JPEG2000 encoder class. More...

#include <JP2Encoder.h>

Collaboration diagram for Isis::JP2Encoder:

Public Member Functions
	JP2Encoder (const QString &jp2file, const unsigned int nsamps, const unsigned int nlines, const unsigned int nbands, const Isis::PixelType type)
	Constructs a JPEG2000 encoder object.
	~JP2Encoder ()
	JP2Encoder destructor.
JP2Error *	kakadu_error () const
void	OpenFile ()
	Open the JPEG2000 file and initialize it.
void	Write (unsigned char **inbuf)
	Write 8-bit data to JP2 file.
void	Write (short int **inbuf)
	Write 16-bit data to JP2 file.

Private Attributes
QString	p_jp2File
	Output file name.
unsigned int	p_sampleDimension
	Sample dimension of output file.
unsigned int	p_lineDimension
	Line dimension of output file.
unsigned int	p_bandDimension
	Band dimension of output file.
unsigned int	p_resolutionLevels
	Number of resolution levels used to make output file.
std::string	p_progressionOrder
	Progression order used to create output file.
unsigned int	p_codeBlockSize
	Code block size used to create output file.
bool	p_signedData
	Determines if output file will contain signed/unsigned <data.
unsigned int	p_tileSizeWidth
	Width of tiles used to create output file.
unsigned int	p_tileSizeHeight
	Height of tiles used to create output file.
std::vector< unsigned int >	p_precinctSize
	Precinct size(s) used to create output file.
unsigned int	p_pixelBits
	Number of bits per pixel used to create output file.
unsigned int	p_pixelBytes
	Number of bytes per pixel used to create output file.
int	p_flushLines
	Number of lines to store in memory before flushing the <buffer that is written to the codestream.
bool	p_writeStripes
	Number of lines written per call to Write methods.
int *	p_stripeHeights
	Determines the number of lines to be written at a time <to the codestream.
int *	p_maxStripeHeights
	Determines the maximum number of lines that can be <written at a time to the codestream.
int *	p_precisions
	Determines bit precision of each band in the output <JP2 file.
bool *	p_isSigned
	Determines if the data is signed/unsigned for each <band in the JP2 file.
JP2Error *	Kakadu_Error
	JP2 Error handling facility.

Detailed Description

JPEG2000 encoder class.

This class is used to convert image data into JPEG2000 format.

Here is an example of how to use JP2Encoder

char **jp2buf;
ProcessExport p;
Cube *icube;
JP2Encoder *JP2_encoder;
icube = p.SetInputCube("FROM",Isis::OneBand);
p.SetInputRange();
p.setFormat(ProcessExport::BIL);
jp2buf = new char* [1];
jp2buf[0] = new char[icube->Samples()];
p.SetOutputType(Isis::UnsignedByte);
p.SetOutputRange(1.0,255.0);
p.SetOutputNull(0.0);
JP2_encoder = new JP2Encoder(ui.GetFileName("TO"),icube->Samples(),
              icube->Lines(),icube->Bands(),Isis::UnsignedByte);
JP2_encoder->OpenFile();
p.StartProcess(toJP2);
p.EndProcess();
delete JP2_encoder;

If you would like to see JP2Encoder being used in implementation, see isis2std.cpp

Author: 2009-01-11 Janet Barrett

History:: 2009-01-11 Janet Barrett - Original version.

History:: 2012-04-06 Kris Becker - Fixed condition compilation where support for JP2K is disabled

Definition at line 80 of file JP2Encoder.h.

Constructor & Destructor Documentation

Isis::JP2Encoder::JP2Encoder	(	const QString &	jp2file,
		const unsigned int	nsamps,
		const unsigned int	nlines,
		const unsigned int	nbands,
		const Isis::PixelType	type
	)

Constructs a JPEG2000 encoder object.

Parameters

jp2file	Name of file where the encoded JP2 data will be stored.
nsamps	Sample dimension of image that will be encoded.
nlines	Line dimension of image that will be encoded.
nbands	Band dimension of image that will be encoded.
type	Pixel type of data that will be encoded.

Definition at line 46 of file JP2Encoder.cpp.

References _FILEINFO_.

Isis::JP2Encoder::~JP2Encoder ( )

JP2Encoder destructor.

Definition at line 296 of file JP2Encoder.cpp.

