referenced by Isis::VimsSkyMap::Init(), Isis::Camera::RaDecRange(), Isis::Camera::RaDecResolution(), Isis::Camera::RawFocalPlanetoImage(), and Isis::AdvancedTrackTool::updateRow().

CameraDetectorMap * Isis::Camera::DetectorMap ( )

inherited

Returns a pointer to the CameraDetectorMap object.

Returns: CameraDetectorMap*

Reimplemented in Isis::LineScanCamera, and Isis::PushFrameCamera.

Definition at line 2575 of file Camera.cpp.

References Isis::Camera::p_detectorMap.

Referenced by Isis::PushFrameCameraGroundMap::FindDistance(), Isis::PushFrameCameraGroundMap::FindSpacecraftDistance(), Isis::Camera::PixelIfovOffsets(), Isis::PushFrameCameraGroundMap::SetGround(), and Isis::LineScanCameraSkyMap::SetSky().

double Isis::Camera::DetectorResolution ( )

inherited

Returns the detector resolution at the current position.

Returns: double The detector resolution

Definition at line 465 of file Camera.cpp.

References Isis::Sensor::Coordinate(), Isis::Sensor::HasSurfaceIntersection(), Isis::Spice::instrumentPosition(), Isis::Camera::p_focalLength, and Isis::Camera::p_pixelPitch.

Referenced by Isis::Camera::LineResolution(), and Isis::Camera::SampleResolution().

CameraDistortionMap * Isis::Camera::DistortionMap ( )

inherited

Returns a pointer to the CameraDistortionMap object.

Returns: CameraDistortionMap*

Definition at line 2557 of file Camera.cpp.

References Isis::Camera::p_distortionMap.

Referenced by Isis::BundleAdjust::ApproximatePoint_ClosestApproach(), Isis::ControlPoint::ComputeApriori(), Isis::ControlPoint::ComputeResiduals(), Isis::PushFrameCameraGroundMap::FindDistance(), Isis::MarciCamera::SetBand(), Isis::ThemisIrCamera::SetBand(), Isis::LroWideAngleCamera::SetBand(), Isis::LineScanCameraSkyMap::SetSky(), and Isis::AdvancedTrackTool::updateRow().

double Isis::Sensor::EmissionAngle ( ) const

inherited

Returns the emission angle in degrees.

Returns: double Emission angle, in degrees.

Definition at line 338 of file Sensor.cpp.

References Isis::Spice::bodyRotation(), Isis::Sensor::Coordinate(), Isis::ShapeModel::emissionAngle(), Isis::Spice::instrumentPosition(), Isis::Target::shape(), and Isis::Spice::target().

Referenced by Isis::CameraStatistics::addStats(), Isis::ImagePolygon::FixPolePoly(), Isis::InterestOperator::InterestByMeasure(), Isis::Camera::OffNadirAngle(), Isis::CubeCalculator::prepareCalculations(), Isis::ImagePolygon::SetImage(), and Isis::AdvancedTrackTool::updateRow().

double Isis::Camera::FocalLength ( ) const

inherited

Returns the focal length.

Returns: double Focal Length

Definition at line 2473 of file Camera.cpp.

References Isis::Camera::p_focalLength.

Referenced by Isis::AmicaCamera::AmicaCamera(), Isis::CrismCamera::CrismCamera(), Isis::PushFrameCameraGroundMap::FindDistance(), Isis::Camera::LoadCache(), Isis::MiniRF::MiniRF(), Isis::MocWideAngleDistortionMap::SetFocalPlane(), Isis::CameraSkyMap::SetSky(), Isis::LineScanCameraSkyMap::SetSky(), Isis::MocWideAngleDistortionMap::SetUndistortedFocalPlane(), Isis::CameraDistortionMap::UndistortedFocalPlaneZ(), and Isis::VimsCamera::VimsCamera().

CameraFocalPlaneMap * Isis::Camera::FocalPlaneMap ( )

inherited

Returns a pointer to the CameraFocalPlaneMap object.

Returns: CameraFocalPlaneMap*

Definition at line 2566 of file Camera.cpp.

References Isis::Camera::p_focalPlaneMap.

Referenced by Isis::BundleAdjust::ApproximatePoint_ClosestApproach(), Isis::ControlPoint::ComputeResiduals(), Isis::PushFrameCameraGroundMap::FindDistance(), Isis::HrscCamera::HrscCamera(), Isis::MarciCamera::MarciCamera(), Isis::ThemisIrCamera::SetBand(), Isis::NewHorizonsLeisaCamera::SetBand(), Isis::LroWideAngleCamera::SetBand(), Isis::LoMediumDistortionMap::SetDistortion(), Isis::ReseauDistortionMap::SetFocalPlane(), Isis::LoMediumDistortionMap::SetFocalPlane(), Isis::VariableLineScanCameraDetectorMap::SetParent(), Isis::LineScanCameraDetectorMap::SetParent(), Isis::LineScanCameraSkyMap::SetSky(), Isis::ReseauDistortionMap::SetUndistortedFocalPlane(), Isis::LoMediumDistortionMap::SetUndistortedFocalPlane(), and Isis::AdvancedTrackTool::updateRow().

virtual CameraType Isis::FramingCamera::GetCameraType ( ) const

inlinevirtualinherited

This method returns Framing camera type.

Returns: CameraType Type of camera, Framing.

Implements Isis::Camera.

Definition at line 59 of file FramingCamera.h.

References Isis::Camera::Framing.

iTime Isis::Spice::getClockTime	(	QString	clockValue,
		int	sclkCode = `-1`
	)

inherited

This converts the spacecraft clock ticks value (clockValue) to an iTime.

Use this when possible because naif calls (such as scs2e_c) cannot be called when not using naif.

Definition at line 925 of file Spice.cpp.

References Isis::toString().

Referenced by Isis::AmicaCamera::AmicaCamera(), Isis::Chandrayaan1M3Camera::Chandrayaan1M3Camera(), Isis::CTXCamera::CTXCamera(), Isis::DawnFcCamera::DawnFcCamera(), Isis::HiriseCamera::HiriseCamera(), Isis::VimsSkyMap::Init(), Isis::VimsGroundMap::Init(), Isis::LroNarrowAngleCamera::LroNarrowAngleCamera(), Isis::LroWideAngleCamera::LroWideAngleCamera(), Isis::MarciCamera::MarciCamera(), MdisCamera(), Isis::MocNarrowAngleCamera::MocNarrowAngleCamera(), Isis::MocWideAngleCamera::MocWideAngleCamera(), Isis::NewHorizonsLeisaCamera::NewHorizonsLeisaCamera(), Isis::NewHorizonsLorriCamera::NewHorizonsLorriCamera(), Isis::NewHorizonsMvicFrameCamera::NewHorizonsMvicFrameCamera(), Isis::NewHorizonsMvicTdiCamera::NewHorizonsMvicTdiCamera(), Isis::DawnVirCamera::readHouseKeeping(), Isis::ThemisIrCamera::ThemisIrCamera(), Isis::ThemisVisCamera::ThemisVisCamera(), Isis::VikingCamera::VikingCamera(), and Isis::VimsCamera::VimsCamera().

SpiceDouble Isis::Spice::getDouble	(	const QString &	key,
		int	index = `0`
	)

inherited

This returns a value from the NAIF text pool.

It is a static convience method

Parameters

key	Name of NAIF keyword to obtain from the pool
index	If the keyword is an array, the element to obtain. Defaults to 0

Returns: SpiceDouble Spice double from NAIF text pool

Exceptions

Isis::iException::Io - "Can not find key in instrument kernels."

Definition at line 914 of file Spice.cpp.

Referenced by Isis::LroWideAngleCameraFocalPlaneMap::addFilter(), Isis::LroWideAngleCameraDistortionMap::addFilter(), Isis::AmicaCamera::AmicaCamera(), Isis::ApolloMetricCamera::ApolloMetricCamera(), Isis::ApolloPanoramicCamera::ApolloPanoramicCamera(), Isis::Chandrayaan1M3Camera::Chandrayaan1M3Camera(), computeFocalLength(), Isis::CrismCamera::CrismCamera(), Isis::CTXCamera::CTXCamera(), Isis::DawnFcCamera::DawnFcCamera(), Isis::HiresCamera::HiresCamera(), Isis::HrscCamera::HrscCamera(), Isis::CameraFocalPlaneMap::Init(), Isis::IssNACamera::IssNACamera(), Isis::IssWACamera::IssWACamera(), Isis::KaguyaMiCamera::KaguyaMiCamera(), Isis::LroNarrowAngleCamera::LroNarrowAngleCamera(), Isis::LroWideAngleCamera::LroWideAngleCamera(), Isis::LwirCamera::LwirCamera(), Isis::MarciCamera::MarciCamera(), Isis::MarciDistortionMap::MarciDistortionMap(), Isis::Mariner10Camera::Mariner10Camera(), MdisCamera(), Isis::MsiCamera::MsiCamera(), Isis::NewHorizonsLorriCamera::NewHorizonsLorriCamera(), Isis::NewHorizonsMvicFrameCamera::NewHorizonsMvicFrameCamera(), Isis::NewHorizonsMvicTdiCamera::NewHorizonsMvicTdiCamera(), Isis::NirCamera::NirCamera(), Isis::KaguyaMiCameraDistortionMap::SetDistortion(), Isis::TaylorCameraDistortionMap::SetDistortion(), Isis::LroNarrowAngleDistortionMap::SetDistortion(), Isis::Camera::SetFocalLength(), Isis::Camera::SetPixelPitch(), Isis::SsiCamera::SsiCamera(), and Isis::UvvisCamera::UvvisCamera().

void Isis::Camera::GetGeometricTilingHint	(	int &	startSize,
		int &	endSize
	)

inherited

This will get the geometric tiling hint; these values are typically used for ProcessRubberSheet::SetTiling(...).

Parameters

startSize	Tiling start size
endSize	Tiling end size

Definition at line 2360 of file Camera.cpp.

References Isis::Camera::p_geometricTilingEndSize, and Isis::Camera::p_geometricTilingStartSize.

SpiceInt Isis::Spice::getInteger	(	const QString &	key,
		int	index = `0`
	)

inherited

This returns a value from the NAIF text pool.

It is a static convience

Parameters

key	Name of NAIF keyword to obtain from the pool
index	If the keyword is an array, the element to obtain. Defaults to 0

Returns: SpiceInt Spice integer from NAIF text pool

Exceptions

Isis::iException::Io - "Can not find key in instrument kernels

Definition at line 900 of file Spice.cpp.

Referenced by Isis::DawnVirCamera::getPointingTable(), Isis::LroWideAngleCamera::GetVector(), Isis::IssNACamera::IssNACamera(), Isis::IssWACamera::IssWACamera(), and Isis::LroWideAngleCamera::LroWideAngleCamera().

Latitude Isis::Sensor::GetLatitude ( ) const

inherited

Returns a planetocentric latitude object at the surface intersection point in body fixed.

Returns: Latidude Universal latitude object.

Definition at line 235 of file Sensor.cpp.

References Isis::SurfacePoint::GetLatitude(), Isis::Target::shape(), Isis::ShapeModel::surfaceIntersection(), and Isis::Spice::target().

Referenced by Isis::StereoTool::calculateElevation(), and Isis::Sensor::UniversalLatitude().

void Isis::Camera::GetLocalNormal ( double normal[3] )

inherited

This method will find the local normal at the current (sample, line) and set it to the passed in array.

Parameters

[out] normal The local normal vector to be calculated.

Definition at line 1251 of file Camera.cpp.

References Isis::SurfacePoint::GetLatitude(), Isis::SurfacePoint::GetLongitude(), Isis::Sensor::GetSurfacePoint(), Isis::ShapeModel::hasIntersection(), Isis::ShapeModel::hasNormal(), Isis::ShapeModel::isDEM(), Isis::Distance::kilometers(), Isis::Camera::Line(), Isis::Sensor::LocalRadius(), Isis::ShapeModel::normal(), Isis::Camera::p_pointComputed, Isis::Angle::radians(), Isis::Camera::Sample(), Isis::Camera::SetImage(), Isis::Target::shape(), and Isis::Spice::target().

Referenced by Isis::Camera::LocalPhotometricAngles().

Longitude Isis::Sensor::GetLongitude ( ) const

inherited

Returns a positive east, 0-360 domain longitude object at the surface intersection point in the body fixed coordinate system.

Returns: Longitude Universal longitude object.

Definition at line 259 of file Sensor.cpp.

References Isis::SurfacePoint::GetLongitude(), Isis::Target::shape(), Isis::ShapeModel::surfaceIntersection(), and Isis::Spice::target().

Referenced by Isis::StereoTool::calculateElevation(), and Isis::Sensor::UniversalLongitude().

PvlObject Isis::Spice::getStoredNaifKeywords ( ) const

inherited

This returns the PvlObject that stores all of the requested Naif data and can be a replacement for furnishing text kernels.

Definition at line 874 of file Spice.cpp.

QString Isis::Spice::getString	(	const QString &	key,
		int	index = `0`
	)

inherited

This returns a value from the NAIF text pool.

It is a static convience method

Parameters

key	Name of NAIF keyword to obtain from the pool
index	If the keyword is an array, the element to obtain. Defaults to 0

Returns: string Value from the NAIF text pool

Exceptions

Isis::IException::Io - "Can not find key in instrument kernels."

Definition at line 1128 of file Spice.cpp.

Referenced by Isis::LightTimeCorrectionState::checkAberrationCorrection(), Isis::LightTimeCorrectionState::checkLightTimeToSurfaceCorrect(), Isis::LightTimeCorrectionState::checkObserverTargetSwap(), computeFocalLength(), MdisCamera(), and Isis::NewHorizonsLorriCamera::NewHorizonsLorriCamera().

SurfacePoint Isis::Sensor::GetSurfacePoint ( ) const

inherited

Returns the surface point (most efficient accessor).

Returns: SurfacePoint Coordinate for the surface intersection.

Definition at line 269 of file Sensor.cpp.

References Isis::Target::shape(), Isis::ShapeModel::surfaceIntersection(), and Isis::Spice::target().

Referenced by Isis::ControlPoint::ComputeResiduals(), Isis::QnetPointDistanceFilter::filter(), Isis::Camera::GetLocalNormal(), Isis::Camera::LocalPhotometricAngles(), Isis::SunShadowTool::recalculateShadowHeight(), and Isis::QnetSetAprioriDialog::setApriori().

double Isis::Camera::GroundAzimuth	(	double	glat,
		double	glon,
		double	slat,
		double	slon
	)

staticinherited

Computes and returns the ground azimuth between the ground point and another point of interest, such as the subspacecraft point or the subsolar point.

The ground azimuth is the clockwise angle on the ground between a line drawn from the ground point to the North pole of the body and a line drawn from the selected point on the surface to some point of interest on the surface (such as the subsolar point or the subspacecraft point).

Note: This is different from the image azimuth algorithm used in ComputeAzimuth(). For ground azimuths, the initial ray of the angle is the vector from the selected ground point to the north pole. For image azimuths, the initial ray is the vector from the selected image location to the right, horizontally.

Parameters

glat	The latitude of the ground point
glon	The longitude of the ground point
slat	The latitude of the subspacecraft or subsolar point
slon	The longitude of the subspacecraft or subsolar point

Returns: double The azimuth in degrees

Definition at line 2013 of file Camera.cpp.

References Isis::PI().

CameraGroundMap * Isis::Camera::GroundMap ( )

inherited

Returns a pointer to the CameraGroundMap object.

Returns: CameraCGroundMap*

Reimplemented in Isis::LineScanCamera, and Isis::PushFrameCamera.

Definition at line 2584 of file Camera.cpp.

References Isis::Camera::p_groundMap.

Referenced by Isis::BundleAdjust::AddPartials(), Isis::BundleAdjust::ComputePartials_DC(), Isis::ControlPoint::ComputeResiduals(), Isis::ControlPoint::ComputeResiduals_Millimeters(), and Isis::VimsCamera::VimsCamera().

bool Isis::Camera::GroundRange	(	double &	minlat,
		double &	maxlat,
		double &	minlon,
		double &	maxlon,
		Pvl &	pvl
	)

inherited

Computes the Ground Range.

Parameters

minlat	The minimum latitude
maxlat	The maximum latitude
minlon	The minimum longitude
maxlon	The maximum longitude
pvl	The pvl file used for ground range calculations

Returns: bool Returns true if it crosses the longitude domain boundary and false if it does not

Definition at line 948 of file Camera.cpp.

References Isis::PvlObject::findGroup(), Isis::Camera::GroundRangeResolution(), Isis::PvlContainer::hasKeyword(), Isis::Distance::Meters, Isis::Camera::p_maxlat, Isis::Camera::p_maxlon, Isis::Camera::p_maxlon180, Isis::Camera::p_minlat, Isis::Camera::p_minlon, Isis::Camera::p_minlon180, Isis::PI(), Isis::Spice::radii(), Isis::toDouble(), and Isis::PvlObject::Traverse.

Referenced by Isis::UniversalGroundMap::GroundRange(), and Isis::Camera::IntersectsLongitudeDomain().

bool Isis::Spice::hasKernels ( Pvl & lab )

inherited

Returns true if the kernel group has kernel files.

Parameters

lab	Label containing Instrument and Kernels groups.

Returns: bool status of kernel files in the kernel group

Definition at line 1334 of file Spice.cpp.

References Isis::PvlObject::findGroup(), Isis::PvlContainer::hasKeyword(), Isis::PvlKeyword::size(), and Isis::IString::UpCase().

bool Isis::Camera::HasProjection ( )

inherited

Checks to see if the camera object has a projection.

Returns: bool Returns true if it has a projection and false if it does not

Definition at line 2392 of file Camera.cpp.

References Isis::Camera::p_projection.

Referenced by Isis::CubeViewport::CubeViewport(), and Isis::ImagePolygon::initCube().

bool Isis::Camera::HasReferenceBand ( ) const

inherited

Checks to see if the Camera object has a reference band.

Returns: bool Returns true if it has a reference band, and false if it does not

Definition at line 2421 of file Camera.cpp.

References Isis::Camera::p_referenceBand.

Referenced by Isis::ThemisVisCamera::BandEphemerisTimeOffset(), and Isis::ThemisIrCamera::SetBand().

bool Isis::Sensor::HasSurfaceIntersection ( ) const

inherited

Returns if the last call to either SetLookDirection or SetUniversalGround had a valid intersection with the target.

If so then other methods such as Coordinate, UniversalLatitude, UniversalLongitude, etc can be used with confidence.

Returns: bool True if the look direction intersects with the target.

Definition at line 200 of file Sensor.cpp.

References Isis::ShapeModel::hasIntersection(), Isis::Target::shape(), and Isis::Spice::target().

Referenced by Isis::CameraStatistics::addStats(), Isis::Camera::ComputeAzimuth(), Isis::Camera::DetectorResolution(), Isis::Chip::Load(), Isis::VimsGroundMap::SetGround(), and Isis::Camera::SetImage().

double Isis::Camera::HighestImageResolution ( )

inherited

Returns the highest/best resolution in the entire image.

Returns: double The highest/best resolution in the entire image

Definition at line 526 of file Camera.cpp.

References Isis::Camera::GroundRangeResolution(), and Isis::Camera::p_minres.

void Isis::Sensor::IgnoreElevationModel ( bool ignore )

inherited

This allows you to ignore the cube elevation model and use the ellipse.

Parameters

ignore Indicates whether the elevation model is ignored.

Definition at line 75 of file Sensor.cpp.

References Isis::Target::restoreShape(), Isis::Target::setShapeEllipsoid(), and Isis::Spice::target().

Referenced by Isis::StereoTool::calculateElevation(), Isis::ImagePolygon::Create(), and Isis::ImagePolygon::initCube().

void Isis::Camera::IgnoreProjection ( bool ignore )

inherited

Set whether or not the camera should ignore the Projection.

Parameters

ignore

Definition at line 2642 of file Camera.cpp.

References Isis::Camera::p_ignoreProjection.

Referenced by Isis::VimsSkyMap::Init(), Isis::VimsGroundMap::Init(), Isis::VimsGroundMap::SetGround(), Isis::VimsSkyMap::SetSky(), and Isis::VimsCamera::VimsCamera().

double Isis::Sensor::IncidenceAngle ( ) const

inherited

Returns the incidence angle in degrees.

This does not use the surface model.

Returns: double Incidence angle, in degrees.

Definition at line 349 of file Sensor.cpp.

References Isis::ShapeModel::incidenceAngle(), Isis::Spice::m_uB, Isis::Target::shape(), and Isis::Spice::target().

Referenced by Isis::CameraStatistics::addStats(), Isis::ImagePolygon::FixPolePoly(), Isis::InterestOperator::InterestByMeasure(), Isis::CubeCalculator::prepareCalculations(), Isis::SunShadowTool::recalculateShadowHeight(), Isis::ImagePolygon::SetImage(), and Isis::AdvancedTrackTool::updateRow().

bool Isis::Camera::InCube ( )

inherited

This returns true if the current Sample() or Line() value is outside of the cube (meaning the point must have been extrapolated).

Returns: bool Point was extrapolated

Definition at line 2374 of file Camera.cpp.

References Isis::Camera::Line(), Isis::Camera::Lines(), Isis::Camera::Sample(), and Isis::Camera::Samples().

Referenced by Isis::MosaicSceneItem::drawImage(), Isis::InterestOperator::FindCnetRef(), Isis::SmtkMatcher::getLineSample(), Isis::UniversalGroundMap::SetGround(), and Isis::UniversalGroundMap::SetUniversalGround().

void Isis::Spice::instrumentBodyFixedPosition ( double p[3] ) const

inherited

Returns the spacecraft position in body-fixed frame km units.

Parameters

p[]	Spacecraft position

See Also: setTime()

Exceptions

Isis::iException::Programmer - "You must call SetTime first"

Definition at line 724 of file Spice.cpp.

References _FILEINFO_.

void Isis::Spice::instrumentBodyFixedVelocity ( double v[3] ) const

inherited

Returns the spacecraft velocity in body-fixed frame km/sec units.

Parameters

v[]	Spacecraft velocity

Definition at line 741 of file Spice.cpp.

References _FILEINFO_.

QString Isis::Camera::instrumentNameLong ( ) const

virtualinherited

This method returns the full instrument name.

Returns: QString

Implements Isis::Sensor.

Reimplemented in Isis::IdealCamera.

Definition at line 2603 of file Camera.cpp.

References Isis::Camera::m_instrumentNameLong.

QString Isis::Camera::instrumentNameShort ( ) const

virtualinherited

This method returns the shortened instrument name.

Returns: QString

Implements Isis::Sensor.

Reimplemented in Isis::IdealCamera.

Definition at line 2613 of file Camera.cpp.

References Isis::Camera::m_instrumentNameShort.

void Isis::Spice::instrumentPosition ( double p[3] ) const

inherited

Returns the spacecraft position in body-fixed frame km units.

Parameters

p[]	Spacecraft position

See Also: setTime()

Exceptions

Isis::iException::Programmer - "You must call SetTime first"

Definition at line 711 of file Spice.cpp.

SpicePosition * Isis::Spice::instrumentPosition ( ) const

inherited

Accessor method for the instrument position.

Returns: iTime Instrument position for the image.

Author: Steven Lambright

History:: 2011-02-09 Steven Lambright - Original version.

Definition at line 1395 of file Spice.cpp.

Referenced by Isis::Camera::DetectorResolution(), Isis::Sensor::EmissionAngle(), Isis::Camera::LocalPhotometricAngles(), Isis::LoHighCamera::LoHighCamera(), Isis::LoMediumCamera::LoMediumCamera(), Isis::Mariner10Camera::Mariner10Camera(), Isis::MiniRF::MiniRF(), Isis::Camera::OffNadirAngle(), Isis::Sensor::PhaseAngle(), Isis::Sensor::SetGroundLocal(), Isis::Sensor::SetLookDirection(), Isis::Sensor::SlantDistance(), and Isis::Sensor::SpacecraftAltitude().

SpiceRotation * Isis::Spice::instrumentRotation ( ) const

inherited

Accessor method for the instrument rotation.

Returns: iTime Instrument rotation for the image.

Author: Steven Lambright

History:: 2011-02-09 Steven Lambright - Original version.

Definition at line 1417 of file Spice.cpp.

bool Isis::Camera::IntersectsLongitudeDomain ( Pvl & pvl )

inherited

Checks whether the ground range intersects the longitude domain or not.

Parameters

pvl	The pvl file used to set the ground range

Returns: bool Returns true if the range intersects the longitude domain, and false if it does not

Definition at line 931 of file Camera.cpp.

References Isis::Camera::GroundRange().

bool Isis::Camera::IsBandIndependent ( )

virtualinherited

Virtual method that checks if the band is independent.

Returns: bool Returns true if the band is independent, and false if it is not

Reimplemented in Isis::LroWideAngleCamera, Isis::ThemisVisCamera, Isis::ThemisIrCamera, Isis::CrismCamera, Isis::MarciCamera, and Isis::NewHorizonsLeisaCamera.

Definition at line 2402 of file Camera.cpp.

Referenced by Isis::ProjectionFactory::CreateForCube(), Isis::Camera::GroundRangeResolution(), Isis::CameraStatistics::init(), Isis::Camera::RaDecRange(), Isis::Camera::ringRangeResolution(), and Isis::ProjectionFactory::RingsCreateForCube().

double Isis::Camera::Line ( )

inherited

Returns the current line number.

Returns: double Line Number

Definition at line 2457 of file Camera.cpp.

References Isis::Camera::p_childLine.

Referenced by Isis::QnetTool::addMeasure(), Isis::Camera::ComputeAzimuth(), Isis::QnetTool::createFixedPoint(), Isis::ProjectionFactory::CreateForCube(), Isis::QnetTool::createPoint(), Isis::MosaicSceneItem::drawImage(), Isis::InterestOperator::FindCnetRef(), Isis::ImagePolygon::FixPolePoly(), Isis::SmtkMatcher::getLineSample(), Isis::Camera::GetLocalNormal(), Isis::Camera::GroundRangeResolution(), Isis::IdealCamera::IdealCamera(), Isis::Camera::InCube(), Isis::UniversalGroundMap::Line(), Isis::Chip::Load(), Isis::Camera::RaDecRange(), Isis::Camera::RaDecResolution(), and Isis::Camera::ringRangeResolution().

double Isis::Camera::LineResolution ( )

inherited

Returns the line resolution at the current position.

Returns: double The line resolution

Definition at line 494 of file Camera.cpp.