Member Function Documentation

void Isis::JP2Encoder::OpenFile ( )

Open the JPEG2000 file and initialize it.

Definition at line 118 of file JP2Encoder.cpp.

Referenced by Isis::JP2Exporter::write().

void Isis::JP2Encoder::Write ( unsigned char ** inbuf )

Write 8-bit data to JP2 file.

Parameters

inbuf The array of pointers to byte buffers that will be used to write out the image data. One byte buffer is required for each band in the image. Kakadu writes in a BIL manner.

Definition at line 270 of file JP2Encoder.cpp.

Referenced by Isis::JP2Exporter::writeLine().

void Isis::JP2Encoder::Write ( short int ** inbuf )

Write 16-bit data to JP2 file.

Parameters

inbuf The array of pointers to byte buffers that will be used to write out the image data. One byte buffer is required for each band in the image. Kakadu writes in a BIL manner.

Definition at line 285 of file JP2Encoder.cpp.

Member Data Documentation

JP2Error* Isis::JP2Encoder::Kakadu_Error

private

JP2 Error handling facility.

Definition at line 128 of file JP2Encoder.h.

unsigned int Isis::JP2Encoder::p_bandDimension

private

Band dimension of output file.

Definition at line 105 of file JP2Encoder.h.

unsigned int Isis::JP2Encoder::p_codeBlockSize

private

Code block size used to create output file.

Definition at line 108 of file JP2Encoder.h.

int Isis::JP2Encoder::p_flushLines

private

Number of lines to store in memory before flushing the <buffer that is written to the codestream.

Definition at line 116 of file JP2Encoder.h.

bool* Isis::JP2Encoder::p_isSigned

private

Determines if the data is signed/unsigned for each <band in the JP2 file.

Definition at line 125 of file JP2Encoder.h.

QString Isis::JP2Encoder::p_jp2File

private

Output file name.

Definition at line 102 of file JP2Encoder.h.

unsigned int Isis::JP2Encoder::p_lineDimension

private

Line dimension of output file.

Definition at line 104 of file JP2Encoder.h.

int* Isis::JP2Encoder::p_maxStripeHeights

private

Determines the maximum number of lines that can be <written at a time to the codestream.

Definition at line 121 of file JP2Encoder.h.

unsigned int Isis::JP2Encoder::p_pixelBits

private

Number of bits per pixel used to create output file.

Definition at line 114 of file JP2Encoder.h.

unsigned int Isis::JP2Encoder::p_pixelBytes

private

Number of bytes per pixel used to create output file.

Definition at line 115 of file JP2Encoder.h.

std::vector<unsigned int> Isis::JP2Encoder::p_precinctSize

private

Precinct size(s) used to create output file.

Definition at line 113 of file JP2Encoder.h.

int* Isis::JP2Encoder::p_precisions

private

Determines bit precision of each band in the output <JP2 file.

Definition at line 123 of file JP2Encoder.h.

std::string Isis::JP2Encoder::p_progressionOrder

private

Progression order used to create output file.

Definition at line 107 of file JP2Encoder.h.

unsigned int Isis::JP2Encoder::p_resolutionLevels

private

Number of resolution levels used to make output file.

Definition at line 106 of file JP2Encoder.h.

unsigned int Isis::JP2Encoder::p_sampleDimension

private

Sample dimension of output file.

Definition at line 103 of file JP2Encoder.h.

bool Isis::JP2Encoder::p_signedData

private

Determines if output file will contain signed/unsigned <data.

Definition at line 109 of file JP2Encoder.h.

int* Isis::JP2Encoder::p_stripeHeights

private

Determines the number of lines to be written at a time <to the codestream.

Definition at line 119 of file JP2Encoder.h.

unsigned int Isis::JP2Encoder::p_tileSizeHeight

private

Height of tiles used to create output file.

Definition at line 112 of file JP2Encoder.h.

unsigned int Isis::JP2Encoder::p_tileSizeWidth

private

Width of tiles used to create output file.

Definition at line 111 of file JP2Encoder.h.

bool Isis::JP2Encoder::p_writeStripes

private

Number of lines written per call to Write methods.

Definition at line 118 of file JP2Encoder.h.

The documentation for this class was generated from the following files:

src/base/objs/JP2Encoder/JP2Encoder.h
src/base/objs/JP2Encoder/JP2Encoder.cpp