References Isis::Camera::DetectorResolution(), Isis::CameraDetectorMap::LineScaleFactor(), and Isis::Camera::p_detectorMap.

Referenced by Isis::CameraStatistics::addStats(), and Isis::Camera::PixelResolution().

int Isis::Camera::Lines ( ) const

inherited

Returns the number of lines in the image.

Returns: int Number of Lines

Definition at line 2522 of file Camera.cpp.

References Isis::Camera::p_lines.

Referenced by Isis::ProjectionFactory::CreateForCube(), Isis::SmtkMatcher::inCube(), Isis::Camera::InCube(), Isis::CameraStatistics::init(), Isis::NewHorizonsMvicFrameCameraDistortionMap::NewHorizonsMvicFrameCameraDistortionMap(), Isis::DawnVirCamera::readHouseKeeping(), and Isis::ProjectionFactory::RingsCreateForCube().

void Isis::Camera::LoadCache ( )

inherited

This loads the spice cache big enough for this image.

The default cache size is the number of lines in the cube if the ephemeris time changes in the image, one otherwise.

History:: 2011-02-08 Jeannie Walldren - Removed unused input parameter. Moved calculations of cache size and start/end ephemeris times to their own methods.

Definition at line 2184 of file Camera.cpp.

References Isis::AlphaCube::BetaLines(), Isis::AlphaCube::BetaSamples(), Isis::Camera::CacheSize(), Isis::Spice::createCache(), Isis::Camera::FocalLength(), Isis::Camera::p_alphaCube, Isis::Camera::p_ignoreProjection, Isis::Camera::PixelPitch(), Isis::Camera::PixelResolution(), Isis::Camera::SetBand(), Isis::Camera::SetImage(), Isis::Sensor::setTime(), Isis::Sensor::SpacecraftAltitude(), Isis::Camera::StartEndEphemerisTimes(), and Isis::Spice::target().

Referenced by Isis::AmicaCamera::AmicaCamera(), Isis::ApolloMetricCamera::ApolloMetricCamera(), Isis::ApolloPanoramicCamera::ApolloPanoramicCamera(), Isis::Chandrayaan1M3Camera::Chandrayaan1M3Camera(), Isis::CrismCamera::CrismCamera(), Isis::CTXCamera::CTXCamera(), Isis::DawnFcCamera::DawnFcCamera(), Isis::HiresCamera::HiresCamera(), Isis::HiriseCamera::HiriseCamera(), Isis::HrscCamera::HrscCamera(), Isis::IdealCamera::IdealCamera(), Isis::IssNACamera::IssNACamera(), Isis::IssWACamera::IssWACamera(), Isis::KaguyaMiCamera::KaguyaMiCamera(), Isis::LoHighCamera::LoHighCamera(), Isis::LoMediumCamera::LoMediumCamera(), Isis::LroNarrowAngleCamera::LroNarrowAngleCamera(), Isis::LroWideAngleCamera::LroWideAngleCamera(), Isis::LwirCamera::LwirCamera(), Isis::MarciCamera::MarciCamera(), Isis::Mariner10Camera::Mariner10Camera(), MdisCamera(), Isis::MocNarrowAngleCamera::MocNarrowAngleCamera(), Isis::MocWideAngleCamera::MocWideAngleCamera(), Isis::MsiCamera::MsiCamera(), Isis::NewHorizonsLeisaCamera::NewHorizonsLeisaCamera(), Isis::NewHorizonsLorriCamera::NewHorizonsLorriCamera(), Isis::NewHorizonsMvicFrameCamera::NewHorizonsMvicFrameCamera(), Isis::NewHorizonsMvicTdiCamera::NewHorizonsMvicTdiCamera(), Isis::NirCamera::NirCamera(), Isis::SsiCamera::SsiCamera(), Isis::ThemisIrCamera::ThemisIrCamera(), Isis::ThemisVisCamera::ThemisVisCamera(), Isis::UvvisCamera::UvvisCamera(), Isis::VikingCamera::VikingCamera(), and Isis::VoyagerCamera::VoyagerCamera().

void Isis::Camera::LocalPhotometricAngles	(	Angle &	phase,
		Angle &	incidence,
		Angle &	emission,
		bool &	success
	)

inherited

Calculates LOCAL photometric angles using the DEM (not ellipsoid).

These calculations are more expensive computationally than Sensor's angle getter methods. Furthermore, this cost is mostly in calculating the local normal vector, which can be done only once for all angles using this method.

Parameters

phase	The local phase angle to be calculated
emission	The local emission angle to be calculated
incidence	The local incidence angle to be calculated

Definition at line 1406 of file Camera.cpp.

References Isis::Spice::bodyRotation(), Isis::Sensor::Coordinate(), Isis::Camera::GetLocalNormal(), Isis::Sensor::GetSurfacePoint(), Isis::Spice::instrumentPosition(), Isis::Displacement::kilometers(), Isis::Spice::m_uB, Isis::Angle::Radians, and Isis::SpiceRotation::ReferenceVector().

Referenced by Isis::AdvancedTrackTool::updateRow().

Distance Isis::Sensor::LocalRadius ( ) const

inherited

Returns the local radius at the intersection point.

This is either the radius on the ellipsoid, the radius from the surface model passed into the constructor, or the radius set with SetUniversalGround.

Returns: Distance The local radius at the surface intersection.

Definition at line 281 of file Sensor.cpp.

References Isis::SurfacePoint::GetLocalRadius(), Isis::Target::shape(), Isis::ShapeModel::surfaceIntersection(), and Isis::Spice::target().

Referenced by Isis::CameraStatistics::addStats(), Isis::StereoTool::calculateElevation(), Isis::Camera::ComputeAzimuth(), Isis::FindTool::distancePerPixel(), Isis::QnetCubeDistanceFilter::filter(), Isis::Camera::GetLocalNormal(), Isis::Camera::GroundRangeResolution(), Isis::RadarGroundMap::Iterate(), Isis::Camera::NorthAzimuth(), Isis::ControlNetFilter::PointDistanceFilter(), Isis::ControlNetFilter::PointLatLonFilter(), Isis::Camera::RawFocalPlanetoImage(), Isis::Camera::ringRangeResolution(), Isis::ProjectionFactory::RingsCreateForCube(), Isis::PushFrameCameraGroundMap::SetGround(), Isis::LineScanCameraGroundMap::SetGround(), Isis::VimsGroundMap::SetGround(), Isis::RadarGroundMap::SetGround(), Isis::Camera::SetGround(), Isis::Camera::SetImage(), Isis::Sensor::SetUniversalGround(), Isis::Sensor::SpacecraftAltitude(), Isis::Camera::SpacecraftAzimuth(), Isis::Camera::SunAzimuth(), Isis::TrackTool::updateLabels(), and Isis::AdvancedTrackTool::updateRow().

Distance Isis::Sensor::LocalRadius	(	Latitude	lat,
		Longitude	lon
	)

inherited

Returns the local radius at the intersection point.

This is either the radius on the ellipsoid, the radius from the surface model passed into the constructor, or the radius set with SetUniversalGround.

Parameters

lat
lon

Returns: Distance The distance from the center of the planet to this lat,lon in meters.

Definition at line 299 of file Sensor.cpp.

References Isis::Target::shape(), and Isis::Spice::target().

Distance Isis::Sensor::LocalRadius	(	double	lat,
		double	lon
	)

inherited

Returns the local radius at the intersection point.

This is either the radius on the ellipsoid, the radius from the surface model passed into the constructor, or the radius set with SetUniversalGround.

Parameters

lat
lon

Returns: Distance The distance from the center of the planet to this lat,lon in meters.

Definition at line 315 of file Sensor.cpp.

References Isis::Angle::Degrees, Isis::Target::shape(), and Isis::Spice::target().

double Isis::Sensor::LocalSolarTime ( )

inherited

Return the local solar time in hours.

Returns: double Local solar time, in hours.

Definition at line 626 of file Sensor.cpp.

References Isis::Spice::subSolarPoint(), and Isis::Sensor::UniversalLongitude().

Referenced by Isis::CameraStatistics::addStats(), and Isis::AdvancedTrackTool::updateRow().

void Isis::Sensor::LookDirection ( double v[3] ) const

inherited

Returns the look direction in the camera coordinate system.

Parameters

v[]	The look vector.

Definition at line 513 of file Sensor.cpp.

References Isis::Spice::bodyRotation(), Isis::Spice::instrumentRotation(), Isis::SpiceRotation::J2000Vector(), Isis::Sensor::m_lookB, and Isis::SpiceRotation::ReferenceVector().

double Isis::Camera::LowestImageResolution ( )

inherited

Returns the lowest/worst resolution in the entire image.

Returns: double The lowest/worst resolution in the image

Definition at line 516 of file Camera.cpp.

References Isis::Camera::GroundRangeResolution(), and Isis::Camera::p_maxres.

SpiceInt Isis::Spice::naifBodyCode ( ) const

inherited

This returns the NAIF body code of the target indicated in the labels.

Returns: SpiceInt NAIF body code

Definition at line 817 of file Spice.cpp.

Referenced by Isis::Camera::SpkCenterId().

SpiceInt Isis::Spice::naifBodyFrameCode ( ) const

inherited

This returns the NAIF body frame code.

It is read from the labels, if it exists. Otherwise, it's calculated by the init() method.

Returns: SpiceInt NAIF body frame code

Definition at line 865 of file Spice.cpp.

SpiceInt Isis::Spice::naifCkCode ( ) const

inherited

This returns the NAIF CK code to use when reading from CK kernels.

Returns: SpiceInt NAIF CK code

Definition at line 835 of file Spice.cpp.

SpiceInt Isis::Spice::naifIkCode ( ) const

inherited

This returns the NAIF IK code to use when reading from instrument kernels.

Returns: SpiceInt NAIF IK code

Definition at line 844 of file Spice.cpp.

Referenced by Isis::AmicaCamera::AmicaCamera(), Isis::ApolloMetricCamera::ApolloMetricCamera(), Isis::ApolloPanoramicCamera::ApolloPanoramicCamera(), Isis::Chandrayaan1M3Camera::Chandrayaan1M3Camera(), Isis::CrismCamera::CrismCamera(), Isis::CTXCamera::CTXCamera(), Isis::DawnFcCamera::DawnFcCamera(), Isis::HiresCamera::HiresCamera(), Isis::HiriseCamera::HiriseCamera(), Isis::HrscCamera::HrscCamera(), Isis::IssNACamera::IssNACamera(), Isis::IssWACamera::IssWACamera(), Isis::KaguyaMiCamera::KaguyaMiCamera(), Isis::LoHighCamera::LoHighCamera(), Isis::LoMediumCamera::LoMediumCamera(), Isis::LroNarrowAngleCamera::LroNarrowAngleCamera(), Isis::LroWideAngleCamera::LroWideAngleCamera(), Isis::LwirCamera::LwirCamera(), Isis::MarciCamera::MarciCamera(), Isis::Mariner10Camera::Mariner10Camera(), MdisCamera(), Isis::MiniRF::MiniRF(), Isis::MocNarrowAngleCamera::MocNarrowAngleCamera(), Isis::MocWideAngleCamera::MocWideAngleCamera(), Isis::MsiCamera::MsiCamera(), Isis::NewHorizonsLeisaCamera::NewHorizonsLeisaCamera(), Isis::NewHorizonsLorriCamera::NewHorizonsLorriCamera(), Isis::NewHorizonsMvicFrameCamera::NewHorizonsMvicFrameCamera(), Isis::NewHorizonsMvicTdiCamera::NewHorizonsMvicTdiCamera(), Isis::NirCamera::NirCamera(), Isis::Camera::SetFocalLength(), Isis::Camera::SetPixelPitch(), Isis::SsiCamera::SsiCamera(), Isis::ThemisIrCamera::ThemisIrCamera(), Isis::ThemisVisCamera::ThemisVisCamera(), Isis::UvvisCamera::UvvisCamera(), Isis::VikingCamera::VikingCamera(), Isis::VimsCamera::VimsCamera(), and Isis::VoyagerCamera::VoyagerCamera().

SpiceInt Isis::Spice::naifSclkCode ( ) const

inherited

This returns the NAIF SCLK code to use when reading from instrument kernels.

Returns: SpiceInt NAIF SCLK code

Definition at line 854 of file Spice.cpp.

Referenced by Isis::CrismCamera::CrismCamera().

SpiceInt Isis::Spice::naifSpkCode ( ) const

inherited

This returns the NAIF SPK code to use when reading from SPK kernels.

Returns: SpiceInt NAIF SPK code

Definition at line 826 of file Spice.cpp.

Referenced by Isis::DawnVirCamera::readHouseKeeping(), and Isis::Camera::SpkTargetId().

double Isis::Camera::NorthAzimuth ( )

inherited

Returns the North Azimuth.

Returns: double North Azimuth

Definition at line 1670 of file Camera.cpp.

References _FILEINFO_, Isis::Camera::ComputeAzimuth(), Isis::Sensor::LocalRadius(), Isis::IException::Programmer, Isis::Spice::target(), and Isis::Sensor::UniversalLatitude().

Referenced by Isis::CameraStatistics::addStats(), and Isis::AdvancedTrackTool::updateRow().

double Isis::Camera::OffNadirAngle ( )

inherited

Return the off nadir angle in degrees.

Returns: double Off Nadir Angle

Definition at line 1972 of file Camera.cpp.

References Isis::NaifStatus::CheckErrors(), Isis::Sensor::Coordinate(), Isis::Sensor::EmissionAngle(), Isis::Spice::instrumentPosition(), and Isis::PI().

int Isis::Camera::ParentLines ( ) const

inherited

Returns the number of lines in the parent alphacube.

Returns: int Number of Lines in parent alphacube

Definition at line 2540 of file Camera.cpp.

References Isis::AlphaCube::AlphaLines(), and Isis::Camera::p_alphaCube.

Referenced by Isis::ApolloMetricCamera::ApolloMetricCamera(), Isis::CrismCamera::CrismCamera(), Isis::DawnFcCamera::DawnFcCamera(), Isis::VimsSkyMap::Init(), Isis::VimsGroundMap::Init(), Isis::LroWideAngleCamera::LroWideAngleCamera(), Isis::MarciCamera::MarciCamera(), Isis::MiniRF::MiniRF(), Isis::VimsSkyMap::SetFocalPlane(), Isis::VimsGroundMap::SetFocalPlane(), Isis::VimsGroundMap::SetGround(), Isis::VimsSkyMap::SetSky(), Isis::ThemisVisCamera::ThemisVisCamera(), Isis::PushFrameCameraDetectorMap::TotalFramelets(), and Isis::VimsGroundMap::VimsGroundMap().

int Isis::Camera::ParentSamples ( ) const

inherited

Returns the number of samples in the parent alphacube.

Returns: int Number of Samples in the parent alphacube

Definition at line 2549 of file Camera.cpp.

References Isis::AlphaCube::AlphaSamples(), and Isis::Camera::p_alphaCube.

Referenced by Isis::ApolloMetricCamera::ApolloMetricCamera(), Isis::DawnFcCamera::DawnFcCamera(), Isis::VimsSkyMap::Init(), Isis::VimsGroundMap::Init(), Isis::VimsSkyMap::SetFocalPlane(), Isis::VimsGroundMap::SetFocalPlane(), Isis::VimsGroundMap::SetGround(), Isis::VimsSkyMap::SetSky(), and Isis::VimsGroundMap::VimsGroundMap().

double Isis::Sensor::PhaseAngle ( ) const

inherited

Returns the phase angle in degrees.

This does not use the surface model.

Returns: double Phase angle, in degrees.

Definition at line 326 of file Sensor.cpp.

References Isis::Spice::bodyRotation(), Isis::Sensor::Coordinate(), Isis::Spice::instrumentPosition(), Isis::Spice::m_uB, Isis::ShapeModel::phaseAngle(), Isis::Target::shape(), and Isis::Spice::target().

Referenced by Isis::CameraStatistics::addStats(), Isis::CubeCalculator::prepareCalculations(), and Isis::AdvancedTrackTool::updateRow().

QList< QPointF > Isis::Camera::PixelIfovOffsets ( )

virtualinherited

Returns the pixel ifov offsets from center of pixel, which defaults to the (pixel pitch * summing mode ) / 2.

If an instrument has a non-square ifov, it must implement this method to return the offsets from the center of the pixel.

Reimplemented from Isis::Sensor.

Reimplemented in Isis::VimsCamera.

Definition at line 2492 of file Camera.cpp.

References Isis::Camera::DetectorMap(), and Isis::Camera::PixelPitch().

double Isis::Camera::PixelPitch ( ) const

inherited

Returns the pixel pitch.

Returns: double Pixel Pitch

Definition at line 2482 of file Camera.cpp.

References Isis::Camera::p_pixelPitch.

Referenced by Isis::BundleAdjust::AddPartials(), Isis::BundleAdjust::ComputePartials_DC(), Isis::NewHorizonsMvicTdiCameraDistortionMap::computeResidualDistortionCorrections(), Isis::CrismCamera::CrismCamera(), Isis::IdealCamera::IdealCamera(), Isis::Camera::LoadCache(), Isis::MiniRF::MiniRF(), Isis::MocWideAngleCamera::MocWideAngleCamera(), Isis::NewHorizonsMvicFrameCameraDistortionMap::NewHorizonsMvicFrameCameraDistortionMap(), Isis::NewHorizonsMvicTdiCameraDistortionMap::NewHorizonsMvicTdiCameraDistortionMap(), Isis::Camera::PixelIfovOffsets(), Isis::ReseauDistortionMap::ReseauDistortionMap(), Isis::KaguyaMiCameraDistortionMap::SetDistortion(), Isis::MarciDistortionMap::SetFocalPlane(), Isis::MarciDistortionMap::SetUndistortedFocalPlane(), Isis::CameraDistortionMap::SetUndistortedFocalPlane(), and Isis::VimsCamera::VimsCamera().

double Isis::Camera::PixelResolution ( )

inherited

Returns the pixel resolution at the current position in m/pix.

Returns: double The pixel resolution

Definition at line 503 of file Camera.cpp.

References Isis::Camera::LineResolution(), and Isis::Camera::SampleResolution().

Referenced by Isis::CameraStatistics::addStats(), Isis::Camera::ComputeAzimuth(), Isis::Camera::GroundRangeResolution(), Isis::InterestOperator::InterestByMeasure(), Isis::Camera::LoadCache(), Isis::ControlNetValidMeasure::MetersFromEdge(), Isis::MiniRF::MiniRF(), Isis::UniversalGroundMap::Resolution(), Isis::Camera::resolution(), Isis::Camera::ringRangeResolution(), Isis::MeasureTool::updateDist(), Isis::AdvancedTrackTool::updateRow(), and Isis::VimsCamera::VimsCamera().

bool Isis::Camera::RaDecRange	(	double &	minra,
		double &	maxra,
		double &	mindec,
		double &	maxdec
	)

inherited

Computes the RaDec range.

Parameters

minra	Minimum right ascension value
maxra	Maximum right ascension value
mindec	Minimum declination value
maxdec	Maximum declination value

Exceptions

iException::Programmer - "Camera::RaDecRange can not calculate a right ascension, declination range for projected images which are not projected to sky"

Returns: bool Returns true if the range computation was successful and false if it was not

Definition at line 1473 of file Camera.cpp.

References _FILEINFO_, Isis::Camera::Band(), Isis::Sensor::Declination(), Isis::Camera::IsBandIndependent(), Isis::Projection::IsSky(), Isis::Camera::Line(), Isis::Camera::p_bands, Isis::Camera::p_lines, Isis::Camera::p_maxdec, Isis::Camera::p_maxra, Isis::Camera::p_maxra180, Isis::Camera::p_mindec, Isis::Camera::p_minra, Isis::Camera::p_minra180, Isis::Camera::p_pointComputed, Isis::Camera::p_projection, Isis::Camera::p_samples, Isis::IException::Programmer, Isis::Sensor::RightAscension(), Isis::Camera::Sample(), Isis::Camera::SetBand(), Isis::Camera::SetImage(), and Isis::Camera::SetRightAscensionDeclination().

double Isis::Camera::RaDecResolution ( )

inherited

Returns the RaDec resolution.

Returns: double The resutant RaDec resolution

Definition at line 1620 of file Camera.cpp.

References _FILEINFO_, Isis::Camera::Band(), Isis::Sensor::Declination(), Isis::Projection::IsSky(), Isis::Camera::Line(), Isis::Camera::p_lines, Isis::Camera::p_pointComputed, Isis::Camera::p_projection, Isis::Camera::p_samples, Isis::IException::Programmer, Isis::Sensor::RightAscension(), Isis::Camera::Sample(), Isis::Camera::SetBand(), and Isis::Camera::SetImage().

void Isis::Spice::radii ( Distance r[3] ) const

inherited

Returns the radii of the body in km.

The radii are obtained from the appropriate SPICE kernel for the body specified by TargetName in the Instrument group of the labels.

Parameters

r[]	Radii of the target in kilometers

Definition at line 806 of file Spice.cpp.

Referenced by Isis::Camera::BasicMapping(), Isis::Camera::GroundRange(), Isis::VimsGroundMap::Init(), Isis::BundleAdjust::Init(), Isis::MiniRF::MiniRF(), Isis::SunShadowTool::recalculateShadowHeight(), Isis::RadarGroundMap::SetFocalPlane(), and Isis::AdvancedTrackTool::updateRow().

QVariant Isis::Spice::readValue	(	QString	key,
		SpiceValueType	type,
		int	index = `0`
	)

protectedinherited

This should be used for reading ALL text naif kernel values.

This will read it from Naif if we're using naif/not attached kernels. If we have attached kernels and a NaifKeywords label object we will grab it from there instead. This allows us to not furnish kernels after spiceinit.

Parameters

key	The naif keyword/value name
type	The naif value's primitive type
index	The index into the naif keyword array to read

Definition at line 960 of file Spice.cpp.

References _FILEINFO_.

Referenced by Isis::IdealCamera::IdealCamera().

int Isis::Camera::ReferenceBand ( ) const

inherited

Returns the reference band.

Returns: int Reference Band

Definition at line 2411 of file Camera.cpp.

References Isis::Camera::p_referenceBand.

Referenced by Isis::ThemisVisCamera::BandEphemerisTimeOffset(), and Isis::ThemisIrCamera::SetBand().

double Isis::Camera::resolution ( )

virtualinherited

Returns the resolution of the camera.

Returns: double pixel resolution

Reimplemented from Isis::Sensor.

Definition at line 2465 of file Camera.cpp.

References Isis::Camera::PixelResolution().

double Isis::Sensor::RightAscension ( )

inherited

Returns the right ascension angle (sky longitude).

Returns: double The angle of right ascension, in degrees.

Definition at line 531 of file Sensor.cpp.

References Isis::Sensor::computeRaDec(), Isis::Sensor::m_newLookB, and Isis::Sensor::m_ra.

Referenced by Isis::VimsSkyMap::Init(), Isis::Camera::RaDecRange(), Isis::Camera::RaDecResolution(), Isis::Camera::RawFocalPlanetoImage(), and Isis::AdvancedTrackTool::updateRow().

bool Isis::Camera::ringRange	(	double &	minRingRadius,
		double &	maxRingRadius,
		double &	minRingLongitude,
		double &	maxRingLongitude,
		Pvl &	pvl
	)

inherited

Analogous to the above Ground Range method.

Computes Range on the ring plane

Parameters

minRingRadius	The minimum ring radius
maxRingRadius	The maximum ring radius
minRingLongitude	The minimum ring longitude
maxRingLongitude	The maximum ring longitude
pvl	The pvl file used for ring range calculations

Returns: bool Returns true if it crosses the longitude domain boundary and false if it does not

Definition at line 1052 of file Camera.cpp.

References Isis::PvlObject::findGroup(), Isis::PvlContainer::hasKeyword(), Isis::Camera::p_maxRingLongitude, Isis::Camera::p_maxRingLongitude180, Isis::Camera::p_maxRingRadius, Isis::Camera::p_minRingLongitude, Isis::Camera::p_minRingLongitude180, Isis::Camera::p_minRingRadius, Isis::Camera::ringRangeResolution(), and Isis::PvlObject::Traverse.

double Isis::Camera::Sample ( )

inherited

Returns the current sample number.

Returns: double Sample Number

Definition at line 2439 of file Camera.cpp.

References Isis::Camera::p_childSample.

Referenced by Isis::QnetTool::addMeasure(), Isis::Camera::ComputeAzimuth(), Isis::QnetTool::createFixedPoint(), Isis::ProjectionFactory::CreateForCube(), Isis::QnetTool::createPoint(), Isis::MosaicSceneItem::drawImage(), Isis::InterestOperator::FindCnetRef(), Isis::ImagePolygon::FixPolePoly(), Isis::SmtkMatcher::getLineSample(), Isis::Camera::GetLocalNormal(), Isis::Camera::GroundRangeResolution(), Isis::IdealCamera::IdealCamera(), Isis::Camera::InCube(), Isis::Chip::Load(), Isis::Camera::RaDecRange(), Isis::Camera::RaDecResolution(), Isis::Camera::ringRangeResolution(), and Isis::UniversalGroundMap::Sample().

double Isis::Camera::SampleResolution ( )

inherited

Returns the sample resolution at the current position.

Returns: double The sample resolution

Definition at line 485 of file Camera.cpp.

References Isis::Camera::DetectorResolution(), Isis::Camera::p_detectorMap, and Isis::CameraDetectorMap::SampleScaleFactor().

Referenced by Isis::CameraStatistics::addStats(), and Isis::Camera::PixelResolution().

int Isis::Camera::Samples ( ) const

inherited

Returns the number of samples in the image.

Returns: int Number of Samples

Definition at line 2513 of file Camera.cpp.

References Isis::Camera::p_samples.

Referenced by Isis::ProjectionFactory::CreateForCube(), Isis::SmtkMatcher::inCube(), Isis::Camera::InCube(), Isis::CameraStatistics::init(), Isis::MiniRF::MiniRF(), Isis::NewHorizonsMvicFrameCameraDistortionMap::NewHorizonsMvicFrameCameraDistortionMap(), Isis::NewHorizonsMvicTdiCameraDistortionMap::NewHorizonsMvicTdiCameraDistortionMap(), Isis::RadarSlantRangeMap::RadarSlantRangeMap(), and Isis::ProjectionFactory::RingsCreateForCube().

void Isis::Camera::SetBand ( const int band )

virtualinherited

Virtual method that sets the band number.

Parameters

band	Band Number

Reimplemented in Isis::LroWideAngleCamera, Isis::ThemisVisCamera, Isis::NewHorizonsLeisaCamera, Isis::ThemisIrCamera, Isis::MarciCamera, Isis::CrismCamera, and Isis::NewHorizonsMvicFrameCamera.

Definition at line 2430 of file Camera.cpp.

References Isis::Camera::p_childBand.

Referenced by Isis::ProjectionFactory::CreateForCube(), Isis::Camera::GroundRangeResolution(), Isis::CameraStatistics::init(), Isis::Camera::LoadCache(), Isis::Camera::RaDecRange(), Isis::Camera::RaDecResolution(), Isis::Camera::ringRangeResolution(), Isis::ProjectionFactory::RingsCreateForCube(), Isis::UniversalGroundMap::SetBand(), Isis::Camera::StartEndEphemerisTimes(), Isis::CubeViewport::viewGray(), and Isis::CubeViewport::viewRGB().

void Isis::Camera::SetDetectorMap ( CameraDetectorMap * map )

inherited

Sets the Detector Map.

This object will take ownership of the detector map pointer.

Parameters

*map	Pointer to a CameraDetectorMap object

Definition at line 2139 of file Camera.cpp.

References Isis::Camera::p_detectorMap.

Referenced by Isis::CameraDetectorMap::CameraDetectorMap().

void Isis::Camera::SetDistortionMap ( CameraDistortionMap * map )

inherited

Sets the Distortion Map.

This object will take ownership of the distortion map pointer.

Parameters

*map	Pointer to a CameraDistortionMap object

Definition at line 2111 of file Camera.cpp.

References Isis::Camera::p_distortionMap.

Referenced by Isis::CameraDistortionMap::CameraDistortionMap().

void Isis::Camera::SetFocalLength ( double v )

protectedinherited

Sets the focal length.

Parameters

v	Focal Length

Definition at line 2731 of file Camera.cpp.

References Isis::Camera::p_focalLength.

Referenced by Isis::RadarSlantRangeMap::SetFocalPlane(), and Isis::RadarGroundMap::SetGround().

void Isis::Camera::SetFocalLength ( )

protectedinherited

Reads the focal length from the instrument kernel.

Definition at line 1176 of file Camera.cpp.

References Isis::Spice::getDouble(), Isis::Spice::naifIkCode(), and Isis::toString().

Referenced by Isis::AmicaCamera::AmicaCamera(), Isis::ApolloMetricCamera::ApolloMetricCamera(), Isis::ApolloPanoramicCamera::ApolloPanoramicCamera(), Isis::Chandrayaan1M3Camera::Chandrayaan1M3Camera(), Isis::CrismCamera::CrismCamera(), Isis::CTXCamera::CTXCamera(), Isis::DawnFcCamera::DawnFcCamera(), Isis::HiresCamera::HiresCamera(), Isis::HiriseCamera::HiriseCamera(), Isis::HrscCamera::HrscCamera(), Isis::IdealCamera::IdealCamera(), Isis::IssNACamera::IssNACamera(), Isis::IssWACamera::IssWACamera(), Isis::KaguyaMiCamera::KaguyaMiCamera(), Isis::LoHighCamera::LoHighCamera(), Isis::LoMediumCamera::LoMediumCamera(), Isis::LroNarrowAngleCamera::LroNarrowAngleCamera(), Isis::LroWideAngleCamera::LroWideAngleCamera(), Isis::LwirCamera::LwirCamera(), Isis::MarciCamera::MarciCamera(), Isis::Mariner10Camera::Mariner10Camera(), MdisCamera(), Isis::MiniRF::MiniRF(), Isis::MocNarrowAngleCamera::MocNarrowAngleCamera(), Isis::MocWideAngleCamera::MocWideAngleCamera(), Isis::MsiCamera::MsiCamera(), Isis::NewHorizonsLeisaCamera::NewHorizonsLeisaCamera(), Isis::NewHorizonsLorriCamera::NewHorizonsLorriCamera(), Isis::NewHorizonsMvicFrameCamera::NewHorizonsMvicFrameCamera(), Isis::NewHorizonsMvicTdiCamera::NewHorizonsMvicTdiCamera(), Isis::NirCamera::NirCamera(), Isis::LroWideAngleCamera::SetBand(), Isis::SsiCamera::SsiCamera(), Isis::ThemisIrCamera::ThemisIrCamera(), Isis::ThemisVisCamera::ThemisVisCamera(), Isis::UvvisCamera::UvvisCamera(), Isis::VikingCamera::VikingCamera(), Isis::VimsCamera::VimsCamera(), and Isis::VoyagerCamera::VoyagerCamera().

void Isis::Camera::SetFocalPlaneMap ( CameraFocalPlaneMap * map )

inherited

Sets the Focal Plane Map.

This object will take ownership of the focal plane map pointer.

Parameters

*map	Pointer to a CameraFocalPlaneMap object

Definition at line 2125 of file Camera.cpp.

References Isis::Camera::p_focalPlaneMap.

Referenced by Isis::CameraFocalPlaneMap::CameraFocalPlaneMap(), and Isis::CameraFocalPlaneMap::Init().

void Isis::Camera::SetGeometricTilingHint	(	int	startSize = `128`,
		int	endSize = `8`
	)

protectedinherited

This method sets the best geometric tiling size for projecting from this camera model.

This is used by cam2map/ProcessRubberSheet. When cubes are projected, an attempt is made to use linear equations to take large, square chunks of data at a time to cull the amount of SetUniversalGround(...) calls necessary to project a cube. If the chunk of data fails to be linear, then it will be split up into 4 corners and each of the new chunks (corners) are reconsidered up until endSize is reached - the endsize size will be considered, it is inclusive. The startSize must be a power of 2 greater than 2, and the endSize must be a power of 2 equal to or less than the start size but greater than 2. If both the startSize and endSize are set to 2 then no geometric tiling will be enabled.

Parameters

startSize	The tile size to start with; default 128
endSize	The tile size to give up at; default 8

Definition at line 2310 of file Camera.cpp.

References _FILEINFO_, Isis::Camera::p_geometricTilingEndSize, Isis::Camera::p_geometricTilingStartSize, and Isis::IException::Programmer.

Referenced by Isis::Camera::Camera(), Isis::LroWideAngleCamera::LroWideAngleCamera(), and Isis::MarciCamera::MarciCamera().

bool Isis::Sensor::SetGround	(	const SurfacePoint &	surfacePt,
		bool	backCheck = `true`
	)

inherited

This overloaded method has the opposite function as SetLookDirection.

Instead of computing a point on the target, a point is set and the look direction is computed. Other methods such as lat/lon, phase, incidence, etc. can be used if this method returns a true.

Parameters

backCheck If true this method will check the lat/lon point to see if it falls on the backside of the target (or beyond the horizon). If false this test will not occur. Defaults to true.

Returns: bool

Definition at line 440 of file Sensor.cpp.

References Isis::ShapeModel::clearSurfacePoint(), Isis::Sensor::SetGroundLocal(), Isis::ShapeModel::setSurfacePoint(), Isis::Target::shape(), and Isis::Spice::target().

bool Isis::Camera::SetGround	(	Latitude	latitude,
		Longitude	longitude
	)

inherited

Sets the lat/lon values to get the sample/line values.

Parameters

latitude	Latitude coordinate of the point
longitude	Longitude coordinate of the point

Returns: bool Returns true if the Universal Ground was set successfully and false if it was not

Definition at line 306 of file Camera.cpp.

References Isis::ShapeModel::clearSurfacePoint(), Isis::Angle::Degrees, Isis::Angle::degrees(), Isis::Distance::isValid(), Isis::Distance::Kilometers, Isis::Sensor::LocalRadius(), Isis::ShapeModel::name(), Isis::Target::shape(), and Isis::Spice::target().

Referenced by Isis::Camera::GroundRangeResolution(), Isis::Camera::ringRangeResolution(), Isis::UniversalGroundMap::SetGround(), and Isis::Camera::SetImage().

bool Isis::Camera::SetGround ( const SurfacePoint & surfacePt )

inherited

Sets the lat/lon/radius values to get the sample/line values.

Parameters

latitude	Latitude coordinate of the point
longitude	Longitude coordinate of the point

Returns: bool Returns true if the Universal Ground was set successfully and false if it was not

Definition at line 337 of file Camera.cpp.

References Isis::ShapeModel::clearSurfacePoint(), Isis::Camera::p_groundMap, Isis::Camera::RawFocalPlanetoImage(), Isis::CameraGroundMap::SetGround(), Isis::Target::shape(), and Isis::Spice::target().

void Isis::Camera::SetGroundMap ( CameraGroundMap * map )

inherited

Sets the Ground Map.

This object will take ownership of the ground map pointer.

Parameters

*map	Pointer to a CameraGroundMap object

Definition at line 2153 of file Camera.cpp.

References Isis::Camera::p_groundMap.

bool Isis::Camera::SetImage	(	const double	sample,
		const double	line
	)

inherited

Sets the sample/line values of the image to get the lat/lon values.

Parameters

sample	Sample coordinate of the cube
line	Line coordinate of the cube

Returns: bool Returns true if the image was set successfully and false if it was not

Definition at line 163 of file Camera.cpp.

References Isis::AlphaCube::AlphaLine(), Isis::AlphaCube::AlphaSample(), Isis::ShapeModel::clearSurfacePoint(), Isis::Angle::Degrees, Isis::CameraDetectorMap::DetectorLine(), Isis::CameraDetectorMap::DetectorSample(), Isis::CameraFocalPlaneMap::FocalPlaneX(), Isis::CameraFocalPlaneMap::FocalPlaneY(), Isis::Sensor::HasSurfaceIntersection(), Isis::Projection::IsSky(), Isis::Angle::isValid(), Isis::Sensor::LocalRadius(), Isis::TProjection::Longitude(), Isis::Distance::Meters, Isis::ShapeModel::name(), Isis::Camera::p_alphaCube, Isis::Camera::p_childLine, Isis::Camera::p_childSample, Isis::Camera::p_detectorMap, Isis::Camera::p_distortionMap, Isis::Camera::p_focalPlaneMap, Isis::Camera::p_groundMap, Isis::Camera::p_ignoreProjection, Isis::Camera::p_pointComputed, Isis::Camera::p_projection, Isis::CameraFocalPlaneMap::SetDetector(), Isis::CameraDistortionMap::SetFocalPlane(), Isis::CameraGroundMap::SetFocalPlane(), Isis::Camera::SetGround(), Isis::ShapeModel::setHasIntersection(), Isis::CameraDetectorMap::SetParent(), Isis::Camera::SetRightAscensionDeclination(), Isis::Projection::SetWorld(), Isis::Target::shape(), Isis::Spice::target(), Isis::CameraDistortionMap::UndistortedFocalPlaneX(), Isis::CameraDistortionMap::UndistortedFocalPlaneY(), Isis::CameraDistortionMap::UndistortedFocalPlaneZ(), Isis::TProjection::UniversalLatitude(), Isis::TProjection::UniversalLongitude(), Isis::RingPlaneProjection::UniversalRingLongitude(), and Isis::RingPlaneProjection::UniversalRingRadius().

Referenced by Isis::QnetTool::addMeasure(), Isis::BundleAdjust::AddPartials(), Isis::CameraStatistics::addStats(), Isis::BundleAdjust::ApproximatePoint_ClosestApproach(), Isis::StereoTool::calculateElevation(), Isis::ControlPoint::ComputeApriori(), Isis::Camera::ComputeAzimuth(), Isis::BundleAdjust::ComputePartials_DC(), Isis::ControlPoint::ComputeResiduals(), Isis::ControlPoint::ComputeResiduals_Millimeters(), Isis::ProjectionFactory::CreateForCube(), Isis::QnetPointDistanceFilter::filter(), Isis::QnetCubeDistanceFilter::filter(), Isis::InterestOperator::FindCnetRef(), Isis::QnetTool::findPointLocation(), Isis::SmtkMatcher::getLatLon(), Isis::Camera::GetLocalNormal(), Isis::Camera::GroundRangeResolution(), Isis::VimsSkyMap::Init(), Isis::VimsGroundMap::Init(), Isis::InterestOperator::InterestByMeasure(), Isis::Chip::Load(), Isis::Camera::LoadCache(), Isis::ControlNetValidMeasure::MetersFromEdge(), Isis::SunShadowTool::mouseButtonPress(), Isis::ControlNetFilter::PointDistanceFilter(), Isis::ControlNetFilter::PointLatLonFilter(), Isis::CubeCalculator::prepareCalculations(), Isis::Camera::RaDecRange(), Isis::Camera::RaDecResolution(), Isis::SunShadowTool::recalculateShadowHeight(), Isis::Camera::ringRangeResolution(), Isis::ProjectionFactory::RingsCreateForCube(), Isis::QnetSetAprioriDialog::setApriori(), Isis::VimsGroundMap::SetGround(), Isis::UniversalGroundMap::SetImage(), Isis::VimsSkyMap::SetSky(), Isis::Camera::StartEndEphemerisTimes(), Isis::MeasureTool::updateDist(), Isis::TrackTool::updateLabels(), Isis::AdvancedTrackTool::updateRow(), and Isis::VimsCamera::VimsCamera().

bool Isis::Sensor::SetLookDirection ( const double v[3] )

inherited

Sets the look direction of the spacecraft.

This routine will then attempt to intersect the look direction with the target. If successful you can utilize the methods which return the lat/lon, phase, incidence, etc. This routine returns false if the look direction does not intersect the target.

Parameters

v[]	A look vector in camera coordinates. For example, (0,0,1) is usually the look direction out of the boresight of a camera.

Returns: bool Indicates whether the given look direction intersects the target.

History:: 2009-09-23 Tracie Sucharski - Convert negative longitudes returned my reclat.

History:: 2010-09-15 Janet Barrett - Modified this method to use a new algorithm for finding the intersection of a ray with the DEM. This was required to take care of problems that were encountered at the poles of global DEM files. The algorithm that is being used was taken from "Intersection between spacecraft viewing vectors and digital elevation models" by N.A. Teanby. This algorithm only works on Equatorial Cylindrical projections. Other projections still use the previous algorithm.

History:: 2010-10-26 Janet Barrett - The tolerance value of 1E-5 was too small and was causing a divide by zero error when the current and last intersections were virtually the same. The tolerance was changed to 3E-8 * a (where a is the equatorial radius of the planet we are dealing with).

History:: 2011-01-24 Janet Barrett - Got rid of extra loop that wasn't needed for the new ray tracing algorithm.

History:: 2011-08-16 Jeff Anderson - Fixed a problem with an infinite loop in the ray tracing algorithm. The problem was first exposed when trying to intersect the Vesta DEM on the limb.

Definition at line 156 of file Sensor.cpp.

References Isis::Spice::bodyRotation(), Isis::Sensor::Coordinate(), Isis::Spice::instrumentPosition(), Isis::Spice::instrumentRotation(), Isis::SpiceRotation::J2000Vector(), Isis::Sensor::m_lookB, Isis::Sensor::m_newLookB, Isis::SpiceRotation::ReferenceVector(), Isis::ShapeModel::setHasIntersection(), Isis::Target::shape(), and Isis::Spice::target().

Referenced by Isis::CameraSkyMap::SetFocalPlane(), Isis::VimsSkyMap::SetFocalPlane(), Isis::VimsGroundMap::SetFocalPlane(), and Isis::Sensor::SetRightAscensionDeclination().

void Isis::Camera::SetPixelPitch ( double v )

protectedinherited

Sets the pixel pitch.

Parameters

v	Pixel Pitch

Definition at line 2740 of file Camera.cpp.

References Isis::Camera::p_pixelPitch.

void Isis::Camera::SetPixelPitch ( )

protectedinherited

Reads the Pixel Pitch from the instrument kernel.

Definition at line 1183 of file Camera.cpp.

References Isis::Spice::getDouble(), Isis::Spice::naifIkCode(), and Isis::toString().

Referenced by Isis::AmicaCamera::AmicaCamera(), Isis::ApolloMetricCamera::ApolloMetricCamera(), Isis::ApolloPanoramicCamera::ApolloPanoramicCamera(), Isis::Chandrayaan1M3Camera::Chandrayaan1M3Camera(), Isis::CrismCamera::CrismCamera(), Isis::CTXCamera::CTXCamera(), Isis::DawnFcCamera::DawnFcCamera(), Isis::HiresCamera::HiresCamera(), Isis::HiriseCamera::HiriseCamera(), Isis::HrscCamera::HrscCamera(), Isis::IdealCamera::IdealCamera(), Isis::IssNACamera::IssNACamera(), Isis::IssWACamera::IssWACamera(), Isis::KaguyaMiCamera::KaguyaMiCamera(), Isis::LoHighCamera::LoHighCamera(), Isis::LoMediumCamera::LoMediumCamera(), Isis::LroNarrowAngleCamera::LroNarrowAngleCamera(), Isis::LroWideAngleCamera::LroWideAngleCamera(), Isis::LwirCamera::LwirCamera(), Isis::MarciCamera::MarciCamera(), Isis::Mariner10Camera::Mariner10Camera(), MdisCamera(), Isis::MiniRF::MiniRF(), Isis::MocNarrowAngleCamera::MocNarrowAngleCamera(), Isis::MocWideAngleCamera::MocWideAngleCamera(), Isis::MsiCamera::MsiCamera(), Isis::NewHorizonsLeisaCamera::NewHorizonsLeisaCamera(), Isis::NewHorizonsLorriCamera::NewHorizonsLorriCamera(), Isis::NewHorizonsMvicFrameCamera::NewHorizonsMvicFrameCamera(), Isis::NewHorizonsMvicTdiCamera::NewHorizonsMvicTdiCamera(), Isis::NirCamera::NirCamera(), Isis::SsiCamera::SsiCamera(), Isis::ThemisIrCamera::ThemisIrCamera(), Isis::ThemisVisCamera::ThemisVisCamera(), Isis::UvvisCamera::UvvisCamera(), Isis::VikingCamera::VikingCamera(), Isis::VimsCamera::VimsCamera(), and Isis::VoyagerCamera::VoyagerCamera().

bool Isis::Camera::SetRightAscensionDeclination	(	const double	ra,
		const double	dec
	)

inherited

Sets the right ascension declination.

Parameters

ra	Right ascension value
dec	Declination value

Returns: bool Returns true if the declination was set successfully and false if it was not

Reimplemented from Isis::Sensor.

Definition at line 1198 of file Camera.cpp.

References Isis::AlphaCube::BetaLine(), Isis::AlphaCube::BetaSample(), Isis::CameraFocalPlaneMap::DetectorLine(), Isis::CameraFocalPlaneMap::DetectorSample(), Isis::CameraSkyMap::FocalPlaneX(), Isis::CameraDistortionMap::FocalPlaneX(), Isis::CameraSkyMap::FocalPlaneY(), Isis::CameraDistortionMap::FocalPlaneY(), Isis::Projection::IsSky(), Isis::Camera::p_alphaCube, Isis::Camera::p_childLine, Isis::Camera::p_childSample, Isis::Camera::p_detectorMap, Isis::Camera::p_distortionMap, Isis::Camera::p_focalPlaneMap, Isis::Camera::p_ignoreProjection, Isis::Camera::p_pointComputed, Isis::Camera::p_projection, Isis::Camera::p_skyMap, Isis::CameraDetectorMap::ParentLine(), Isis::CameraDetectorMap::ParentSample(), Isis::CameraDetectorMap::SetDetector(), Isis::CameraFocalPlaneMap::SetFocalPlane(), Isis::CameraSkyMap::SetSky(), Isis::CameraDistortionMap::SetUndistortedFocalPlane(), Isis::Projection::SetUniversalGround(), Isis::Spice::target(), Isis::Sensor::UniversalLatitude(), Isis::Sensor::UniversalLongitude(), Isis::Projection::WorldX(), and Isis::Projection::WorldY().

Referenced by Isis::Camera::RaDecRange(), and Isis::Camera::SetImage().

void Isis::Camera::SetSkyMap ( CameraSkyMap * map )

inherited

Sets the Sky Map.

This object will take ownership of the sky map pointer.

Parameters

*map	Pointer to a CameraSkyMap object

Definition at line 2166 of file Camera.cpp.

References Isis::Camera::p_skyMap.

Referenced by Isis::CameraSkyMap::CameraSkyMap().

void Isis::Sensor::setTime ( const iTime & time )

inherited

By setting the time you essential set the position of the spacecraft and body as indicated in the class Spice.

However, after this is invoked there will be no intersection point until SetLookDirection or SetUniversalGround is invoked. (Read NAIF documentation for a detailed description of ephemeris time.)

Parameters

time	Ephemeris time.

Reimplemented from Isis::Spice.

Definition at line 112 of file Sensor.cpp.

References Isis::ShapeModel::clearSurfacePoint(), Isis::Target::shape(), and Isis::Spice::target().

Referenced by Isis::AmicaCamera::AmicaCamera(), Isis::ApolloMetricCamera::ApolloMetricCamera(), Isis::ApolloPanoramicCamera::ApolloPanoramicCamera(), Isis::CrismCamera::CrismCamera(), Isis::DawnFcCamera::DawnFcCamera(), Isis::HiresCamera::HiresCamera(), Isis::IdealCamera::IdealCamera(), Isis::VimsSkyMap::Init(), Isis::VimsGroundMap::Init(), Isis::IssNACamera::IssNACamera(), Isis::IssWACamera::IssWACamera(), Isis::KaguyaMiCamera::KaguyaMiCamera(), Isis::Camera::LoadCache(), Isis::LoHighCamera::LoHighCamera(), Isis::LoMediumCamera::LoMediumCamera(), Isis::LroNarrowAngleCamera::LroNarrowAngleCamera(), Isis::LwirCamera::LwirCamera(), Isis::Mariner10Camera::Mariner10Camera(), MdisCamera(), Isis::MiniRF::MiniRF(), Isis::MsiCamera::MsiCamera(), Isis::NewHorizonsLorriCamera::NewHorizonsLorriCamera(), Isis::NirCamera::NirCamera(), Isis::NewHorizonsMvicFrameCamera::SetBand(), Isis::ThemisVisCamera::SetBand(), Isis::VimsSkyMap::SetFocalPlane(), Isis::VimsGroundMap::SetFocalPlane(), Isis::PushFrameCameraDetectorMap::SetFramelet(), Isis::VariableLineScanCameraDetectorMap::SetParent(), Isis::RadarPulseMap::SetParent(), Isis::LineScanCameraDetectorMap::SetParent(), Isis::SsiCamera::SsiCamera(), Isis::UvvisCamera::UvvisCamera(), Isis::VikingCamera::VikingCamera(), and Isis::VoyagerCamera::VoyagerCamera().

bool Isis::Sensor::SetUniversalGround	(	const double	latitude,
		const double	longitude,
		bool	backCheck = `true`
	)

inherited

This is the opposite routine for SetLookDirection.

Instead of computing a point on the target, a point is set and the look direction is computed. Other methods such as lat/lon, phase, incidence, etc. can be used if this method returns a true.

Parameters

latitude	Planetocentric latitude.
longitude	Positive east longitude.
backCheck	If true this method will check the lat/lon point to see if it falls on the backside of the target (or beyond the horizon). If false this test will not occur. Defaults to true.

Returns: bool True if the look direction intersects the target.

Definition at line 370 of file Sensor.cpp.

References Isis::ShapeModel::clearSurfacePoint(), Isis::Angle::Degrees, Isis::Sensor::LocalRadius(), Isis::Sensor::SetGroundLocal(), Isis::SurfacePoint::SetSpherical(), Isis::Target::shape(), Isis::ShapeModel::surfaceIntersection(), and Isis::Spice::target().

bool Isis::Sensor::SetUniversalGround	(	const double	latitude,
		const double	longitude,
		const double	radius,
		bool	backCheck = `true`
	)

inherited

This overloaded method has the opposite function as SetLookDirection.

Instead of computing a point on the target, a point is set and the look direction is computed. Other methods such as lat/lon, phase, incidence, etc. can be used if this method returns a true.

Parameters

latitude	Planetocentric latitude in degrees.
longitude	Positive east longitude in degrees.
radius	Radius in meters.
backCheck	If true this method will check the lat/lon point to see if it falls on the backside of the target (or beyond the horizon). If false this test will not occur. Defaults to true.

Returns: bool True if the look direction intersects the target.

Definition at line 405 of file Sensor.cpp.

References Isis::ShapeModel::clearSurfacePoint(), Isis::Angle::Degrees, Isis::Distance::Meters, Isis::Sensor::SetGroundLocal(), Isis::SurfacePoint::SetSpherical(), Isis::Target::shape(), Isis::ShapeModel::surfaceIntersection(), and Isis::Spice::target().

bool Isis::Camera::SetUniversalGround	(	const double	latitude,
		const double	longitude
	)

inherited

Sets the lat/lon values to get the sample/line values.

Parameters

latitude	Latitude coordinate of the point
longitude	Longitude coordinate of the point

Returns: bool Returns true if the Universal Ground was set successfully and false if it was not

Definition at line 285 of file Camera.cpp.

References Isis::ShapeModel::clearSurfacePoint(), Isis::Angle::Degrees, Isis::Camera::p_groundMap, Isis::Camera::RawFocalPlanetoImage(), Isis::CameraGroundMap::SetGround(), Isis::Target::shape(), and Isis::Spice::target().

Referenced by Isis::QnetTool::addMeasure(), Isis::Camera::ComputeAzimuth(), Isis::QnetTool::createFixedPoint(), Isis::ProjectionFactory::CreateForCube(), Isis::QnetTool::createPoint(), Isis::InterestOperator::FindCnetRef(), Isis::SmtkMatcher::getLineSample(), Isis::Chip::Load(), and Isis::UniversalGroundMap::SetUniversalGround().

bool Isis::Camera::SetUniversalGround	(	const double	latitude,
		const double	longitude,
		const double	radius
	)

inherited

Sets the lat/lon/radius values to get the sample/line values.

Parameters

latitude	Latitude coordinate of the cube
longitude	Longitude coordinate of the cube
radius	Radius coordinate of the cube

Returns: bool Returns true if the Universal Ground was set successfully and false if it was not

Definition at line 447 of file Camera.cpp.

References Isis::ShapeModel::clearSurfacePoint(), Isis::Angle::Degrees, Isis::Distance::Meters, Isis::Camera::p_groundMap, Isis::Camera::RawFocalPlanetoImage(), Isis::CameraGroundMap::SetGround(), Isis::Target::shape(), and Isis::Spice::target().

pair< iTime, iTime > Isis::MdisCamera::ShutterOpenCloseTimes	(	double	time,
		double	exposureDuration
	)

virtual

Returns the shutter open and close times.

The user should pass in the ExposureDuration keyword value, converted from milliseconds to seconds, and the SpacecraftClockCount keyword value, converted to ephemeris time. The StartTime keyword value from the labels represents the shutter open time of the observation. This method uses the FramingCamera class implementation, returning the given time value as the shutter open and the sum of the time value and exposure duration as the shutter close.

Parameters

exposureDuration	Exposure duration value from the labels, converted to seconds.
time	The SpacecraftClockCount value from the labels, converted to ephemeris time

Returns: pair < iTime, iTime > The first value is the shutter open time and the second is the shutter close time.

See Also

Author: 2011-05-03 Jeannie Walldren

History:: 2011-05-03 Jeannie Walldren - Original version.

Implements Isis::FramingCamera.

Definition at line 271 of file MdisCamera.cpp.

CameraSkyMap * Isis::Camera::SkyMap ( )

inherited

Returns a pointer to the CameraSkyMap object.

Returns: CameraSkyMap*

Reimplemented in Isis::LineScanCamera.

Definition at line 2593 of file Camera.cpp.

References Isis::Camera::p_skyMap.

Referenced by Isis::VimsCamera::VimsCamera().

double Isis::Sensor::SlantDistance ( ) const

inherited

Return the distance between the spacecraft and surface point in kmv.

Returns: double Slant distance.

Definition at line 603 of file Sensor.cpp.

References Isis::Spice::bodyRotation(), Isis::Sensor::Coordinate(), Isis::Spice::instrumentPosition(), Isis::Displacement::kilometers(), Isis::SpiceRotation::ReferenceVector(), Isis::Target::shape(), Isis::ShapeModel::surfaceIntersection(), and Isis::Spice::target().

Referenced by Isis::PushFrameCameraGroundMap::FindSpacecraftDistance(), and Isis::AdvancedTrackTool::updateRow().

double Isis::Sensor::SolarDistance ( ) const

inherited

Returns the distance between the sun and surface point in AU.

Returns: double Solar distance.

Definition at line 643 of file Sensor.cpp.

References Isis::Displacement::kilometers(), Isis::Target::shape(), Isis::Spice::sunPosition(), Isis::ShapeModel::surfaceIntersection(), and Isis::Spice::target().

Longitude Isis::Spice::solarLongitude ( )

inherited

Returns the solar longitude.

Returns: double The Solar Longitude

Definition at line 1317 of file Spice.cpp.

Referenced by Isis::AdvancedTrackTool::updateRow().

double Isis::Sensor::SpacecraftAltitude ( )

inherited

Returns the distance from the spacecraft to the subspacecraft point in km.

It uses the ellipsoid, not the shape model.

Returns: double Spacecraft altitude.

Definition at line 667 of file Sensor.cpp.

References Isis::Spice::instrumentPosition(), Isis::Distance::kilometers(), Isis::Sensor::LocalRadius(), Isis::PI(), and Isis::Spice::subSpacecraftPoint().

Referenced by Isis::CrismCamera::CrismCamera(), Isis::Camera::LoadCache(), Isis::MiniRF::MiniRF(), and Isis::VimsCamera::VimsCamera().

double Isis::Camera::SpacecraftAzimuth ( )

inherited

Return the Spacecraft Azimuth.

Returns: double Spacecraft Azimuth

Todo:: Get appropriate radius at the subscraft point

Definition at line 1711 of file Camera.cpp.

References Isis::Camera::ComputeAzimuth(), Isis::Sensor::LocalRadius(), and Isis::Spice::subSpacecraftPoint().

Referenced by Isis::AdvancedTrackTool::updateRow().

QString Isis::Camera::spacecraftNameLong ( ) const

virtualinherited

This method returns the full spacecraft name.

Returns: QString

Implements Isis::Sensor.

Reimplemented in Isis::IdealCamera.

Definition at line 2623 of file Camera.cpp.

References Isis::Camera::m_spacecraftNameLong.

QString Isis::Camera::spacecraftNameShort ( ) const

virtualinherited

This method returns the shortened spacecraft name.

Returns: QString

Implements Isis::Sensor.

Reimplemented in Isis::IdealCamera.

Definition at line 2633 of file Camera.cpp.

References Isis::Camera::m_spacecraftNameShort.

void Isis::Sensor::SpacecraftSurfaceVector ( double scSurfaceVector[3] ) const

inherited

Sets the vector between the spacecraft and surface point in body-fixed.

Parameters

scSurfaceVector The direction vector from the observer to the surface intersection.

Author: 2011-12-20 Tracie Sucharski

Definition at line 591 of file Sensor.cpp.

References Isis::Sensor::m_lookB.

int Isis::Camera::SpkCenterId ( ) const

virtualinherited

Provides the center of motion body for SPK NAIF kernel.

This virtual method may need to be implemented in each camera model providing the NAIF integer code for the center of motion of the object identified by the SpkTargetId() code. This is typically the targeted body for a particular image observation, but may be unique depending upon the design of the SPK mission kernels.

This value can be easily determined by using the NAIF spacit application that sumarizes binary kernels on the SPK kernel used for a particular instrument on a spacecraft. spacit will additionally require a leap seconds kernel (LSK). For example, the output of the MESSENGER SPK camera supporting the MDIS camera below indicates it is Venus.

Segment ID     : msgr_20050903_20061125_recon002.nio
Target Body    : Body -236, MESSENGER
Center Body    : Body 2, VENUS BARYCENTER
Reference frame: Frame 1, J2000
SPK Data Type  : Type 1
Description : Modified Difference Array
UTC Start Time : 2006 OCT 16 19:25:41.111
UTC Stop Time  : 2006 OCT 31 22:14:24.040
ET Start Time  : 2006 OCT 16 19:26:46.293
ET Stop time   : 2006 OCT 31 22:15:29.222

The SpkCenterId value is found in the "Center Body" entry (2). The center of motion is most likely the targeted body for the image and this is provided by the naifBodyCode() method (in the Spice class). If this is not consistently the case for a particular mission, then camera models will need to reimplement this method.

Returns: int NAIF code for SPK center of motion body for an instrument

Reimplemented in Isis::VimsCamera, Isis::IssWACamera, Isis::IssNACamera, and Isis::IdealCamera.

Definition at line 2722 of file Camera.cpp.

References Isis::Spice::naifBodyCode().

virtual int Isis::MdisCamera::SpkReferenceId ( ) const

inlinevirtual

SPK Reference ID - J2000.

Returns: int The appropriate instrument code for the Spacecraft Kernel Reference ID

Implements Isis::Camera.

Definition at line 144 of file MdisCamera.h.

virtual int Isis::MdisCamera::SpkTargetId ( ) const

inlinevirtual

SPK Target Body ID - MESSENGER spacecraft -236.

Returns: int The appropriate instrument code for the Spacecraft Kernel Target ID

Reimplemented from Isis::Camera.

Definition at line 137 of file MdisCamera.h.

pair< double, double > Isis::Camera::StartEndEphemerisTimes ( )

inherited

Calculates the start and end ephemeris times.

These times are found by looping through the bands and finding the ephemeris times for the upper left and bottom right pixels in the image. The start time (shutter open time) is the minimum value of those ephemeris times. The end time (shutter close time) is the maximum value of those ephemeris times. This method must be called before a call to the Spice::createCache() method. It is called in the LoadCache() method.

Exceptions

iException::Programmer - "Unable to find time range for the spice kernels."

See Also: createCache(); LoadCache()

Author: 2011-02-02 Jeannie Walldren

History:: 2011-02-02 Jeannie Walldren - Original version.

Definition at line 2241 of file Camera.cpp.

References _FILEINFO_, Isis::Camera::Bands(), Isis::AlphaCube::BetaLines(), Isis::AlphaCube::BetaSamples(), Isis::iTime::Et(), Isis::Camera::p_alphaCube, Isis::IException::Programmer, Isis::Camera::SetBand(), Isis::Camera::SetImage(), and Isis::Spice::time().

Referenced by Isis::Camera::LoadCache().

void Isis::Spice::subSolarPoint	(	double &	lat,
		double &	lon
	)

inherited

Returns the sub-solar latitude/longitude in universal coordinates (0-360 positive east, ocentric)

Parameters

lat	Sub-solar latitude
lon	Sub-solar longitude

See Also: setTime()

Exceptions

Isis::IException::Programmer - "You must call SetTime first."

Definition at line 1193 of file Spice.cpp.

References _FILEINFO_, and Isis::PI().

Referenced by Isis::Sensor::LocalSolarTime(), and Isis::Camera::SunAzimuth().

void Isis::Spice::subSpacecraftPoint	(	double &	lat,
		double &	lon
	)

inherited

Returns the sub-spacecraft latitude/longitude in universal coordinates (0-360 positive east, ocentric)

Parameters

lat	Sub-spacecraft latitude
lon	Sub-spacecraft longitude

See Also: setTime()

Exceptions

Isis::IException::Programmer - "You must call SetTime first."

Definition at line 1145 of file Spice.cpp.

References _FILEINFO_, and Isis::PI().

Referenced by Isis::Camera::GroundRangeResolution(), Isis::Sensor::SpacecraftAltitude(), and Isis::Camera::SpacecraftAzimuth().

double Isis::Camera::SunAzimuth ( )

inherited

Returns the Sun Azimuth.

Returns: double Sun Azimuth

Todo:: Get appropriate radius at the subsolar point

Definition at line 1698 of file Camera.cpp.

References Isis::Camera::ComputeAzimuth(), Isis::Sensor::LocalRadius(), and Isis::Spice::subSolarPoint().

Referenced by Isis::SunShadowTool::mouseButtonPress(), and Isis::AdvancedTrackTool::updateRow().

void Isis::Spice::sunPosition ( double p[3] ) const

inherited

Fills the input vector with sun position information, in either body-fixed or J2000 reference frame and km units.

Parameters

p[]	Sun position

See Also: setTime()

Definition at line 779 of file Spice.cpp.

References _FILEINFO_.

Referenced by Isis::SunShadowTool::recalculateShadowHeight().

SpicePosition * Isis::Spice::sunPosition ( ) const

inherited

Accessor method for the sun position.

Returns: iTime Sun position for the image.

Author: Steven Lambright

History:: 2011-02-09 Steven Lambright - Original version.

Definition at line 1384 of file Spice.cpp.

Referenced by Isis::Sensor::SolarDistance().

Target * Isis::Spice::target ( ) const

inherited

Returns a pointer to the target object.

Returns: string

Definition at line 1231 of file Spice.cpp.

Referenced by Isis::Camera::BasicMapping(), Isis::Camera::basicRingMapping(), Isis::Sensor::Coordinate(), Isis::Sensor::EmissionAngle(), Isis::FeatureNomenclatureTool::findMissingNomenclature(), Isis::Sensor::GetLatitude(), Isis::Camera::GetLocalNormal(), Isis::Sensor::GetLongitude(), Isis::Sensor::GetSurfacePoint(), Isis::UniversalGroundMap::GroundRange(), Isis::Camera::GroundRangeResolution(), Isis::Sensor::HasSurfaceIntersection(), Isis::Sensor::IgnoreElevationModel(), Isis::Sensor::IncidenceAngle(), Isis::Camera::LoadCache(), Isis::Sensor::LocalRadius(), Isis::Camera::NorthAzimuth(), Isis::Sensor::PhaseAngle(), Isis::Camera::RawFocalPlanetoImage(), Isis::VimsGroundMap::SetGround(), Isis::RadarGroundMap::SetGround(), Isis::Sensor::SetGround(), Isis::Camera::SetGround(), Isis::Sensor::SetGroundLocal(), Isis::Camera::SetImage(), Isis::Sensor::SetLookDirection(), Isis::Camera::SetRightAscensionDeclination(), Isis::Sensor::setTime(), Isis::Sensor::SetUniversalGround(), Isis::Camera::SetUniversalGround(), Isis::Sensor::SlantDistance(), Isis::Sensor::SolarDistance(), Isis::TrackTool::updateLabels(), and Isis::AdvancedTrackTool::updateRow().

double Isis::Spice::targetCenterDistance ( ) const

inherited

Calculates and returns the distance from the spacecraft to the target center.

Returns: double Distance to the center of the target from the spacecraft

Definition at line 794 of file Spice.cpp.

QString Isis::Spice::targetName ( ) const

inherited

Returns the string name of the target.

Returns: string

Definition at line 1241 of file Spice.cpp.

References Isis::Target::name().

iTime Isis::Spice::time ( ) const

inherited

Returns the ephemeris time in seconds which was used to obtain the spacecraft and sun positions.

Returns: double

Definition at line 767 of file Spice.cpp.

Referenced by Isis::RadarSlantRangeMap::ComputeA(), Isis::HiresCamera::HiresCamera(), Isis::LoHighCamera::LoHighCamera(), Isis::LoMediumCamera::LoMediumCamera(), Isis::LwirCamera::LwirCamera(), Isis::NewHorizonsMvicFrameCamera::SetBand(), Isis::VariableLineScanCameraDetectorMap::SetDetector(), Isis::RadarPulseMap::SetDetector(), Isis::LineScanCameraDetectorMap::SetDetector(), Isis::RadarSlantRangeMap::SetFocalPlane(), Isis::RadarSlantRangeMap::SetUndistortedFocalPlane(), Isis::FramingCamera::ShutterOpenCloseTimes(), Isis::Camera::StartEndEphemerisTimes(), Isis::AdvancedTrackTool::updateRow(), and Isis::UvvisCamera::UvvisCamera().

double Isis::Sensor::UniversalLatitude ( ) const

inherited

Returns the planetocentric latitude, in degrees, at the surface intersection point in the body fixed coordinate system.

Returns: double Universal latitude, in degrees.

Definition at line 224 of file Sensor.cpp.

References Isis::Angle::degrees(), and Isis::Sensor::GetLatitude().

Referenced by Isis::QnetTool::addMeasure(), Isis::CameraStatistics::addStats(), Isis::ProjectionFactory::CreateForCube(), Isis::QnetCubeDistanceFilter::filter(), Isis::InterestOperator::FindCnetRef(), Isis::QnetTool::findPointLocation(), Isis::SmtkMatcher::getLatLon(), Isis::Camera::GroundRangeResolution(), Isis::Chip::Load(), Isis::Camera::NorthAzimuth(), Isis::ControlNetFilter::PointDistanceFilter(), Isis::ControlNetFilter::PointLatLonFilter(), Isis::Camera::RawFocalPlanetoImage(), Isis::Camera::SetRightAscensionDeclination(), Isis::UniversalGroundMap::UniversalLatitude(), Isis::TrackTool::updateLabels(), and Isis::AdvancedTrackTool::updateRow().

double Isis::Sensor::UniversalLongitude ( ) const

inherited

Returns the positive east, 0-360 domain longitude, in degrees, at the surface intersection point in the body fixed coordinate system.

Returns: double Universal longitude, in degrees.

Definition at line 247 of file Sensor.cpp.

References Isis::Angle::degrees(), and Isis::Sensor::GetLongitude().

Referenced by Isis::QnetTool::addMeasure(), Isis::CameraStatistics::addStats(), Isis::ProjectionFactory::CreateForCube(), Isis::QnetCubeDistanceFilter::filter(), Isis::InterestOperator::FindCnetRef(), Isis::QnetTool::findPointLocation(), Isis::SmtkMatcher::getLatLon(), Isis::Camera::GroundRangeResolution(), Isis::Chip::Load(), Isis::Sensor::LocalSolarTime(), Isis::ControlNetFilter::PointDistanceFilter(), Isis::ControlNetFilter::PointLatLonFilter(), Isis::Camera::RawFocalPlanetoImage(), Isis::Camera::ringRangeResolution(), Isis::ProjectionFactory::RingsCreateForCube(), Isis::Camera::SetRightAscensionDeclination(), Isis::UniversalGroundMap::UniversalLongitude(), Isis::TrackTool::updateLabels(), and Isis::AdvancedTrackTool::updateRow().

Member Data Documentation

SpiceDouble Isis::Spice::m_BJ[3][3]

protectedinherited

This contains the transformation matrix from J2000 (J) to Body fixed (B).

Recall that the transpose of this matrix JB will convert from body-fixed to J2000. It is left in protected space so that conversions between double and SpiceDouble do not have to occur in inheriting classes.

Definition at line 358 of file Spice.h.

QString Isis::Camera::m_instrumentNameLong

protectedinherited

Full instrument name.

Definition at line 441 of file Camera.h.

Referenced by Isis::AmicaCamera::AmicaCamera(), Isis::ApolloMetricCamera::ApolloMetricCamera(), Isis::ApolloPanoramicCamera::ApolloPanoramicCamera(), Isis::Camera::Camera(), Isis::Chandrayaan1M3Camera::Chandrayaan1M3Camera(), Isis::CrismCamera::CrismCamera(), Isis::CTXCamera::CTXCamera(), Isis::DawnFcCamera::DawnFcCamera(), Isis::HiresCamera::HiresCamera(), Isis::HiriseCamera::HiriseCamera(), Isis::HrscCamera::HrscCamera(), Isis::Camera::instrumentNameLong(), Isis::IssNACamera::IssNACamera(), Isis::IssWACamera::IssWACamera(), Isis::KaguyaMiCamera::KaguyaMiCamera(), Isis::LoHighCamera::LoHighCamera(), Isis::LoMediumCamera::LoMediumCamera(), Isis::LroNarrowAngleCamera::LroNarrowAngleCamera(), Isis::LroWideAngleCamera::LroWideAngleCamera(), Isis::LwirCamera::LwirCamera(), Isis::MarciCamera::MarciCamera(), Isis::Mariner10Camera::Mariner10Camera(), MdisCamera(), Isis::MiniRF::MiniRF(), Isis::MocNarrowAngleCamera::MocNarrowAngleCamera(), Isis::MocWideAngleCamera::MocWideAngleCamera(), Isis::MsiCamera::MsiCamera(), Isis::NewHorizonsLeisaCamera::NewHorizonsLeisaCamera(), Isis::NewHorizonsLorriCamera::NewHorizonsLorriCamera(), Isis::NewHorizonsMvicFrameCamera::NewHorizonsMvicFrameCamera(), Isis::NewHorizonsMvicTdiCamera::NewHorizonsMvicTdiCamera(), Isis::NirCamera::NirCamera(), Isis::SsiCamera::SsiCamera(), Isis::ThemisIrCamera::ThemisIrCamera(), Isis::ThemisVisCamera::ThemisVisCamera(), Isis::UvvisCamera::UvvisCamera(), Isis::VikingCamera::VikingCamera(), Isis::VimsCamera::VimsCamera(), and Isis::VoyagerCamera::VoyagerCamera().

QString Isis::Camera::m_instrumentNameShort

protectedinherited

Shortened instrument name.

Definition at line 442 of file Camera.h.

Referenced by Isis::AmicaCamera::AmicaCamera(), Isis::ApolloMetricCamera::ApolloMetricCamera(), Isis::ApolloPanoramicCamera::ApolloPanoramicCamera(), Isis::Camera::Camera(), Isis::Chandrayaan1M3Camera::Chandrayaan1M3Camera(), Isis::CrismCamera::CrismCamera(), Isis::CTXCamera::CTXCamera(), Isis::DawnFcCamera::DawnFcCamera(), Isis::HiresCamera::HiresCamera(), Isis::HiriseCamera::HiriseCamera(), Isis::HrscCamera::HrscCamera(), Isis::Camera::instrumentNameShort(), Isis::IssNACamera::IssNACamera(), Isis::IssWACamera::IssWACamera(), Isis::KaguyaMiCamera::KaguyaMiCamera(), Isis::LoHighCamera::LoHighCamera(), Isis::LoMediumCamera::LoMediumCamera(), Isis::LroNarrowAngleCamera::LroNarrowAngleCamera(), Isis::LroWideAngleCamera::LroWideAngleCamera(), Isis::LwirCamera::LwirCamera(), Isis::MarciCamera::MarciCamera(), Isis::Mariner10Camera::Mariner10Camera(), MdisCamera(), Isis::MiniRF::MiniRF(), Isis::MocNarrowAngleCamera::MocNarrowAngleCamera(), Isis::MocWideAngleCamera::MocWideAngleCamera(), Isis::MsiCamera::MsiCamera(), Isis::NewHorizonsLeisaCamera::NewHorizonsLeisaCamera(), Isis::NewHorizonsLorriCamera::NewHorizonsLorriCamera(), Isis::NewHorizonsMvicFrameCamera::NewHorizonsMvicFrameCamera(), Isis::NewHorizonsMvicTdiCamera::NewHorizonsMvicTdiCamera(), Isis::NirCamera::NirCamera(), Isis::SsiCamera::SsiCamera(), Isis::ThemisIrCamera::ThemisIrCamera(), Isis::ThemisVisCamera::ThemisVisCamera(), Isis::UvvisCamera::UvvisCamera(), Isis::VikingCamera::VikingCamera(), Isis::VimsCamera::VimsCamera(), and Isis::VoyagerCamera::VoyagerCamera().

QString Isis::Camera::m_spacecraftNameLong

protectedinherited

Full spacecraft name.

Definition at line 443 of file Camera.h.

Referenced by Isis::AmicaCamera::AmicaCamera(), Isis::ApolloMetricCamera::ApolloMetricCamera(), Isis::ApolloPanoramicCamera::ApolloPanoramicCamera(), Isis::Camera::Camera(), Isis::Chandrayaan1M3Camera::Chandrayaan1M3Camera(), Isis::CrismCamera::CrismCamera(), Isis::CTXCamera::CTXCamera(), Isis::DawnFcCamera::DawnFcCamera(), Isis::HiresCamera::HiresCamera(), Isis::HiriseCamera::HiriseCamera(), Isis::HrscCamera::HrscCamera(), Isis::IssNACamera::IssNACamera(), Isis::IssWACamera::IssWACamera(), Isis::KaguyaMiCamera::KaguyaMiCamera(), Isis::LoHighCamera::LoHighCamera(), Isis::LoMediumCamera::LoMediumCamera(), Isis::LroNarrowAngleCamera::LroNarrowAngleCamera(), Isis::LroWideAngleCamera::LroWideAngleCamera(), Isis::LwirCamera::LwirCamera(), Isis::MarciCamera::MarciCamera(), Isis::Mariner10Camera::Mariner10Camera(), MdisCamera(), Isis::MiniRF::MiniRF(), Isis::MocNarrowAngleCamera::MocNarrowAngleCamera(), Isis::MocWideAngleCamera::MocWideAngleCamera(), Isis::MsiCamera::MsiCamera(), Isis::NewHorizonsLeisaCamera::NewHorizonsLeisaCamera(), Isis::NewHorizonsLorriCamera::NewHorizonsLorriCamera(), Isis::NewHorizonsMvicFrameCamera::NewHorizonsMvicFrameCamera(), Isis::NewHorizonsMvicTdiCamera::NewHorizonsMvicTdiCamera(), Isis::NirCamera::NirCamera(), Isis::Camera::spacecraftNameLong(), Isis::SsiCamera::SsiCamera(), Isis::ThemisIrCamera::ThemisIrCamera(), Isis::ThemisVisCamera::ThemisVisCamera(), Isis::UvvisCamera::UvvisCamera(), Isis::VikingCamera::VikingCamera(), Isis::VimsCamera::VimsCamera(), and Isis::VoyagerCamera::VoyagerCamera().

QString Isis::Camera::m_spacecraftNameShort

protectedinherited

Shortened spacecraft name.

Definition at line 444 of file Camera.h.

Referenced by Isis::AmicaCamera::AmicaCamera(), Isis::ApolloMetricCamera::ApolloMetricCamera(), Isis::ApolloPanoramicCamera::ApolloPanoramicCamera(), Isis::Camera::Camera(), Isis::Chandrayaan1M3Camera::Chandrayaan1M3Camera(), Isis::CrismCamera::CrismCamera(), Isis::CTXCamera::CTXCamera(), Isis::DawnFcCamera::DawnFcCamera(), Isis::HiresCamera::HiresCamera(), Isis::HiriseCamera::HiriseCamera(), Isis::HrscCamera::HrscCamera(), Isis::IssNACamera::IssNACamera(), Isis::IssWACamera::IssWACamera(), Isis::KaguyaMiCamera::KaguyaMiCamera(), Isis::LoHighCamera::LoHighCamera(), Isis::LoMediumCamera::LoMediumCamera(), Isis::LroNarrowAngleCamera::LroNarrowAngleCamera(), Isis::LroWideAngleCamera::LroWideAngleCamera(), Isis::LwirCamera::LwirCamera(), Isis::MarciCamera::MarciCamera(), Isis::Mariner10Camera::Mariner10Camera(), MdisCamera(), Isis::MiniRF::MiniRF(), Isis::MocNarrowAngleCamera::MocNarrowAngleCamera(), Isis::MocWideAngleCamera::MocWideAngleCamera(), Isis::MsiCamera::MsiCamera(), Isis::NewHorizonsLeisaCamera::NewHorizonsLeisaCamera(), Isis::NewHorizonsLorriCamera::NewHorizonsLorriCamera(), Isis::NewHorizonsMvicFrameCamera::NewHorizonsMvicFrameCamera(), Isis::NewHorizonsMvicTdiCamera::NewHorizonsMvicTdiCamera(), Isis::NirCamera::NirCamera(), Isis::Camera::spacecraftNameShort(), Isis::SsiCamera::SsiCamera(), Isis::ThemisIrCamera::ThemisIrCamera(), Isis::ThemisVisCamera::ThemisVisCamera(), Isis::UvvisCamera::UvvisCamera(), Isis::VikingCamera::VikingCamera(), Isis::VimsCamera::VimsCamera(), and Isis::VoyagerCamera::VoyagerCamera().

SpiceDouble Isis::Spice::m_uB[3]

protectedinherited

This contains the sun position (u) in the bodyfixed reference frame (B).

It is left protected so that conversions between double and SpiceDouble do not have to occur in inheriting classes. Units are km

Definition at line 353 of file Spice.h.

Referenced by Isis::Sensor::IncidenceAngle(), Isis::Camera::LocalPhotometricAngles(), and Isis::Sensor::PhaseAngle().

The documentation for this class was generated from the following files:

src/messenger/objs/MdisCamera/MdisCamera.h
src/messenger/objs/MdisCamera/MdisCamera.cpp

Public Types

Public Member Functions

Static Public Member Functions

Protected Types

Protected Member Functions

Protected Attributes

Private Member Functions

Detailed Description

Member Enumeration Documentation

Constructor & Destructor Documentation

Member Function Documentation

Member Data Documentation
